MT9V114EBKSTC5H-GEVB
MT9V114 Evaluation Board
User's Manual
Evaluation Board Overview
The evaluation boards are designed to demonstrate the features of
ON Semiconductor's image sensors products. This headboard is
intended to plug directly into the Demo 2X system. Test points and
jumpers on the board provide access to clock, I/Os and other
miscellaneous signals.
Features
Clock Input
Default − 27 MHz crystal oscillator
Optional Demo 2X controlled MClk
Two Wire Serial Interface
Selectable base address
Parallel Interface
ROHS Compliant
Block Diagram
© Semiconductor Components Industries, LLC, 2016
July, 2016 − Rev. 0
Figure 2. Block Diagram of MT9V114EBKSTC5H−GEVB
EVAL BOARD USER'S MANUAL
Figure 1. MT9V114 Evaluation Board
1
www.onsemi.com
Publication Order Number:
EVBUM2464/D

Advertisement

loading
Need help?

Need help?

Do you have a question about the MT9V114EBKSTC5H-GEVB and is the answer not in the manual?

Questions and answers

Summary of Contents for ON Semiconductor MT9V114EBKSTC5H-GEVB

  • Page 1 Evaluation Board Overview The evaluation boards are designed to demonstrate the features of www.onsemi.com ON Semiconductor’s image sensors products. This headboard is intended to plug directly into the Demo 2X system. Test points and EVAL BOARD USER’S MANUAL jumpers on the board provide access to clock, I/Os and other miscellaneous signals.
  • Page 2 MT9V114EBKSTC5H−GEVB Top View +VDDIO P4 +2V8_VAA P6 +1V8_VDD P5 STANDBY SW2 +VPP P1 CLK_SELECT SW9 EXTCLK_SELECT SW8 CLK_IN P10 EEPROM ADDR SW6 Figure 3. Top View of Evaluation Board − Default Jumpers Bottom View Baseboard Connector J3 ON_LED SW7 Figure 4. Bottom View of the Evaluation Board − Connector www.onsemi.com...
  • Page 3 MT9V114EBKSTC5H−GEVB Jumper Pin Locations The jumpers on headboards start with Pin 1 on the leftmost side of the pin. Grouped jumpers increase in pin size with each jumper added. Pin 1 Pins 1−4 Figure 5. Pin Locations for a Single Jumper. Pin 1 is Located at the Leftmost Side and Increases as it Moves to the Right ADR0 ADR1...
  • Page 4 Off (Default) Connects to on-board oscillator Connects to output of SW8 Interfacing to ON Semiconductor Demo 2X Baseboard The ON Semiconductor Demo 2X baseboard has headboard. The four mounting holes secure the baseboard a similar 26-pin connector which mates with J3 of the and the headboard with spacers and screws.
  • Page 5: Technical Support

    LIMITATIONS OF LIABILITY: ON Semiconductor shall not be liable for any special, consequential, incidental, indirect or punitive damages, including, but not limited to the costs of requalification, delay, loss of profits or goodwill, arising out of or in connection with the board, even if ON Semiconductor is advised of the possibility of such damages. In no event shall ON Semiconductor’s aggregate liability from any obligation arising out of or in connection with the board, under any theory of liability, exceed the purchase price paid for the board, if any.
