BVF 24-F User Manual

User manual
BVF 24-F
RF room thermostat (sender only)
PRG mode
Manual mode
Day Indicator
Clock
On/off button
Increase / decrease temperature
PRG button
CODE PAIRING
According to the receiver's manual.
MODE SELECT
Press button to select PRG mode / manual mode / away mode.
CLOCK
Under thermostat on, press and hold button for 3s, set the clock by adjusting the knob to left or right, each press of
bvfheating.com
TECHNICAL DATA
Thermostat Operating Voltage: 2 x AAA 1.5V, alkaline batteries
Backup Storage:
Frequency:
Receiver capacity:
24-X
24-A
Switching options:
Temperature settings:
Accuracy:
Thermostat dimensions:
Color:
IP protection rating:
Certification:
PRODUCT FEATURES
• Large display can be clearly read with the background
lighting
• Easy to fit thermostat and receiver
• Knob button make it easy to use.
• 4 periods of each day programmable (5+1+1)
• The display shows the set and the measured temperature
• Compatible with 24-A, 24-P, 24-X
Current PRG period
RF pairing icon (appears when pairing only)
Key lock on
Heating on icon
Open window mode
Mode select button
EEPROM
868MHz
3600W/16A
3600W/16A
5+1+1 day, 4 periods each day
5°C ~ 35°C, 0.5°C increments
+/- 0.5°C
86mm x 86mm x 26.5mm
White
20
CE
button will go to next item setting.
