2507009WC
Futon with Cupholder and USB
Date of Purchase: _____ / _____ / ______
Lot Number:
Weight Limit:
600 lbs / 272 kgs
Do Not Return This Product!
Contact our customer service team for help first.
DOREL HOME FURNISHINGS
Visit: www.dorelhome.com/help/dhp
WARNING
This unit is intended for use only with the
products and/or maximum weights indicated. Use
with other products and/or products heavier than
the maximum weights indicated may result in
instability or cause possible injury.
B342507009W00LH
COLOR: (Black Faux Leather)
Scan for Product Information &
Assembly Instruction
Easy
Assembly Difficulty Meter
People Needed for Assembly: 2
dorelhome.com/help/dhp
Tough
Advertisement
Related Manuals for Mainstays 2507009WC
Summary of Contents for Mainstays 2507009WC
- Page 1 2507009WC Futon with Cupholder and USB B342507009W00LH Date of Purchase: _____ / _____ / ______ Lot Number: COLOR: (Black Faux Leather) Weight Limit: Scan for Product Information & Assembly Instruction 600 lbs / 272 kgs Do Not Return This Product! Contact our customer service team for help first.
-
Page 2: Limited 1-Year Warranty
Limited 1 year Warranty DHP warrants this product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers one year from the date of original purchase from authorized retailers. This is solely limited to the repair or replacement of defective parts and assembly labor is not included. This warranty does not apply to any product which has been improperly assembled, subjected to misuse or abuse or which has been altered or repaired in any way. - Page 3 www.dorelhome.com...
-
Page 4: Parts Identification
Parts Identification For any replacement part, see page 7. www.dorelhome.com... - Page 5 Parts Identification SEAT TEA TABLE X 4 PCS X 1 PC X 1 PC ADAPTER (L2500mm) MIDDLE LEG X 1PC X 2PCS For any replacement part, see page 7. www.dorelhome.com...
-
Page 6: Hardware List
Hardware list (x6) (x8) Bolt Bolt 1/4"X 1 1/8" M6 X 10mm (x1) M4 x 75mm Alle n key Hardware Pack HP#: T2241009W-00 2507009WC (Black Faux Leather) www.dorelhome.com... - Page 7 Parts Number Reference Each part has a unique part number. Please reference the appropriate part number when contacting customer service for replacement parts. Before throwing any packaging, please verify all contents and make sure you have received all the parts listed above!. www.dorelhome.com...
- Page 8 STEP 1 Step 1 Unzip the bottom of Seat take out Tea Table as shown. Open the box to take out the Leg , Middle Leg , and Adapter as shown. X 4PCS X 2PCS X 1PC Legs , Hardware and Adapter in the Box Tea Table B will be found in the compartment under the seat A as shown.
- Page 9 STEP 2 Step 2 Please remove the protective cap on the tip of thread before assembling. Manually screw legs to seat as shown. www.dorelhome.com...
- Page 10 STEP 3 Step 3 Attach Middle Legs x 2 to Seat with bolts 2 , as shown. www.dorelhome.com...
- Page 11 STEP 4 Step 4 4 .1 Lift the sofa and turn it over. 4 .2 Lift the sofa backrest, as show n . 4 .1 4 .2 www.dorelhome.com...
- Page 12 STEP 5 Step 5 5.1 The plug on the Tea Table goes through the gap between the seats. 5.2 Put down the Tea Table and slide Tea Table onto seat 5.3 Open the zipper panel on the back of Tea Table and align with the holes on Seat 5 .1...
- Page 13 STEP 6 Step 6 6.1 Attach Tea Table to seat with , as shown. 6.2 Close the zipper panel on the back of Tea Table 6 . 1 6 .2 www.dorelhome.com...
- Page 14 STEP 7 Step 7 Attach Adapter to Tea Table as shown. www.dorelhome.com...
-
Page 15: Maximum Loads
Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. Weight Limit: 600 lbs/ 272 kgs www.dorelhome.com... - Page 16 Register your product to receive the following: * New trend details - sneak peek on what's new * Surveys - have a voice within our community www.dhpfurniture.com * Quick and easy replacement part service www.dorelhome.com Visit Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You"...
- Page 17 Espanol Cubierta Delantera Este libro de instrucciones contiene informacion IMPORTANTE de seguridad. Por favor lea y mantengalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Visitar: www.dorelhome.com/help/dhp PRECAUCION Esta unidad esta disenada para usarse Cmicamente con los productos y/o pesos maximos indicados.
- Page 18 Espanol ADVERTENCIA " ----------- ----------- www.dorelhome.com...
- Page 19 Espanol ldentificaci6n de piezas (Pagina 4-7) - Cada pieza tiene un numero de pieza unico. Consulte el numero de pieza correspondiente cuando se ponga en contacto con el servicio de atenci6n al cliente para obtener piezas de repuesto. - Antes de tirar cualquier embalaje, verifique todo el contenido y asegurese de haber recibido todas las piezas enumeradas anteriormente.
- Page 20 Espanol Pagina 15 Esta unidad ha sido diseiiada para soportar las cargas maximas que se muestran. Exceder estos limites de carga podrfa causar hundimiento, inestabilidad, colapso del producto y/o lesiones graves. Lfmite de peso: 600 lbs/ 272 kg Certificado de conformidad 1.
- Page 21 Fran�ais Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SECURITE. VEUILLEZ LIRE ET GARDER POUR UNE REFERENCE FUTURE Ne retournez pas ce produit! Contactez notre equipe de service la clientele amicale d'abord pour obtenir de l'aide. Visitez: www.dorelhome.com ATTENTION Cet appareil est destine etre utilise uniquement avec les produits et/ou les poids maximum indiques.
- Page 22 Fran�ais AVERTISSEMENT L'unite d'alimentation est conc;ue pour etre orientee correctement, soit via un montage vertical ou sur le sol. Ne pas utiliser ce meuble s'il est endommage ou brise. Gardez le meuble loin des sources de chaleur pour eviler le glac;age, la fusion ou la brOlure des composants. Lire toutes les instructions avant d'utiliser ce meuble.
- Page 23 Fran�ais Identification des materiaux (Page 4-7) - Chaque piece possede un numero de piece unique. Veuillez vous referer au numero de piece correspondant lorsque vous contactez le service client pour les pieces de rechange. - Avant de jeter un emballage, verifiez tout son contenu et assurez-vous d'avoir re9u toutes les pieces listees ci-dessus.
- Page 24 Fran�ais Page 15 Cette unite a ete congue pour resister aux charges maximales indiquees. Le depassement de ces limites de charge pourrait provoquer un affaissement, une instabilite, un effondrement du produit et/ou des blessures graves. Limite de poids : 600 lb/ 272 kg Certificat de conformite 1.
