AUTODOME IP starlight 5000i | AUTODOME IP

starlight 5000i IR

NDP‑5522‑Z30│NDP‑5522‑Z30C│NDP‑5522‑Z30L

User manual

Table of Contents

Need help?

Do you have a question about the AUTODOME IP starlight 5000i and is the answer not in the manual?

Questions and answers

Summary of Contents for Bosch AUTODOME IP starlight 5000i

Page 1 AUTODOME IP starlight 5000i | AUTODOME IP starlight 5000i IR NDP‑5522‑Z30│NDP‑5522‑Z30C│NDP‑5522‑Z30L User manual...
Page 3: Table Of Contents
AUTODOME IP starlight 5000i | AUTODOME IP Table of contents | en starlight 5000i IR Table of contents Safety About this Manual Legal Information Safety Precautions Important safety instructions Important notices Important Notices - Illumination Safety Connection in Applications Use latest software...
Page 4 AUTODOME IP starlight 5000i | AUTODOME IP en | Table of contents starlight 5000i IR 6.16 Pixel Counter Recording Introduction to recording Storage Management 7.2.1 Device manager 7.2.2 Recording media 7.2.3 Activating and configuring storage media 7.2.4 Formatting storage media 7.2.5...
Page 5: Table Of Contents | En
AUTODOME IP starlight 5000i | AUTODOME IP Table of contents | en starlight 5000i IR 11.1.8 Date and Time 11.1.9 Full-screen video 11.1.10 Saving snapshots 11.1.11 Recording live video 11.1.12 Video Security App 11.1.13 Show latest event 11.1.14 Audio communication 11.1.15...
Page 6: Safety
Legal Information Copyright This manual is the intellectual property of Bosch Security Systems, and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered trademarks and must be treated accordingly.
Page 7: Important Safety Instructions
Video loss - Video loss is inherent to digital video recording; therefore, Bosch Security Systems cannot be held liable for any damage that results from missing video information.
Page 8: Important Notices
AUTODOME IP starlight 5000i | AUTODOME IP en | Safety starlight 5000i IR Important notices UL disclaimer Underwriter Laboratories Inc. ("UL") has not tested the performance or reliability of the security or signaling aspects of this product. UL has only tested fire, shock and/or casualty hazards as outlined in Standard(s) for Safety for Information Technology Equipment, IEC 62368-1.
Page 9: Important Notices - Illumination Safety
AUTODOME IP starlight 5000i | AUTODOME IP Safety | en starlight 5000i IR Important Notices - Illumination Safety The text in this section applies only to cameras that have illuminators. Notice! This product has been tested according to standard IEC62471:2006 “Photobiological safety of lamps and lamp systems”.
Page 10: Use Latest Software
Security advisories, that is a list of identified vulnerabilities and proposed solutions: https://www.boschsecurity.com/xc/en/support/product-security/security- advisories.html Bosch assumes no liability whatsoever for any damage caused by operating its products with outdated software components. Notice! Bosch strongly recommends upgrading to the latest firmware for the best possible functionality, compatibility, performance and security.
Page 11: Introduction
You can also use the Project Assistant app to complete the initial configuration of the camera. In order to use this device with the Project Assistant app by Bosch, you must download the app from the BoschDownloadStore, from Google Play, or from the Apple Store.
Page 12 5000i IR – From www.boschsecurity.com, select Support > Apps and Tools > Online Apps - Video > Bosch Project Assistant app. Select the appropriate operating system, and then click the appropriate button to download and install the app. –...
Page 13: System Overview
Click this icon to configure the device. Dashboard Click this icon to see detailed system information. Links Click this icon to navigate to the Bosch download store. Logout Click this icon to log out of the device. Click this icon to get context-sensitive help for the page you are browsing.
Page 14: Dashboard
AUTODOME IP starlight 5000i | AUTODOME IP en | System overview starlight 5000i IR Some changes only take effect after the unit is rebooted. In this case, the Set button changes to Set and Reboot. Make the desired changes. Click the Set and Reboot button. The camera reboots and the changed settings are activated.
Page 15: General
A check mark in this check box indicates that at least one certificate is loaded onto the camera. If no certificates are loaded, then “No certificate installed” appears to the right of the text. The Escrypt certificate is a root certificate for Bosch Security Systems that proves that the device meets the following criteria: –...
Page 16: Date/Time
AUTODOME IP starlight 5000i | AUTODOME IP en | General starlight 5000i IR You can define and change a password for each authorization level if you are logged into the “service” user account. The device has three authorization levels: service, user, and live.
Page 17 AUTODOME IP starlight 5000i | AUTODOME IP General | en starlight 5000i IR Device time zone Select the time zone in which the system is located. Daylight saving time The internal clock can switch automatically between normal and daylight saving time (DST).
Page 18: Web Interface
AUTODOME IP starlight 5000i | AUTODOME IP en | Web Interface starlight 5000i IR Web Interface Appearance You can adapt the appearance of the web interface and change the website language to meet your requirements. Website language Select the language for the user interface.
Page 19: Live' Functions
AUTODOME IP starlight 5000i | AUTODOME IP Web Interface | en starlight 5000i IR Select this checkbox to receive a notification when a user logs in. Video player Select the type of player to be used for live mode viewing.
Page 20: Camera
AUTODOME IP starlight 5000i | AUTODOME IP en | Camera starlight 5000i IR Camera Installer Menu Sensor mode The sensor mode specifies the base resolution and frame rates for the image quality settings. Fast moving scenes use more frame rates (50 fps or 60 fps) for better image quality than slow moving scenes.
