Cooper & Hunter Medium Static CH-RS06MDT-MS Owner's Manual

Slim duct air conditioners

Hide thumbs

Table Of Contents

Quick Links

Download this manual

SPLIT-TYPE

Owner's Manual

Medium Static

Models with sensor:

CH-RS06MDT-MS

CH-RS09MDT-MS

CH-RS12MDT-MS

CH-RS18MDT-MS

IMPORTANT NOTE:

Read this manual carefully before installing

or operating your new air conditioning unit.

Make sure to save this manual for future

reference.

ROOM AIR CONDITIONER

Model with dip switch:

CH-RS06-12MDT- MS

SLIM DUCT

Air Conditioners

Table of Contents

Need help?

Do you have a question about the Medium Static CH-RS06MDT-MS and is the answer not in the manual?

Questions and answers

Summary of Contents for Cooper & Hunter Medium Static CH-RS06MDT-MS

Page 1 SLIM DUCT Air Conditioners SPLIT-TYPE ROOM AIR CONDITIONER Owner’s Manual Medium Static Models with sensor: Model with dip switch: CH-RS06MDT-MS CH-RS06-12MDT- MS CH-RS09MDT-MS CH-RS12MDT-MS CH-RS18MDT-MS IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference.
Page 3 About the Company With more than 25 years of experience in air conditioning and ventilation, Cooper&Hunter is considered one of the HVAC leaders in the US market. Distributed in more than 55 countries worldwide, brand dedicated technological innovation consumer-driven product development, while generating HVAC equipment that adheres to the highest quality standards in the US.
Page 4: Warranty Registration
Learn more about your unit Learn more technical information about your unit at www.cooperandhunter.us, where you can ﬁnd submittals, leaﬂets, videos and all technical speciﬁcations of your unit. Step 1 On the website cooperandhunter.us, type in your unit model number into the search ﬁeld and click enter.
Page 5 How to apply for the rebate program Almost all Cooper&Hunter equipment is eligible for the rebate program.Visit our website to see if the rebates apply to your location. Step 1 Go to cooperandhunter.us/rebates to add your zip code and select your outdoor unit to see if your unit qualiﬁes for the rebate.
Page 6: Table Of Contents
CONTENTS SAFETY PRECAUTIONS CARE AND MAINTENANCE TROUBLESHOOTING PACKING AND UNPACKING THE UNIT DIP SWITCH INSTRUCTION...
Page 7: Safety Precautions
SAFETY PRECAUTIONS It is really important that you read Safety Precautions Before Operation and Installation. Incorrect installation due to ignoring instructions can cause serious damage or injury. The seriousness of potential damage or injuries is classiﬁed as either a WARNING or CAUTION. Explanation of Symbols WARNING This symbol indicates the possibility of personnel injury or loss of...
Page 8: Electrical Warnings
ELECTRICAL WARNINGS Only use the speciﬁed wire. If the wire is damaged, it must be replaced by the ● manufacturer, its service agent or similarly qualiﬁed persons in order to avoid a hazard. The product must be properly grounded at the time of installation, or electric ●...
Page 9 WARNING FOR USING FLAMMABLE REFRIGERANTS Do not use means to accelerate the defrosting process or to clean, other than ● those recommended by the manufacturer. The appliance shall be stored in a room without continuously operating ignition ● sources (for example: open ﬂames, an operating gas appliance or an operating electric heater).
Page 10 Room size restriction The appliances are connected via an air duct system to one or more rooms, the bottom of the air outlet of the air duct in the room should be at a height ≥7.3ft/2.2m from the ﬂoor. In UL/CSA 60335-2-40, the R454B refrigerant belongs to mildly ﬂammable refrigerants, which will limit the room area of the system service.
Page 11 Height of outlet/m A/m² Mc/Kg Mmax/kg Anvmin/m² 2.685 0.045 2.941 0.042 3.177 0.038 3.396 0.035 3.602 0.031 3.797 0.028 3.983 0.024 4.160 0.020 4.330 0.016 4.493 0.013 4.651 0.009 4.803 0.005 4.951 0.001 Note: Take the Mc =5.0kg as an example. For appliances serving one or more rooms with an air duct system, the room area calculation shall be determined based on the total area of the conditioned space (TA) connected by ducts taking into consideration that the circulating airﬂow distributed to all the rooms by the appliance integral indoor...
Page 12 [ft/m] inst 6.0~7.3/ c or 7.6/2.3 7.9/2.4 8.6/2.6 9.2/2.8 9.9/3.0 [ozs/kg] 1.8~2.2 12/1.10 ＜=62.6/1.776 60/5.53 57/5.29 47/4.35 44/4.06 63.4/1.8 55/5.07 51/4.68 67/6.15 64/5.88 52/4.83 49/4.51 70.5/2.0 61/5.64 56/5.20 73/6.76 70/6.47 58/5.31 54/4.96 77.5/2.2 67/6.20 62/5.72 80/7.38 76/7.06 63/5.80 84.6/2.4 73/6.76 68/6.24 59/5.41 86/7.99...
Page 13 1. Installation(where refrigerant pipes are allowed) - Any person who is involved with working on or breaking into a refrigerant circuit should hold a current valid certiﬁcate from an industry-accredited assessment authority, which authorises their competence to handle refrigerants safely in accordance with an industry recognised assessment speciﬁcation. - Maintenance and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the person competent in the use of ﬂammable refrigerants.
Page 14: Information Servicing
c. During the evacuation test, after achieving a vacuum level speciﬁed in the manual or less, the refrigeration system shall be isolated from the vacuum pump and the pressure shall not rise above 1500 microns within 10 min. The vacuum pressure level shall be speciﬁed in the manual, and shall be the lessor of 500 microns or the value required for compliance with national and local codes and standards, which may vary between residential, commercial,and industrial...
