Installation Manual

Models with refrigerant and huminity sensor:

CH-RSH09MMC

CH-RSH12MMC

CH-RSH16MMC

IMPORTANT NOTE:

Read this manual carefully before installing

or operating your new air conditioning unit.

Make sure to save this manual for future

reference.

ROOM AIR CONDITIONER

MINI FLOOR

CONSOLE

Table of Contents

Need help?

Do you have a question about the CH-RSH09MMC and is the answer not in the manual?

Questions and answers

Summary of Contents for Cooper & Hunter CH-RSH09MMC

Page 1 MINI FLOOR CONSOLE SPLIT-TYPE ROOM AIR CONDITIONER Installation Manual Models with refrigerant and huminity sensor: CH-RSH09MMC CH-RSH12MMC CH-RSH16MMC IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future...
Page 3 About the Company With more than 25 years of experience in air conditioning and ventilation, Cooper&Hunter is considered one of the HVAC leaders in the US market. Distributed in more than 55 countries worldwide, brand dedicated technological innovation consumer-driven product development, while generating HVAC equipment that adheres to the highest quality standards in the US.
Page 4: Warranty Registration
Learn more about your unit Learn more technical information about your unit at www.cooperandhunter.us, where you can ﬁnd submittals, leaﬂets, videos and all technical speciﬁcations of your unit. Step 1 On the website cooperandhunter.us, type in your unit model number into the search ﬁeld and click enter.
Page 5 How to apply for the rebate program Almost all Cooper&Hunter equipment is eligible for the rebate program.Visit our website to see if the rebates apply to your location. Step 1 Go to cooperandhunter.us/rebates to add your zip code and select your outdoor unit to see if your unit qualiﬁes for the rebate.
Page 6: Table Of Contents
CONTENTS SAFETY PRECAUTIONS INTELLIGENT SENSOR FOR OPTIMAL HUMIDITY CONTROL PRODUCT OVERVIEW PRODUCTION INSTALLATION REFRIGERANT PIPING CONNECTION WIRING PRECAUTIONS AIR EVACUATION NOTE ON ADDING REFRIGERANT TEST RUN PACKING AND UNPACKING THE UNIT...
Page 7: Safety Precautions
SAFETY PRECAUTIONS It is really important you read Safety Precautions Before Operation and Installation Incorrect installation due to ignoring instructions can cause serious damage or injury. The seriousness of potential damage or injuries is classiﬁed as either a WARNING or CAUTION. Explanation of Symbols WARNING This symbol indicates the possibility of personal injury or loss of...
Page 8 WARNINGS FOR PRODUCT INSTALLATION Turn o the air conditioner and disconnect the power before performing any ● installation or repairing. Failure to do so can cause electric shock. Installation must be performed by an authorized dealer or specialist. Defective ● installation can cause water leakage, electrical shock, or ﬁre.
Page 9: Intelligent Sensor For Optimal Humidity Control
INTELLIGENT SENSOR FOR OPTIMAL HUMIDITY CONTROL To enjoy the ideal humidity level without sacriﬁcing a comfortable room tempera- ture, it is important to understand how humidity control units work. If your units are equipped with humidity sensors, the following information explains how these sen- sors work.
Page 10 Outdoor unit Model Indoor unit CH-RES09-230VO CH-RSH09MMC CH-RHP09-230VO CH-RES12-230VO CH-RSH12MMC CH-RHP12-230VO CH-RES18-230VO CH-RSH16MMC CH-RHP18-230VO [ft/m] inst 0.33~3.93 c or [oz/kg] 0.1~1.2 ≤62.6/1.776 12/1.10 60/5.53 60/5.53 63.4/1.8 67/6.15 67/6.15 70.5/2.0 73/6.76 73/6.76 77.5/2.2 80/7.38 80/7.38 84.6/2.4 86/7.99 86/7.99 91.7/2.6 93/8.60 93/8.60 98.7/2.8...
Page 11 1. Installation(where refrigerant pipes are allowed) - Any person who is involved with working on or breaking into a refrigerant circuit should hold a current valid certiﬁcate from an industry-accredited assessment authority, which authorises their competence to handle refrigerants safely in accordance with an industry recognised assessment speciﬁcation. - Maintenance and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the person competent in the use of ﬂammable refrigerants.
Page 12 not be isolated from the low side of the system in which case the entire system shall be pressure tested to the low side design pressure. b. The test pressure after removal of pressure source shall be maintained for at least 1 h with no decrease of pressure indicated by the test gauge, with test gauge resolution not exceeding 5% of the test pressure.
