Summary of Contents for Zumimall G1K
- Page 1 4G LTE Security Camera QUICK START GUIDE...
- Page 2 Brand Story Leading the Way in Affordable, Advanced Home Security. From our inception in 2008, Zumimall has been at the forefront of redefining home security. Our philosophy? Combine top-tier specifications with affordability. Our results? Over a million premium, yet affordable smart security products in homes and businesses worldwide.
-
Page 3: Warranty Service
In addition, Your advice and suggestions are always appreciated. How to Activate the Free 1-year Warranty Extension? Send us the order number and SN number via email. Please email us within 30 days of receiving the camera. Email: Support@zumimall.com Product Service Email: Support@zumimall.com Distributor: Distributor@zumimall.com... -
Page 4: Table Of Contents
CATALOGS PAGE 1. Package List - G1K ------------------------------------------------------ 2. Product Diagram ------------------------------------------------------- 3. Download and Install App ------------------------------------------------ 4. Accounts Registration --------------------------------------------------- 5. How to Reset the Camera ----------------------------------------------- 6. Add Camera to App ---------------------------------------------------- 6.1 About the SIM Card --------------------------------------------------- 6.2 Adding Methods --------- -------------------------------------------... - Page 5 CATALOGS PAGE 9. Device Menu ---------------------------------------------------------- 10. PIR Motion Detection --------------------------------------------------- 10.1 Motion Detection Alarm Setting ----------------------------------------- 10.2 Alarm Notification --------------------------------------------------- 10.3 Record/Playback/Delete --------------------------------------------- 11. Storage Instructions ---------------------------------------------------- 12. Power Saving Settings -------------------------------------------------- 12.1 Alarm Interval ------------------------------------------------------- 12.2 Recording Time ----------------------------------------------------- 12.3 Alarm Plan --------------------------------------------------------- 12.4 Battery Management ------------------------------------------------ 13.
-
Page 6: Package List - G1K
1. Package List - G1K Camera Camera Charging Product Bracket Cable Manual Solar Panel Screw Bag Solar Panel Bracket NOTE: Micro SD card and power adapter are not included. -
Page 7: Product Diagram
2. Product Diagram Antenna Charging Port Working LED PlR Sensor Spotlight Charging LED Power Key Reset Key Speaker Lens Microphone SD Card Clot Charge Port Use 5V/2A power supply to charge the camera Power Key Press and hold the power button for 5 seconds to turn on the camera Reset Key Press and hold RESET for 5 seconds to reset the device Red means charging is in progress... -
Page 8: Download And Install App
3. Download and Install App Download ZUMIMALL App from Google Play™ or App Store™. Or scan the QR codes below with your smartphone. NOTE: Google Play™ is a trademark of Google Inc. App Store™ is a service mark of Apple Inc. -
Page 9: Accounts Registration
4. Accounts Registration New user needs to sign up ZUMIMALL App with an email address. Click 'Sign up' to create a New Account and follow the steps to complete registration. Step 1 Step 2 Step 3 NOTE: ① Agree to Terms: Review and accept the User Agreement and Privacy Policy before proceeding. -
Page 10: How To Reset The Camera
5. How to Reset the Camera ① Go to the device homepage, select the camera that needs to be reset, and long press it to remove it from the app. ② Press the camera's reset button for 5-10 seconds until you hear the 'Boogu' sound. ③... -
Page 11: Add Camera To App
6. Add Camera to App 6.1 About the SIM Card This camera comes with a built-in 4G SIM card compatible with major operators like Verizon, T-Mobile, and AT&T in your country. It's a dedicated IoT SIM card designed specifically for this camera. Advantages: - No need to apply for or purchase an additional SIM card. -
Page 12: Adding Methods
① Move the camera and smartphone to a location with smooth 4G network and ensure that there is no signal interference around. ② Run the ZUMIMALL application and click on 'Scan Code'. ③ Find the QR code on the camera casing (on the label paper of the camera), Scan this QR code using a mobile phone lens. - Page 13 ④ Observe the indicator light status of the camera. - Flashing blue, select 'Blue Light Flashing' and proceed to step 5. - Flashing red, please continue to wait. - Flashing red and blue, click 'Red and blue lights flashing' to check the reason for the failure.
-
Page 14: Method 2: Manual Add
Method 2: Manual Add Tap 'Add Device' Select Camera Can't Find the QR Code Turn on the Camera Prepare the Scanning Scan QR Code... - Page 15 Installation Complete at 100% Name the Camera View Installation Tips 03-26-2024 10:16:44 AM 23KB/s Perform Network Diagnosis Using the Camera...
-
Page 16: Add Failed
6.3 Add failed? Please refer to the following to resolve the issues: Camera Working Camera status Solutions voice light status If the network is not Indicator Press and hold the power button to Wait for configured for a long light off restart the camera and add it again connection time, the device will... -
Page 17: Camera Installation
7. Camera Installation 7.1 Installation Preparation ① Surface Selection: Choose a clean, smooth, and dry surface for mounting the bracket. Avoid uneven surfaces like wood veneer or plaster walls. ② Bracket Mounting: Use the provided positioning stickers and screws to securely attach the bracket to the wall. -
Page 18: Mounting Position And Angle
7.2 Mounting Position and Angle ① Location: Ensure the camera is unobstructed and within Wi-Fi coverage. ② Mounting: Select an appropriate position on the wall to mount the camera. Indoor Outdoor... - Page 19 ③ Angle for Motion Detection: - Aim the camera to cover the lower two-thirds of the field of view, which is the most sensitive to motion. - For close monitoring (e.g., front door), mount the camera 7-10 feet (2-3 meters) high.
