Summary of Contents for ALLEN & HEATH avantis solo
- Page 1 Getting Started Guide Avantis Solo Before starting please check www.allen-heath.com for the latest Avantis firmware and documentation.
-
Page 2: Conditions Of Warranty
Check with your Allen & Heath distributor or agent for any additional warranty information which may apply. If further assistance is required please contact Allen & Heath Ltd. AP13258 Issue 1 Avantis Solo Getting Started Guide AP13258 Issue 1... -
Page 3: Important - Read Before Starting
To prevent damage to the controls and cosmetics, avoid placing heavy objects on the mixer, scratching the mixer or touchscreen with sharp objects, or rough handling and vibration. Register your product Register your product online at www.allen-heath.com/register. Avantis Solo Getting Started Guide AP13258 Issue 1... -
Page 4: Table Of Contents
Packed items Check you have received the following: • Avantis Solo Digital Mixing Console • Getting Started Guide AP13258 • Safety Sheet • IEC mains lead Contents IMPORTANT - Read before starting ....................... 3 Safety instructions ............................ 3 System operating firmware ........................3 Software licence agreement ........................ -
Page 5: Introduction
1. Introduction Avantis Solo is a 64 channel 96kHz digital mixing console providing a powerful solution for any live sound application. Pristine audio quality is delivered at ultra-low latency, and comprehensive signal routing and processing options are easily accessible via the 15.6” Full HD touchscreen. -
Page 6: Connect And Power Up
If the system is not powered down correctly there is a possibility recent changes may be lost. If the system was not powered down as described above, then a “Not Shut Down Correctly” screen appears the next time the system is turned on. Avantis Solo Getting Started Guide AP13258 Issue 1... -
Page 7: Dpack Activation
If you did not purchase your Avantis with the dPack upgrade, but wish to purchase dPack for your mixer, please visit shop.allen-heath.com If you experience any difficulties, please contact Allen & Heath Shop Support by emailing shopsupport@allen-heath.com Avantis Solo Getting Started Guide AP13258 Issue 1... -
Page 8: Rear Panel
6x line level, balanced XLR outputs. Nominal level +4dBu. The outputs are relay protected to prevent power on or off thumps. Signals can be patched to any output socket using the I/O screen. Avantis Solo Getting Started Guide AP13258 Issue 1... - Page 9 Heed the safety warnings printed on the panel. 12. USB 2.0 Socket Insert a compatible USB device to store and recall show files, update the firmware or to perform USB playback and recording. Avantis Solo Getting Started Guide AP13258 Issue 1...
-
Page 10: Front Panel
Insert a compatible USB device to store and recall show files, update the firmware or to perform USB playback and recording. 2. Headphone Sockets Standard 6.35mm (1/4“) and 3.5mm (1/8”) headphone jack sockets are located under the armrest. Avantis Solo Getting Started Guide AP13258 Issue 1... -
Page 11: Top Panel
Reset - Hold down Reset and press a Name Block, Mix key or a highlighted area of the touchscreen to reset the related parameters to factory default. Hold down Reset and nudge a fader up or down to quickly set it to 0dB or off. Avantis Solo Getting Started Guide AP13258 Issue 1... -
Page 12: Fader Strip
PAFL – Sends the channel signal PFL (pre-fade listen) or AFL (after-fade listen) to the headphones and monitoring system. Preferences for the PAFL system are set using the Setup / Audio / PAFL screen. Avantis Solo Getting Started Guide AP13258 Issue 1... -
Page 13: Screen
6.2 Screen Avantis Solo has one screen, showing channel processing, bank overview, system setup & status, memory management menus and more. The touchscreen integrates with a trio of user-configurable soft rotaries in addition to a Touch & Turn rotary control for quick and easy parameter modification. -
Page 14: Mix Basics
Press a Main Mix (e.g. LR) strip Mix key. This is the default mixing mode: The Input channel strips present the channel faders. The Mix channel strips present the mix bus level faders. Channel Levels to LR Mix Avantis Solo Getting Started Guide AP13258 Issue 1... -
Page 15: Working With Sends - Mix Mode
Mute Mute Mute Mute Mute Mute Mute Mute Mute from the Input channel. PAFL PAFL PAFL PAFL PAFL PAFL PAFL PAFL PAFL PAFL PAFL PAFL To LR Send Level from IP 1 Avantis Solo Getting Started Guide AP13258 Issue 1... -
Page 16: Assigning And Un-Assigning A Channel To A Mix, Group Or Dca
PAFL In Sends on Rotaries mode, Strip Rotaries are used to control send levels to the active mix, with the channel faders remaining as level controls to the Main Mix. To LR Avantis Solo Getting Started Guide AP13258 Issue 1... -
Page 17: Setting Pre/Post Fader Send Status
Current Pre/Post status is displayed on the lower part of the Name Block. You can quickly set all assignments pre or post fader by touching the Mix channel Name Block while holding Pre. Avantis Solo Getting Started Guide AP13258 Issue 1... -
Page 18: Dimensions
8. Dimensions All dimensions shown in mm. Avantis Solo Getting Started Guide AP13258 Issue 1... -
Page 19: Flightcase Information
Leave adequate space for (1) ventilation ( ) and (2) USB / headphone connections at front of mixer. Leave adequate space for (1) ventilation ( ) and (2) audio / power connections at rear of mixer. Avantis Solo Getting Started Guide AP13258 Issue 1... -
Page 20: Expanders, I/O Cards And Controllers
4 in, 6 out, AES3 audio interface AES 10o 0x10 96/88/48/44.1kHz 0 in, 10 out, AES3 audio interface AES 6i4o 96/88/48/44.1kHz 6 in, 4 out, AES3 audio interface AES 2i8o 96/88/48/44.1kHz 2 in, 8 out, AES3 audio interface Avantis Solo Getting Started Guide AP13258 Issue 1... -
Page 21: Remote Controllers
GPIO General purpose I/O interface for remote control 10.4 Personal Monitor Mixing ME-500 16 Channel Personal Mixer ME-1 40 Source Personal Mixer ME-U Personal Monitor Mixer Hub Visit allen-heath.com/me/ for more information. Avantis Solo Getting Started Guide AP13258 Issue 1... -
Page 22: Technical Specifications
546 x 627 x 269 mm Width x Depth x Height 830 x 730 x 425 mm 21.5" x 24.7" x 10.6" 32.6" x 28.7" x 16.7" Weight 17.5kg Weight 24.3kg 38.6lbs 53.6lbs Avantis Solo Getting Started Guide AP13258 Issue 1... - Page 23 ALLEN&HEATH Avantis Getting Started Guide Copyright © 2023 Allen & Heath. All rights reserved. Allen & Heath Limited, Kernick Industrial Estate, Penryn, Cornwall, TR10 9LU, UK www.allen-heath.com Avantis Solo Getting Started Guide AP13258 Issue 1...
