First Data FD 150 Terminal Setup Guide

In the Box

The First Data FD 150 terminal comes with all the parts listed below.

LAN Ethernet Cable

Before anything else, connect the FD 150 via ethernet and / or telephone line.

The terminal requires a connection to be able to run transactions and communicate

with the processor.

1. Remove the cover from the bottom of the device.

paystri.com | Paystri Support: 978-744-9090

Table of Contents

Do you have a question about the FD 150 and is the answer not in the manual?

Page 1 The First Data FD 150 terminal comes with all the parts listed below. LAN Ethernet Cable Connect the Terminal Before anything else, connect the FD 150 via ethernet and / or telephone line. The terminal requires a connection to be able to run transactions and communicate with the processor.
Page 2 2. Plug an ethernet cable into the yellow port and / or a phone cable into the blue port. 3. Plug the other end of the ethernet cable into an open port on the router or modem. If using a telephone line, connect the other end of the phone cable into a wall jack preferably not being shared with another device.
Page 3 6. Lift the hatch to open the paper tray. 7. Drop the paper into the printer tray with the leading edge feeding down from the bottom of the roll. 8. With the end of the paper sticking out, close the lid on the paper. 9.
