- Page 1 XMM007 INSTRUCTION MANUAL For 26-55" TV If you have any questions along the way, just give us a call 1-800-460-0956 or mail to customerservice@x-mount.com. We’re ready to help!
- Page 2 Before getting started, let’s check below lists to make sure it is just right for you! MAX:400mm/15.74" (MIN:200mm/7.87") Check your TV VESA is within No? This mount is NOT compatible. Min and Max size MAX:400mm/15.74" (MIN:100mm/3.93") Yes? Perfect ! CAUTION: DO NOT exceed the maximum weight Does your TV No? Perfect –...
- Page 3 TV INTERFACE 400mm [15.75in] 400mm [15.75in] WALL PLATE TOP VIEW - EXTENDED SIDE VIEW - EXTENDED 5° 50mm 15° [1.97in] 473mm 224mm [18.62in] [8.82in] 112mm [4.41in] SIDE VIEW - RETRACTED FULLY ASSEMBLED MOUNT TOP VIEW - RETRACTED 468mm [18.43in] 63mm [2.48in] 429mm [16.90in]...
- Page 4 WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service.
- Page 5 Parts and Hardware for STEP 2 Lag Bolt M8 Washer Wall Plate Unit CAUTION: Do not use in drywall or wood Concrete Wall Anchor 4pcs Parts and Hardware for STEP 3 Allen Key M6x8mm Bolt M6x15mm Bolt Extension Arm End Support M6x8mm Bolt...
- Page 6 1-2 Need Spacer? 1-1 Select TV Screws No, go to PAGE 7 for detailed combination. Bracket Short Screw Washer TV back Yes, go to PAGE 7 for detailed combination. Long Screw Washer Spacer Bracket TV back...
- Page 7 1-3 Attach the TV Brackets Screw and washer Spacer(s), screw(s) and washer(s) Tips: If you need to combine M8( c / f ) screw with 2.5mm spacer( j ), you have to remove the inner circle.
- Page 8 CAUTION: Avoid potential personal injury or property damage! ● Drywall covering the wall, must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: common 2 x 4 in. (51 x 102 mm) nominal 1½ x 3½ in. (38 x 89 mm) ●...
- Page 9 3. Drill pilot holes using a 7/32 in. (5.5 mm) diameter drill bit. IMPORTANT: Pilot holes must be drilled to a depth of 2.5 in. (64 mm). Be sure to drill into the center of the studs. 4. Install wall plate using three lag bolts and three washers .
- Page 10 CAUTION: Avoid potential personal injury or property damage! ● Mount the wall plate assembly directly onto the concrete surface ● Minimum solid concrete thickness: 8 in. (203 mm) 1. Position the wall plate on the wall at your desired height. Level the wall plate and mark the hole locations.
- Page 11 3. Insert four anchors CAUTION: Be sure the anchors are seated flush with the concrete surface. 4. Insert wall plate using four lag bolts and washers .Tighten the lag bolts only until they are pulled firmly against the wall plate. CAUTION: Improper use could reduce the holding power of the lag bolt.
- Page 13 Before hanging TV, please try to pull the mount to make sure that it has been assembled on the wall tightly. 60 LBS (27 kg)
- Page 14 Hang TV/bracket assembly onto wall plate , wrap clips on bracket around extension arms and tighten them using bolts HEAVY! You may need assistance with this step.
- Page 15 6-1 TV leveling adjustment (±4°): Loosen 4 leveling bolts on the rear of TV plate by maximum 2 turns, adjust to level, and retighten to secure. Loosen Tighten...
- Page 16 6-2 Tilting angle adjustment (+5°/-15°) ： Loosen handle and tilting bolt, adjust TV to your desired position, then tighten handle and tilting bolt. Tilting bolts Tighten Handle Loosen +5° -15°...
