Metal Rainbow Bed/ Daybed
Thank you for purchasing from DHP!
DO NOT RETURN TO THE STORE !
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/support-home
or Call Toll-Free 1-800-267-1739
Date of Purchase
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
4059019WE
Lot Number
B344059019WE00-10125-M
Twin
Black
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Mainstays 4059019WE
Summary of Contents for Mainstays 4059019WE
- Page 1 4059019WE Metal Rainbow Bed/ Daybed Twin Black Thank you for purchasing from DHP! DO NOT RETURN TO THE STORE ! If parts are missing or damaged, we will gladly ship your replacement parts free of charge. Visit www.dhpfurniture.com/eng/support-home or Call Toll-Free 1-800-267-1739...
- Page 2 Warranty Information Read Before Beginning Assembly DHP warrants this product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers one year from the date of original purchase. This is solely limited to the repair or replacement of defective 2 (however it is always better parts and assembly labor is not included.
- Page 3 B34 4059019WE00...
- Page 4 Parts Replacement Parts, Visit www.dhpfurniture.com/eng/support-home All in 1 big box! There are inner box(es) that include components required to complete this assembly. Before you throw the package, please use the Post Head And Foot Board Side Rail 01 Side Rail 02 Check Box to identify the parts and ensure that T931060 T931070...
- Page 5 Hardware Pack Hardware Pack #: T4059019WE-00 1/4" X 3/4" 5/16"X 3/4" X 12 1/4" X 1 3/8" Hardware Note: Please do not completely tighten all the hardware, until the entire assembly is complete, unless otherwise indicated in the step-by-step instructions. B34 4059019WE00...
- Page 6 Step 1 Insert POSTS (A X 4) into (D X 2) and secure with BOLTS 2. B34 4059019WE00...
- Page 7 Step 2 Insert (F) into (E) and secure with BOLTS B34 4059019WE00...
- Page 8 Step 3 Wide side of the slot should be facing up ! Attach sub-assembly (E,F) from STEP TWO to HEADBOARD/FOOTBOARD (D) with BOLTS 1. Open slot should be facing up ! B34 4059019WE00...
- Page 9 Step 4 4.1 Attach LEGS (M X 2) to (G) with BOLTS 2; 4.2 Attach (G) to the SIDE RAILS (E) with BOLTS 3 and NUTS 4. B34 4059019WE00...
- Page 10 Step 5 Step 5 5.1 Insert (O) into the slots in (E) & (F) as illustrated. 5.2 Lock (O) into place with (Y). B34 4059019WE00 B34 4059019WE00...
- Page 11 Helpful Hints Helpful Hints Weight Limit: 400 Lb / 181 Kg lifting and carrying the unit to its new location. reassembled to move. with a clean, dry cloth. They are illustrated on this page and available for replacement. WARNINGS: For safety reasons and to prevent injuries: ●...
- Page 12 NO LO REGRESE A LA TIENDA ! 4059019WE mucho gusto le enviaremos sus piezas de reemplazo sin cargo extra. Twin Visite www.dhpfurniture.com/spa/support-home o llame gratis al 1-800-267-1739 Negro ESTE INSTRUCTIVO CONTIENE INFORMACION IMPORTANTE DE Fecha de compra SEGURIDAD. POR FAVOR LEA Y GUARDE PARA SU REFERENCIA FUTURA.
- Page 13 (E) Barandilla lateral 02:T931090 (G) Armazón central:T931100 (O) Tubos:T919600 (M) Patas:T931110 (Y) Cubiertas De Plástico:T932590 Paquete de componentes Paquete de componentes #: T-4059019WE-00 Nota: Por favor no apriete completamente las piezas hasta que el las indicaciones paso a paso. B34 4059019WE00...
- Page 14 Instrucciones 400 Lb / 181 Kg Paso 1 Inserte los POSTES (A X 4) dentro de (D X 2) y asegure las partes usando los TORNILLOS 2. Paso 2 Inserte (F) dentro de (E) y asegure las partes usando los TORNILLOS 2. Paso 3 mudanza.
