SOPHIA
M UL TI-ZONE
DUCTLESS INVERTER
SPLIT AIR CONDITIONER
WITH HEAT PUMP
CONSOLE TYPE
USER'S MANUAL
INDOOR UNIT
Models:
CH-09MSPHMC-230VI
CH-12MSPHMC-230VI
IMPORTANT NOTE:
Read this manual carefully before
•
installing or operating your new air
conditioning unit. Make sure to save
this manual for future reference.
This manual only describes the installation of
•
outdoor unit. When installing the indoor unit,
refer to the installation manual of indoor unit.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Cooper & Hunter SOPHIA CH-09MSPHMC-230VI
Summary of Contents for Cooper & Hunter SOPHIA CH-09MSPHMC-230VI
- Page 1 SOPHIA M UL TI-ZONE DUCTLESS INVERTER SPLIT AIR CONDITIONER WITH HEAT PUMP CONSOLE TYPE USER’S MANUAL INDOOR UNIT Models: CH-09MSPHMC-230VI CH-12MSPHMC-230VI IMPORTANT NOTE: Read this manual carefully before • installing or operating your new air conditioning unit. Make sure to save this manual for future reference.
- Page 2 Table of Contents Owner’s Manual Safety Precautions ............ SAFETY FIRST Indoor Unit Parts and Major Functions ..05 Manual Operations ............
-
Page 3: Table Of Contents
Care and Maintenance ......a. Unit Maintenance ........b. How to Clean the Air Filter ....... c. Repairing Refrigerant Leaks ...... d. Preparation for Periods of Non-use ..09 Troubleshooting ......... a. Common Problems ......b. Troubleshooting Tips ...... Page 3 ... - Page 4 Safety Precautions Thank you for purchasing this air conditioner. This manual will provide you with information on how to operate, maintain, and troubleshoot your air conditioner. Following the instructions will ensure the proper function and extended lifespan of your unit. Please pay attention to the following signs: Failure to observe a warning may result in death.
- Page 5 Indoor Unit Parts And Major Functions Unit Parts Air flow louver (at air outlet) Display panel Air inlet (with air filter in it) Air flow louver (at air outlet) Refrigerant connecting pipe Drain hose Fig. 2.1 Operating Conditions Use the system under the following temperatures for safe and e ective operation. If the air conditioner is used under di erent conditions, it may malfunction or become less e cient.
- Page 6 Features Default Setting Louver Angle Memory Function (Optional) When the air conditioner restarts after a power Some models are designed with a louver angle failure, it will default to the factory settings memory function. When the unit restarts after a (AUTO mode, AUTO fan, 24°C (76°F)).
- Page 7 Manual Operations This display panel on the indoor unit can be used When cooling to operate the unit in case the remote control Adjust the louver downwards (horizontally). has been misplaced or is out of batteries. (See Fig.3.3). When heating Infrared receiver Adjust the louver vertically.
-
Page 8: Care And Maintenance
Care And Maintenance WARNING: DO NOT REMOVE OR Safety Precautions CLEAN THE FILTER BY YOURSELF Contact an authorized service technician for • repair or maintenance. Improper repair and Removing and cleaning the filter can be maintenance may cause water leakage, dangerous. -
Page 9: Repairing Refrigerant Leaks
3. Hold the tabs of the frame,and remove the Repairing Refrigerant Leaks 4 claws. (The special function lter can be washed with water once every 6 months. It WARNING isrecommended that you replace it once every 3 years.) If the refrigerant leaks, turn o the air •... -
Page 10: Troubleshooting
Troubleshooting CAUTIONS If one of the following conditions occurs, switch o the power supply immediately and contact your dealer for further assistance. The operation light continues to flash rapidly after the unit has been restarted. • The remote control buttons do not work. •... -
Page 11: Troubleshooting Tips
Problem Possible Causes Dust is emitted from The unit may accumulate dust during extended periods of non-use, which either the indoor or will be emitted when the unit is turned on. This can be mitigated by covering outdoor unit the unit during long periods of inactivity. The unit may absorb odors from the environment (such as furniture, cooking, The unit emits a cigarettes, etc.) which will be emitted during operations. - Page 12 Error Codes The number Timer Error Cause Number of flashes indicator Code per second Indoor EEPROM (Electrically Erasable Programmable Read-Only Memory) error Indoor and outdoor unit communication malfunction Indoor fan speed malfunction Indoor room temperature sensor error Evaporator coil temperature sensor error Refrigerant leak detection system malfunction Water level alarm malfunction Dual indoor unit (twin model only) communication...
- Page 13 www.cooperandhunter.us LIMITED WARRANTY STATEMENT MULTI ZONE INVERTER AIR CONDITIONING SYSTEM WITH HEAT PUMP This warranty should be registered on our web-site www.cooperandhunter.us The warranty is only valid when installed by a Licensed HVAC Technician FOR WARRANTY SERVICE OR REPAIR: Contact your installing contractor. You may find the installer’s name on the equipment or in your Owner’s packet. Complete product registration below and send back by e-mail at warranty@cooperandhunter.us PRODUCT REGISTRATION: Model No.: ______________________________________________________________________________________________...
- Page 14 LIMITATIONS OF WARRANTIES: ALL IMPLIED WARRANTIES AND/OR CONDITIONS (INCLUDING IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR USE OR PURPOSE) ARE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY. SOME STATES OR PROVINCES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY OR CONDITION LASTS, SO THE ABOVE MAY NOT APPLY TO YOU.