Page 13 NOTE Examples of leak detection ﬂuids are - bubble method, - ﬂuorescent method agents. If a leak is suspected, all naked ﬂames shall be removed/extinguished. If a leakage of refrigerant is found which requires brazing, all of the refrigerant shall be recovered from the system, or isolated (by means of shut o valves) in a part of the system remote from the leak.
Page 14 Explanation of symbols displayed on the indoor unit or outdoor unit This symbol shows that this appliance used a ﬂammable refrigerant. If the refrigerant is leaked and exposed to an WARNING external ignition source, there is a risk of ﬁre. This symbol shows that the operation manual should be CAUTION read carefully.
Page 15: Product Overview 1
PRODUCT OVERVIEW NOTE ON ILLUSTRATIONS: The piping can be connected from the left, right, rear and lower sides of the unit. Please select the piping method according to the actual demand. Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit may be slightly di erent.
Page 16: Product Installation
PRODUCT INSTALLATION ACCESSORIES The air conditioning system comes with the following accessories. Use all of the installation parts and accessories to install the air conditioner. Improper installation may result in water leakage, electrical shock and ﬁre, or cause the equipment to fail. The items are not included with the air conditioner must be purchased separately.
Page 17 INSTALLATION SUMMARY Install the indoor unit Install the drainpipe Install the outdoor unit Evacuate the Connect the wires Connect the refrigerant refrigeration system pipes Perform a test run...
Page 18: Select Installation Location
Install Your Indoor Unit Select installation location NOTE Panel installation should be performed after piping and wiring have been completed. Proper installation locations meet the following standards: Enough room exists for the There is no direct radiation Enough room exists for ...
Page 19: Installing The Main Body
Installing the main body After loosening the screws, remove the mounting plate from the unit. Remove the mounting plate NOTE: Loosen the screw If the pipe comes out on the left, it is necessary to loosen the screws on the bottom mounting Loosen the plate.
Page 20 Taking the indoor unit apart to Bottom mounting plate installation without skirting line. connect the pipes The bottom mounting plate is ﬁxed 1. Open the bottom piping cover plate. directly to the wall. Press and hold the bottom two buckles, and then rotate to open the piping cover plate.
Page 21: Drill Wall Hole For Connective Piping
Drill wall hole for connective piping Determine the location of the wall hole based on the location of the outdoor unit. 2. Using a 2.5in (65mm) core drill, drill a hole in the wall. Make sure that the hole is drilled at a slight downward angle, so that the outdoor end of the hole is lower than the indoor end by about 0.5in (12mm).
Page 22: Connect Drain Hose
Connect drain hose NOTE ON DRAINPIPE INSTALLATION The drainpipe is used to drain water away from • When using an extended drainpipe, tighten the unit. Improper installation may cause unit the indoor connection with an additional and property damage. protection tube. This prevents it from pulling loose.
Page 23 Install Your Outdoor Unit Select installation location : PRIOR TO INSTALLATION NOTE Before installing the outdoor unit, you must choose an appropriate location. The following are standards that will help you choose an appropriate location for the unit. Proper installation locations meet the following standards: 20in (500mm) or more when front and sides of the unit are clear ...
Page 24: Install Drain Joint
Install drain joint Base pan hole of outdoor unit Step 1： Find out the base pan hole of outdoor unit. Seal Step 2： Fit the rubber seal on the end of the drain joint that will connect to the ● outdoor unit.
Page 25: Anchor Outdoor Unit
Anchor Outdoor Unit WARNING WHEN DRILLING INTO CONCRETE, EYE PROTECTION IS RECOMMENDED AT ALL TIME. The outdoor unit can be anchored to the ground or to a wall-mounted bracket with bolt(M10). Prepare ● the installation base of the unit according to the dimensions below. The following is a list of di erent outdoor unit sizes and the distance between their mounting feet.
Page 26: Refrigerant Piping Connection
REFRIGERANT PIPING CONNECTION When connecting refrigerant piping, DO NOT let substances or gases other than the speciﬁed refrigerant enter the unit. The presence of other gases or substances will lower the unit’s capacity, and can cause abnormally high pressure in the refrigeration cycle. This can cause explosion and injury.
