- Page 1 N-Peak Series InstallatIon InstructIons for all rEc n-PEak solar PanEls cErtIfIEd accordIng to ul 1703...
-
Page 2: Table Of Contents
Clamping zones for panels with rails parallel to long side Fig. 11: Minimum cable bend radius Fig. 6: Mounting holes: REC N-Peak Fig. 12: Panel dimensions: REC N-Peak Series REC Installation Manual - N-Peak - UL 1703 Rev A.2 - 11.18 Ref: NE-06-22... -
Page 3: Introduction
This does not apply to damages due to a panel fault, in cases of loss of life, bodily injury or damage to health or in the event of a grossly negligent breach of obligations on the part of REC SOLaR PTE. LTD. and/or in the event of an intentional or grossly negligent breach of obligations by a legal representative or vicarious agent. -
Page 4: Safety Measures
PanEl HandlIng In order to avoid damage to the solar cells and other components, all REC solar panels should be handled with care and protected from damage at all times. all warnings and instructions on the packaging should be observed. Follow these guidelines when unpacking, transporting, carrying, installing or storing panels: •... -
Page 5: Electrical Installation
REC N-Peak panels have a Type 2 fire rating according to UL1703. The fire performance rating of the panels is only valid when mounted in the manner specified in this installation manual. The complete system fire class rating is to be achieved by the combination of panel fire performance type and UL2703 certified mounting structure for a non-BIPV panel. -
Page 6: Panel Installation
PaNEL INSTaLLaTION REC solar panels are designed for capturing solar radiation and are not suitable for use as overhead or vertical glazing. The IP rating of the junction box provides a level of protection that allows panels to be mounted in any orientation (see product technical specifications for exact rating). The panels are considered to be in compliance with UL 1703, only when the panel is mounted according to the mounting instructions specified below: Panels must be installed so that the cells are not shaded as this will drastically reduce electrical output. -
Page 7: Mounting Methods: Clamping With Rails Parallel To The Short Side
MountIng MEtHods: claMPIng WItH raIls ParallEl to tHE sHort sIdE REC N-Peak solar panels secured by clamping to mounting rails has been found to comply with UL 1703 requirements for downward pressure,e.g., snow, of up to 146 psf (7000 Pa or 4666 Pa design load*) and upward pressure,e.g., wind, of up to 50 psf (2400 Pa or 1600 Pa design load*) according to the instructions below (*design loads apply a safety factor of 1.5 to the stated test load, e.g., test load 7000 Pa / 1.5 = 4666 Pa design load). -
Page 8: Mounting Methods: Clamping With Rails Parallel To The Long Side
MountIng MEtHods: claMPIng WItH raIls ParallEl to tHE long sIdE REC N-Peak solar panels secured by clamping to mounting rails has been found to comply with UL 1703 requirements for downward pressure,e.g., snow, of up to 112 psf (5400 Pa or 3600 Pa design load*) and upward pressure,e.g., wind, of up to 50 psf (2400 Pa or1600 Pa design load*) according to the instructions below (*design loads apply a safety factor of 1.5 to the stated test load, e.g., test load 5400 Pa / 1.5 = 3600 Pa design load). -
Page 9: Mounting Methods: Slide In Systems
MountIng MEtHods: MountIng HolEs REC N-Peak panels can be mounted utilizing the four 0,4 x 0,25 in (11 x 6.6 mm) elongated holes on the underside of the panel at a distance of 15 in (382.5 mm) from the corner (fig. 6) in conjunction with a device, e.g., screws, lockbolts or structural blind fasteners, with specifications suitable for the installation (fig. -
Page 10: Drainage Holes
HolEs Each corner of the REC panel frame has small drainage holes spaced 2.2 in (55 mm) from the corner of the panel frame that allow water caused by rain, condensation, snow melt, cleaning or any other process to exit the frame easily and minimize damage caused by freezing and thawing (fig. 9). These holes must not be used for mounting the panel, and they must not be covered by any part of the mounting structure. -
Page 11: Connections And Connectors
CONNECTIONS aND CONNECTORS The connectors used on REC solar panels are specified in the panel characteristics at the rear of this manual. The connector IP rating is only valid when the they are correctly connected. all connectors and cables must be secure and tight as well as electrically and mechanically sound. UV-resistant cables and connectors approved for outdoor use must be used. -
Page 12: Maintenance
ElEctrIcal and ElEctronIc EquIPMEnt Panels should be recycled at the end of their useful life according to local guidelines and regulations. By ensuring REC solar panels are disposed of correctly, you will help prevent potential negative consequences for the environment and human health which could otherwise be caused by inappropriate waste treatment. -
Page 13: Panel Characteristics
IEC 62804 (PID), IEC 61701 (Salt Mist), IEC 62716 (ammonia), ISO 9001: 2015, ISO 14001: 2004, OHSaS 18001: 2007 See warranty conditions for further details. 1000 Irradiance (W/m²) REC Installation Manual - N-Peak - UL 1703 Rev A.2 - 11.18 Ref: NE-06-22... -
Page 14: Annex 1: Installations On Water Platforms
InstallatIon EnvIronMEnt Installation site • REC solar panels may only be installed on closed bodies of fresh water where water salinity does not exceed 15 PSU (25 mS/cm) at 77°F (25°C). This specifically excludes mounting on sea and ocean applications. •... -
Page 15: Document History
DOCUMENT HISTORY date revision number reason 07.2018 First release 11.2018 Clearance gap reduced from 4 in to 2.4 in REC Installation Manual - N-Peak - UL 1703 Rev A.2 - 11.18 Ref: NE-06-22... - Page 16 REC SoLAR PtE. Ltd. 20 tUAS SoUth AvENUE 14 SINgAPoRE 637312 SINgAPoRE tel: +65 6495 9228 Mail: post@recgroup.com www.recgroup.com REC Installation Manual - N-Peak - UL 1703 Rev A.2 - 11.18 Ref: NE-06-22...
