Transmission Pump
Type
Displacement
Control
Charge Pressure (oil temperature at 50° C) variable with
engine speed
High Pressure 'Loop' Valve Pressure
Hydraulic Motors - Wheeled Machines
Type
Displacement
Hydraulic Motors - Tracked Machines
Type
Displacement
Loader Valve Block - Servo Machines
Services Operated:
- Spool 1
- Spool 2
- Spool 3
Loader Valve Block - Manual Machines
Services Operated:
- Spool 1
- Spool 2
- Spool 3
E - 2
Boom Lift - Hydraulic Servo
Quickhitch Tilt - Hydraulic Servo
Auxiliary - Servo operated via proportional solenoid valve
P T
1 2 3
Boom Lift - Manually operated with Solenoid Spool Lock
Quickhitch Tilt - Manually operated with Solenoid Spool Lock
Auxiliary - Servo operated via proportional solenoid valve
P
1 2 3 T
9803-9450-2
Section E - Hydraulics
Tandem axial piston Series 42
39 cc/rev (2.4 in /rev)
3
Servo non-feedback proportional.
17 - 18 bar (246 - 261 lbf/in
25 - 27 bar (362 - 391 lbf/in
385 bar (5585 lbf/in )
2
Geroter
395 cc/rev (24 in /rev)
3
MCR5C Piston
820 cc/rev (50 in 3 /rev)
Technical Data
General Data
) at engine idle
2
) at max. rev/min
2
