- Page 1 XMM915 INSTRUCTION MANUAL Please read this manual carefully If you have any questions along the way, just message to us. We’re ready to help! USA-D0...
- Page 2 CAUTION: PLEASE READ ENTIRE MANUAL PRIOR TO USE AND SAVE THESE INSTRUCTIONS Before getting started, let’s check below lists to make sure it is just right for you! MAX:400mm/15.75" No? This mount is NOT compatible. Check your TV (MIN:100mm/3.94") Yes? Perfect ! VESA is within Min and Max size MAX:400mm/15.75"...
- Page 3 Exploded drawing (view) Nuts M6x12mm Bolt Extended arms Wall Plate Unit STEP 1 Attach TV Plate to TV If any parts are missing or damaged, do not retum the damaged item to your dealer. Please contact customer service through Amazon Orders. NOTE: Not all hardware included will be used.
- Page 4 Disassemble Wall Plate Unit into Two Pieces Wall plate TV plate 1-2 Choose Configuration If your TV VESA size is above 200*200mm, you need to assemble extended arms onto TV plate using nuts and bolts and Open End Wrench per below option 2 - option 5 shown. Option 1 Option 3 ①...
- Page 5 1-3 Select TV Screws Select the right length and diameter TV screws. 1-4 Need Spacer 1-6 Attach the TV Plate VESA≤200X200mm Round Back Long Screw Cable lnterference lnset Holes Tips: Washer are not required for M8 screws 1-5 No Need Spacer 200X200mm<VESA≤400X400mm Please ensure that all four screws enter the VESA hole before tightening...
-
Page 6: Parts And Hardware
STEP 2 Attach Wall Plate to Wall For wood stud installation, follow STEP 2A on PAGE 6 For concrete installation, follow STEP 2B on PAGE 7 Parts and Hardware Wall plate Lag Bolt M7x55mm Level x1 STEP 2A Attach Wall Plate to Wall Wood Stud Option Wall Requirement Min. - Page 7 STEP 2B Attach Wall Plate to Solid Concrete Wall Wall Requirement Avoid Water Pipes Avoid Cables Concrete Wall Anchor Min. STOP STOP 8"(203mm) Concrete Wall Anchor 3pcs (Anchor Size: φ10x50mm) Please contact the seller via Amazon "Orders" and message to us to have these additional pieces shipped directly to you.
- Page 8 STEP 3 Wall Plate lnstallation lntegrity Test Parts Needed M6x7mm Bolt 3-1 Before hanging TV, please try to pull the mount to make sure that it has been assembled on the wall tightly. 77 lbs (35 kg) 3-2 Hang and Secure TV to Wall Plate...
- Page 9 STEP 4 Adjustments Parts Needed Velcro x3 4-1 TV leveling adjustment (±4°): Loosen 2 leveling bolts on the rear of TV plate by maximum 2 turns, adjust to level, and retighten to secure. ±4° Loosen Tighten 4-2 Tilting angle adjustment (+8°/-5°) ： Pull TV to your desired angle then fasten 2 tilting nuts with open end wrench.
- Page 10 4-3 Cables manage Manage TV cables orderly and guide them through the velcros. Velcro Dimensions TV INTERFACE FULLY ASSEMBLED MOUNT 436.3mm 400mm [17.18in] [15.75in] 436.3mm 400mm [17.18in] [15.75in] WALL PLATE SIDE VIEW - EXTENDED 70mm Ø8.5mm [2.76in] [Ø0.33in] 224mm 250mm [8.82in] [9.84in] -90°...
