BVF 24-F User Manual

Rf room thermostat

Advertisement

Quick Links

User manual
BVF
24-F
RF room thermostat
PRG mode
Manual mode
Day Indicator
Clock
On/off button
Increase / decrease temperature
PRG button
CODE
PAIRING
According to the receiver's manual.
MODE
SELECT
Press
button to select PRG mode / manual mode / away mode.
CLOCK
Under thermostat on, press and hold
button for 3s, set the clock by adjusting the knob to left or right, each press of
bvfheating.com
TECHNICAL
DATA
Thermostat Operating Voltage: 2 x AAA 1.5V, alkaline batteries
Backup Storage:
Frequency:
Receiver capacity:
24-X
24-A
Switching options:
Temperature settings:
Accuracy:
Thermostat dimensions:
Color:
IP protection rating:
Certification:
PRODUCT
FEATURES
Large display can be clearly read with the background
lighting
Easy to fit thermostat and receiver
Knob button make it easy to use.
4 periods of each day programmable (5+1+1)
The display shows the set and the measured temperature
Compatible with 24-A, 24-P, 24-X
Current PRG period
RF pairing icon (appears when pairing only)
Key lock on
Heating on icon
Open window mode
Mode select button
EEPROM
868MHz
3600W/16A
3600W/16A
5+1+1 day, 4 periods each day
5°C ~ 35°C, 0.5°C increments
+/- 0.5°C
86mm x 86mm x 26.5mm
White
20
CE
button will go to next item setting.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 24-F and is the answer not in the manual?

Questions and answers

Summary of Contents for BVF 24-F

  • Page 1 User manual 24-F RF room thermostat TECHNICAL DATA Thermostat Operating Voltage: 2 x AAA 1.5V, alkaline batteries Backup Storage: EEPROM Frequency: 868MHz Receiver capacity: 24-X 3600W/16A 24-A 3600W/16A Switching options: 5+1+1 day, 4 periods each day Temperature settings: 5°C ~ 35°C, 0.5°C increments Accuracy: +/- 0.5°C...
  • Page 2 User manual SETTINGS Press and hold button for 3s to enter program setting. Set the schedule (Weekday-Period-Start time-Temp.) by adjusting knob to left or right to change value setting, each press of button will go to next item setting. Weekday is fixed( Mon.-Fri., Sat., Sun.) Default values: Period Wake up 1...
  • Page 3 (Flashing) Heating is active. (Steady) Start pairing with this button Long press for 3 seconds Pairing mode. (Flashing) PAIRING WITH 24-F THERMOSTAT. STEP BY STEP Make sure the receiver and the thermostat is close to each other. Long press (3 seconds) the code pairing button on the receiver until LED starts flashing yellow. Turn off sender (24-F) by pressing On/Off button, than long press          button until  the RF code shows on the top of the screen (XXXX). Rotate the main button (24-F) to left or right.
  • Page 4 User manual INSTALLATION OF THE RECEIVER Make sure that the heating panels is disconnected. Please remove the blind plug with the screwdriver included in the receiver box. 3. Connect the 24-P receiver according to the picture below. Fix it with the screwdriver included in the packaging. bvfheating.com...
