Questions, problems, or missing parts?
Before returning to your retailer, call our customer service at 1-855-508-3883, or
email us at: service@zoneledlighting.com Monday –Friday 9:00 A.M. – 5:00 P.M. CST
PACKAGE CONTENTS
HARDWARE CONTENTS:
Small Screw
A
x2
WARNINGS
WARNING: This product may represent a potential shock or fire
hazard if improperly installed or mounted. The product should be
installed following these instructions, local electrical codes and/or the
current National Electric Code (NEC).
WARNING: TO AVOID ELECTRIC SHOCK,
DISCONNECT POWER BEFORE INSTALLING.
WARNING: This product needs to be grounded properly in a manner
consistent with local electrical codes and/or the current National
Electric Code (NEC). If the installer cannot determine if the downlight
being retrofitted with this product is properly grounded, has no ground
wire, or is unfamiliar with electrical wiring methods of properly grounding
fixtures, consult a qualified electrician.
Large Screw
B
x2
1
SKU Number: 356-9463
1000 Lumen Solar Motion
Model Number: Z-JW1000-B-ISM
HARDWARE SHOWN-NOT ACTUAL SIZE
C
WARNING: Do NOT mount on ground-level.
WARNING: Do NOT look directly at LED source.
WARNING:
DO
NOT
alter or disassemble the fixture,
factory sealed and non-serviceable.
This fixture is IP54 rated; therefore, it is suitable for dry,
damp, and wet environments both indoors and outdoors.
356-9464
Wall Light
Z-JW1000-W-ISM
Screw Anchor
x2
Rev2_10302024
Advertisement
Related Manuals for Patriot Lighting Z-JW1000-B-ISM
Summary of Contents for Patriot Lighting Z-JW1000-B-ISM
- Page 1 SKU Number: 356-9463 356-9464 1000 Lumen Solar Motion Wall Light Model Number: Z-JW1000-B-ISM Z-JW1000-W-ISM Questions, problems, or missing parts? Before returning to your retailer, call our customer service at 1-855-508-3883, or email us at: service@zoneledlighting.com Monday –Friday 9:00 A.M. – 5:00 P.M. CST...
