Questions, problems, or missing parts?
Before returning to your retailer, call our customer service at 1-855-508-3883.
Monday – Friday, 9:00 A.M. – 5:00 P.M. CST.
PACKAGE CONTENTS
HARDWARE CONTENTS:
A
Wire Nut
C
x3
WARNINGS
WARNING: This product may present a possible shock or fire
hazard if improperly installed or mounted. The product should be
installed following these instructions, local electrical codes and/or the
current National Electric Code (NEC).
WARNING: TO AVOID ELECTRIC SHOCK,
DISCONNECT POWER BEFORE INSTALLING.
WARNING: This product needs to be grounded properly in a
manner consistent with local electrical codes and/or the current
National Electric Code (NEC). If the installer cannot determine if this
product is properly grounded, has no ground wire, or is unfamiliar with
electrical wiring methods of properlygrounding a fixture, consult a
qualified electrician.
WARNING: Do NOT alter or disassemble the fixture. It is factory
sealed and does not contain serviceable parts.
Mounting Arm Crossbar
x1
5000 Lumen D2D Area Light
Model Number: Z-XY-BL50-CCT
HARDWARE SHOWN NOT OF ACTUAL SIZE.
B
CAUTION:
In the event that the fixture is pulled from its
mount, personal injury, damage to the fixture and/or mount
may occur. To prevent premature failure from overheating, the
fixture should only be installed in environments where the
operating temperatures are between -40° to 122°F (-40° to 50° C).
Do not install in a fully enclosed (non-ventilated) area.
WARNING: To prevent wire damage, do not expose the
wiring to sharp edges and/or objects.
WARNING: To be used only in 110-240v, 60Hz circuits.
WARNING: Do NOT look directly at the LED source.
WARNING: Do NOT mount at ground-level.
SKU Number: 356-9473
CCT Changeable
Large Mounting Screw
x3