-
Page 20: Best Practices For Motion Detection
7.3 Best Practices for Motion Detection - Motion Path: Position the camera so that motion moves side-to-side across its view rather than directly toward or away from it. - Detection Range: Optimal motion detection occurs within 5 to 20 feet (1.5 to 6 meters) from the camera, though it can detect motion up to 33 feet (10 meters). -
Page 21: Solar Panel Installation
8. Solar Panel Installation 8.1 Installation Steps ① Use Power Drill and two screws to fix the camera bracket on the wall. Align the screw cap of the bracket with the screw hole on the back of the solar panel and rotate it clockwise to fix it. -
Page 22: Installation Angle
8.3 Installation Angle - Ensure the solar panel is angled to receive direct sunlight. - Avoid installing the solar panel completely horizontally to prevent the accumulation of dust and debris. It is advised to install the solar panel at an angle for optimal sunlight exposure. -
Page 23: Device Menu
9. Device Menu 2024-07-22 12:53:01 AM 2024-07-22 12:53:01 AM 2024-07-22 12:53:01 AM 0 3 - 2 6 -2 0 24 12 :5 6:0 8 A M Add Device and Scan Code Two-Way Talk More Functions Record to Phone Real Time Motion Detection On/Off Live View Button Camera Name... -
Page 24: Pir Motion Detection
10. PIR Motion Detection 10.1 Motion Detection Alarm Setting Sensitivity Adjustment: Adjust motion detection sensitivity from 1 to 10. Refer to the image below for settings. 2024-07-22 12:53:01 AM Tap on 'Settings' Select 'Motion Detection' Set it up Sensitivity Detecting Distance 3.3~10ft（1~3m）... - Page 25 You may encounter the following situations: Problems and failures Solutions ① The phone receives frequent alarm messages The phone receives ② Enable the humanoid detection function frequent alarm ③ Set the alarm area messages ④ Avoid the camera facing the roadside or crowded places There are no moving ①...
-
Page 26: Alarm Notification
10.2 Alarm Notification ① Recording Type: This camera does not support continuous 24/7 recording. It activates only when motion is detected. ② System Reactions: - Alarm Notifications: Receive sound alerts via the app. - Storage: Pictures and videos are automatically saved to the micro SD card or cloud storage. -
Page 27: Storage Instructions
11. Storage Instructions ① Manual Storage - Go to the live video feed and manually record by clicking the 'Record' button to start or stop. - Recordings will be stored in your app's album. - Exiting the live view will automatically stop the recording. ②... -
Page 28: Power Saving Settings
12. Power Saving Settings 12.1 Alarm Interval This function helps avoid repeated alarms for the same event. You can set an alarm interval of different lengths. For example, if the interval is set to 5 minutes, and the camera is triggered at 08:00, you will receive an alarm message, but will not receive another alarm notification within the next 5 minutes, even if motion detection continues. -
Page 29: Alarm Plan
12.3 Alarm Plan You can set a weekly or daily alarm schedule as needed. For example, if the camera's working hours are set from 0:00 to 1:00, the camera will only be triggered and record alarm video during this period. NOTE: Up to 4 time periods can be set for the alarm schedule. - Page 30 In low temperature and cold In cold weather, reduce the sensitivity of motion weather, battery performance will detection, turn on the humanoid detection function, be reduced and solar charging set the alarm area, and reduce the working time of efficiency will decrease the camera Inefficient or no charging of ①...
-
Page 31: Multi-Camera Management
- However, a camera can be shared from account A to account B. Sharing Steps: ① B downloads the ZUMIMALL App on their phone and creates a new account.(the country selected during registration must be the same as your choice). - Page 32 You have two ways to share: QR code The person being shared clicks on the On the camera's settings Scan this QR code page, tap Share and enter your account number QR code on the 'My' page Or enter the account number of the Customise the permissions of the View Shared Records Accepting sharing requests...
-
Page 33: Video Management
15. Video Management The camera needs a Micro SD card (not included) to store video files. Insert the Micro SD card into the SD card slot of the camera correctly. 15.1 SD card requirements: ① Recommend the use of brand name cards such as San Disk, Samsung, etc. ②... -
Page 34: How To Find The Sn Number
16. How to Find the SN Number? If you have any other questions, please send us the SN number of your camera and describe the problem you have encountered. We will resolve it as soon as possible. Email: Support@zumimall.com 2024-07-22 12:53:01 AM Click Settings... -
Page 35: Faq
17. FAQ Q1: Can't the camera power on? A1: It is possible that the camera battery has been depleted. Please use a 5V power adapter Fully charge the camera and then turn it on again. Q2: Failed to add camera? A2: Please go back to page 11 to find solutions, or contact the customer service personnel of the brand for help. - Page 36 Q6: Motion detection missed alarm? A6: ① ncrease the motion detection sensitivity of the camera. ② Please install the camera correctly to prevent intruders from walking vertically to the camera. (For the solution, please refer to the text of 'Installing the Camera' in the manual). ③...
- Page 37 FCC ID: 2AZL7-ZY-G1...
