2609459WE
Mainstays Slipper Accent Chair
Date of Purchase: _____ / _____ / ______
Lot Number:
TAKEN FROM CARTON
Weight Limit:
250lbs / 113kgs
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-267-1739 (toll free)
Visit: www.dhpfurniture.com
WARNING
This unit is intended for use only with the
products and/or maximum weights indicated.
Use with other products and/or products
heavier than the maximum weights indicated
may result in instability or cause possible injury.
B34260945900TPL
COLOR: (
Easy
Assembly Difficulty Meter
People Needed for Assembly: 1
Charcoal Gray Boucle)
Tough
Advertisement
Table of Contents
Related Manuals for Mainstays 2609459WE
Summary of Contents for Mainstays 2609459WE
- Page 1 2609459WE Mainstays Slipper Accent Chair B34260945900TPL Date of Purchase: _____ / _____ / ______ Lot Number: TAKEN FROM CARTON COLOR: ( Charcoal Gray Boucle) Weight Limit: 250lbs / 113kgs Do Not Return This Product! Contact our customer service team for help first.
-
Page 2: Limited 1-Year Warranty
Limited 1 year Warranty DHP warrants this product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers one year from the date of original purchase from authorized retailers. This is solely limited to the repair or replacement of defective parts and assembly labor is not included. This warranty does not apply to any product which has been improperly assembled, subjected to misuse or abuse or which has been altered or repaired in any way. -
Page 3: Parts Identification
Parts Identification For any replacement part, see page 6. www.dhpfurniture.com... - Page 4 Parts Identification RIGHT FRONT LEG SEAT BACK X 1 PC X 1 PC X 1 PC BACK LEFT LEG LEFT FRONT LEG RIGHT BACK LEG X 1PC X 1PC X 1PC For any replacement part, see page 6. www.dhpfurniture.com...
-
Page 5: Hardware List
5/16" x 40mm 1/4" x 45mm (x4) (x12) Bolt 5/16 '' 1/4" x 55mm Spring washer (x12) (x1) 5/16 '' M4 x 75mm Alle n key Flat washer For any replacement Hardware Pack hardware, order part# 2609459WE (Charcoal Gray) 22609459WE0TPL 22609459WE0TPL www.dhpfurniture.com... - Page 6 Each part has a unique part number. Please reference the appropriate part number when contacting customer service for replacement parts. Before throwing any packaging, please verify all contents and make sure you have received all the parts listed above!. 2609459WE PART NAME QUANTITY LABEL...
- Page 7 STEP 1 Step 1 Open the bottom hook and loop material B and take out the Back B , Front Leg ( C & D ), and Back Leg ( E & F ). www.dhpfurniture.com...
- Page 8 STEP 2 Step 2 Attach the Front Leg ( & ) to the Seat using Bolt , Spring Washer , and Flat Washer with the Allen Key as shown. www.dhpfurniture.com...
- Page 9 STEP 3 Step 3 Note: Legs are uniquely curved. The curve should be alligned towards the back. Attach the Back Leg ( ) to & the Seat using Bolt , Spring Washer and Flat Washer with the Allen Key as shown. www.dhpfurniture.com...
- Page 10 STEP 4 Step 4 Attach the Back to the Seat using Bolt , Spring Washer and Flat Washer with the Allen as shown. www.dhpfurniture.com...
- Page 11 STEP 5 Step 5 Close the bottom hook and loop material B www.dhpfurniture.com...
-
Page 12: Maximum Loads
Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. Weight Limit: 250 lbs/ 113 kgs www.dhpfurniture.com... - Page 13 Register your product to receive the following: * New trend details - sneak peek on what's new * Surveys - have a voice within our community www.dhpfurniture.com * Quick and easy replacement part service www.dhpfurniture.com Visit Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You"...
- Page 14 Espanol Cubierta Delantera Este libro de instrucciones contiene informacion IMPORTANTE de seguridad. Por favor lea y mantengalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-267-1739 (llamada gratuita) Visitar: www.dhpfurniture.com PRECAUCION Esta unidad esta disenada para usarse Cmicamente con los productos y/o pesos maximos indicados.
- Page 15 Espanol ldentificaci6n de piezas (Pagina 3-6) - Cada pieza tiene un numero de pieza unico. Consulte el numero de pieza correspondiente cuando se ponga en contacto con el servicio de atenci6n al cliente para obtener piezas de repuesto. - Antes de tirar cualquier embalaje, verifique todo el contenido y asegurese de haber recibido todas las piezas enumeradas anteriormente.
- Page 16 Espanol Pagina 12 Esta unidad ha sido diseiiada para soportar las cargas maximas que se muestran. Exceder estos limites de carga podrfa causar hundimiento, inestabilidad, colapso del producto y/o lesiones graves. Lfmite de peso: 250 lbs/ 113 kg Certificado de conformidad 1.
- Page 17 Fran�ais Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SECURITE. VEUILLEZ LIRE ET GARDER POUR UNE REFERENCE FUTURE Ne retournez pas ce produit! Contactez notre equipe de service la clientele amicale d'abord pour obtenir de l'aide. Appel ez-nous: 1-800-267-1739 (sans frais)- Visitez: www.dhpfurniture.com ATTENTION Cet appareil est destine etre utilise uniquement avec les produits et/ou les poids maximum indiques.
- Page 18 Fran�ais Identification des materiaux (Page 3-6) - Chaque piece possede un numero de piece unique. Veuillez vous referer au numero de piece correspondant lorsque vous contactez le service client pour les pieces de rechange. - Avant de jeter un emballage, verifiez tout son contenu et assurez-vous d'avoir re9u toutes les pieces listees ci-dessus.
- Page 19 Fran�ais Page 12 Cette unite a ete congue pour resister aux charges maximales indiquees. Le depassement de ces limites de charge pourrait provoquer un affaissement, une instabilite, un effondrement du produit et/ou des blessures graves. Limite de poids : 250 lb/ 113 kg Certificat de conformite 1.