Page 27: Connection Instructions-Refrigerant Piping
Connection Instructions—Refrigerant Piping CAUTION • The branching pipe must be installed horizontally. An angle of more than 10° may cause malfunction. DO NOT install the connecting pipe until both indoor and outdoor units have been installed. • • Insulate both the gas and liquid piping to prevent condensation. Step 1: Cut pipes Step 2: Remove burrs When preparing refrigerant pipes, take...
Page 28 Outdoor unit Liquid side piping (Smaller diameter) • Clamp ﬂare from on the end of the pipe. The end of the pipe must extend beyond the ﬂare form. (Bigger Flare form Pipe • Place ﬂaring tool onto the form. • Turn the handle of the ﬂaring tool clockwise Torque wrench until the pipe is fully ﬂared.
Page 29: Wiring Precautions
WIRING PRECAUTIONS WARNING BEFORE PERFORMING ANY ELECTRICAL WORK, READ THESE WARNINGS. All wiring must comply with local and national To avoid getting an electric shock, never ● ● electrical codes, regulations and must be installed touch the electrical components soon by a licensed electrician.
Page 30: Outdoor Unit Wiring
NOTE ON CIRCUIT BREAKER When the maximum current of the air conditioner is more than 16A, a circuit breaker or leakage protection switch with protective device shall be used (purchased seperately). When the maximum current of the air conditioner is less than 16A, the power cord of air conditioner shall be equipped with plug (purchased seperately).
Page 31: Indoor Unit Wiring
INDOOR UNIT WIRING 1. Prepare the cable for connection a. Using wire strippers, strip the rubber Casing connecting plate jacket from both ends of the signal cable to reveal about 5.9in (150mm) of the wire. b. Strip the insulation from the ends of the wires.
Page 32: Air Evacuation
AIR EVACUATION NOTICE When opening valve stems, turn the hexagonal wrench until it hits against the stopper. Do not try to force the valve to open further. Close the Low Pressure side of the manifold Preparations and precautions gauge, and turn o the vacuum pump. Wait for 5 minutes, then check that there Air and foreign matter in the refrigerant circuit has been no change in system pressure.
Page 33: Note On Adding Refrigerant
NOTE ON ADDING REFRIGERANT CAUTION DO NOT mix refrigerant types. Some systems require additional charging depending on pipe lengths. In North America, the standard pipe length is 25ft (7.5m). The refrigerant should be charged from the service port on the outdoor unit’s low pressure valve.
Page 34: Test Run
TEST RUN CAUTION Failure to perform the test run may result in unit damage, property damage, or personal injury. f. Check to see that the drainage system is Before test run unimpeded and draining smoothly. g. Ensure there is no vibration or abnormal A test run must be performed after the entire noise during operation.
Page 35: Packing And Unpacking The Unit
PACKING AND UNPACKING THE UNIT Instructions for packing unpacking the unit: Unpacking: Indoor unit: 1.Cut the packing belt. 2. Unpack the package. 3. Take out the packing cushion and packing support. 4. Remove the packing ﬁlm. 5. Take out the accessories. 6.
Page 36: Technical Support
Technical Support Single & Multi-Zone Mini Splits • PTACs • Portables • TTWs • Light Commercial A/C Systems Limited Warranty provided by Cooper&Hunter (hereby referred to as C&H) covers speciﬁed products and parts, subject to the following details: Our warranty: C&H Limited Warranty applies only to products installed by a licensed HVAC technician.
Page 37 10. For resetting of power or the circuit breakers and replacement of other types of fuses, both internal and external. 11. For any damage caused by the use of dirty, recycled, or wrong type of refrigerants and lubricants. 12. For damage due to moisture, air, dust, sand, dirt, etc., that have been allowed into the system. 13.
Page 38 negotiations, representations, or promises, whether oral or written, of either party shall be deemed to have been merged herein. If any part of this warranty agreement shall be invalidated for any reason, such part shall be deleted, and the remainder shall be una ected and shall continue in full force and e ect. This Warranty provides you certain legal rights and you may also have other rights, which vary from State to State.
Page 39 10112024...