Page 15 6. No ignition sources No person carrying out work in relation to a REFRIGERATING SYSTEM which involves exposing any pipe work shall use any sources of ignition in such a manner that it may lead to the risk of ﬁre or explosion. All possible ignition sources, including cigarette smoking, should be kept su ciently far away from the site of installation, repairing, removing and disposal, during which refrigerant can possibly be released to the surrounding space.
Page 16 12. Cabling Check that cabling will not be subject to wear, corrosion, excessive pressure, vibration, sharp edges or any other adverse environmental e ects. The check shall also take into account the e ects of aging or continual vibration from sources such as compressors or fans.
Page 17 15. Charging procedures In addition to conventional charging procedures, the following requirements shall be followed: Works shall be undertaken with appropriate tools only (In case of uncertainty,  please consult the manufacturer of the tools for use with ﬂammable refrigerants) Ensure that contamination of di erent refrigerants does not occur when using ...
Page 18 for the recovered refrigerant and labelled for that refrigerant (i. e. special cylinders for the recovery of refrigerant). Cylinders shall be complete with pressure-relief valve and associated shut-o valves in good working order. Empty recovery cylinders are evacuated and, if possible,cooled before recovery occurs. The recovery equipment shall be in good working order with a set of instructions concerning the equipment that is at hand and shall be suitable for the recovery of the ﬂammable refrigerant.
Page 19: More Features
More Features NOTE Every time the air conditioner is powered on, a buzzing sound will be heard to indicate that the product has been powered on normally. If there is no sound, it is possible that the unit is abnormal. Please power on again or check the circuit.
Page 20: Care And Maintenance 1
CARE AND MAINTENANCE CAUTION Cleaning Your Indoor Unit • Always TURN OFF your AC system and disconnect its power supply before cleaning or maintenance. • Only use a soft, dry cloth to wipe the unit clean. You can use a cloth soaked in warm water to wipe it clean if the unit is especially dirty.
Page 21: Troubleshooting 1
TROUBLESHOOTING CAUTION If any of the following conditions occurs, turn o your unit immediately! • The power cord is damaged or abnormally warm • You smell a burning odor • The unit emits loud or abnormal sounds • A power fuse blows or the circuit breaker frequently trips •...
Page 22 Problem Possible Causes Solution Wait for the power to be restored Power failure The power is turned o Turn on the power The unit is not The fuse is burned out Replace the fuse working Replace batteries Remote control batteries are dead The Unit’...
Page 23 Troubleshoot Your Wireless Remote Control Problem Possible Causes Solution In AUTO mode, the fan speed is Check whether AUTO set automatically and cannot be mode is selected. changed. The fan speed cannot be changed. In DRY mode, the FAN SPEED Check whether DRY button is ine ective.
Page 24: Packing And Unpacking The Unit
PACKING AND UNPACKING THE UNIT Instructions for packing unpacking the unit: Unpacking: Indoor unit: 1. Cut the packing belt. 2. Unpack the package. 3. Take out the packing cushion and packing support. 4. Remove the packing ﬁlm. 5. Take out the accessories. 6.
Page 25: Dip Switch Instruction
DIP SWITCH INSTRUCTION for Capacity Change ENC1 dip switch is used for capacity change. When matching with single zone condensers, the indoor unit will automatically adjust to 6,000 BTU/H, 9,000 BTU/H or 12,000 BTU/H according to condensers capacity. When matching with multi-zone condensers, it needs to set the ENC1. Change the capacity of indoor unit to 6,000 BTU/H by adjusting the dip switch ENC1 from “0”...
Page 26: Technical Support
Technical Support Single & Multi-Zone Mini Splits • PTACs • Portables • TTWs • Light Commercial A/C Systems Limited Warranty provided by Cooper&Hunter (hereby referred to as C&H) covers speciﬁed products and parts, subject to the following details: Our warranty: C&H Limited Warranty applies only to products installed by a licensed HVAC technician.
Page 27 10. For resetting of power or the circuit breakers and replacement of other types of fuses, both internal and external. 11. For any damage caused by the use of dirty, recycled, or wrong type of refrigerants and lubricants. 12. For damage due to moisture, air, dust, sand, dirt, etc., that have been allowed into the system. 13.
Page 28 negotiations, representations, or promises, whether oral or written, of either party shall be deemed to have been merged herein. If any part of this warranty agreement shall be invalidated for any reason, such part shall be deleted, and the remainder shall be una ected and shall continue in full force and e ect. This Warranty provides you certain legal rights and you may also have other rights, which vary from State to State.
Page 29 10112024...

This manual is also suitable for:

Medium static ch-rs09mdt-ms Medium static ch-rs12mdt-ms Medium static ch-rs18mdt-ms Medium static ch-rs06-12mdt- ms