Page 21: Display Stamping
AUTODOME IP starlight 5000i | AUTODOME IP Camera | en starlight 5000i IR This action resets all settings to defaults (including network settings). 6.1.1 Display Stamping Various overlays or “stamps” in the video image provide important supplementary information. These overlays can be enabled individually and are arranged on the image in a clear manner.
Page 22 AUTODOME IP starlight 5000i | AUTODOME IP en | Camera starlight 5000i IR Time stamping Select the position of the time and date overlay in the drop-down box. It can be displayed at the Top, at the Bottom, or at a position of choice using the Custom option, or it can be set to Off for no overlay information.
Page 23 AUTODOME IP starlight 5000i | AUTODOME IP Camera | en starlight 5000i IR If you have enabled the Transparent background option, the background color is not displayed in the OSD. Transparent background Check this box to make transparent the stamp background on the image.
Page 24 AUTODOME IP starlight 5000i | AUTODOME IP en | Camera starlight 5000i IR Telemetry region Enable The fields Position (XY) and (0...255) appear. In the field Position (XY), specify the exact position. (The default is 10.) In the field (0...255), enter the position range. (The default is 176).
Page 25: Positioning
AUTODOME IP starlight 5000i | AUTODOME IP Camera | en starlight 5000i IR Signature interval [s] For certain Video authentication modes, enter the interval (in seconds) between insertions of the digital signature. 6.1.2 Positioning The Positioning feature describes the location of the camera and the perspective in the camera’s field of view.
Page 26: Scene Mode
AUTODOME IP starlight 5000i | AUTODOME IP en | Camera starlight 5000i IR WGS 84 The WGS 84 coordinate system is a spherical coordinate system description of the world and used in many standards including GPS. Latitude Latitude is the north-south position of the camera in the spherical coordinate system WGS...
Page 27: Color
AUTODOME IP starlight 5000i | AUTODOME IP Camera | en starlight 5000i IR Mode ID The name of the selected mode is displayed. Copy mode to Select the mode from the drop-down menu to which you wish to copy the active mode.
Page 28: Alc
AUTODOME IP starlight 5000i | AUTODOME IP en | Camera starlight 5000i IR Option in field Additional Additional fields for NOTES “White balance” Input field configuration Sodium lamp auto RGB- R-weight weighted G-weight white B-weight balance Dominant color auto RGB-...
Page 29: Picture Settings
AUTODOME IP starlight 5000i | AUTODOME IP Camera | en starlight 5000i IR Exposure Select the appropriate exposure speed. Select Auto to allow the camera to set the optimum shutter speed automatically. The camera tries to maintain the selected shutter speed as long as the light level of the scene permits.
Page 30 AUTODOME IP starlight 5000i | AUTODOME IP en | Camera starlight 5000i IR Sodium blue level Adjust the level of blue for sodium vapor lighting with the slider from 0 to 255. Note: The fields Sodium red level and Sodium blue level appear only when the value in the field White balance is “Sodium lamp auto”...
Page 31: Enhance
The EIS algorithm appears to “shift” the image on the screen while trying to keep the video stable. This “shift” is more visible at night when the camera interprets vehicle headlights as unstable video. Therefore, Bosch recommends not to use IS in combination with VCA. Sharpness mode Select the appropriate sharpness mode.
Page 32: Scene Mode Scheduler
AUTODOME IP starlight 5000i | AUTODOME IP en | Camera starlight 5000i IR Use the slider to adjust the Gamma correction value. The higher the number, the better the image contrast. Intelligent Defog Select this to activate the automatic intelligent defog feature. This feature continuously adjusts image parameters to provide the best picture possible under foggy or misty conditions.
Page 33: Encoder Profile
AUTODOME IP starlight 5000i | AUTODOME IP Camera | en starlight 5000i IR Select the shutter speed for fixed exposure. (The values available depend on the value set for the ALC mode.) Maximum shutter [s] Select a value in this field as the maximum speed of the shutter when the camera is in Automatic exposure mode.
Page 34 AUTODOME IP starlight 5000i | AUTODOME IP en | Camera starlight 5000i IR Caution! The profiles are rather complex. They include a large number of parameters that interact with one another, so it is generally best to use the default profiles.
Page 35 AUTODOME IP starlight 5000i | AUTODOME IP Camera | en starlight 5000i IR For maximum image quality, apply minimum bit rate reduction (Maximum quality). This will also greatly increase the file size. If maximum bit rate reduction is applied, the image will have less quality, but the file size decreases significantly (Minimum bit rate).
Page 36: Encoder Streams
AUTODOME IP starlight 5000i | AUTODOME IP en | Camera starlight 5000i IR frame (QP value), the higher the encoding quality (and thus the best image quality) and the lower the frame refresh rate depending on the settings for the maximum data rate under network settings.
Page 37: Encoder Statistics
AUTODOME IP starlight 5000i | AUTODOME IP Camera | en starlight 5000i IR Profile number Default Profile name Description Profile 2 HD Balanced For an HD image, the video bit rate and frame quality are adjusted to a median profile for everyday use.
Page 38: Privacy Masks
AUTODOME IP starlight 5000i | AUTODOME IP en | Camera starlight 5000i IR Privacy Masks Note: The sequence of fields in the GUI may not match the sequence of the fields in this section of the User Manual. In this section of the User Manual, fields appear in a more logical functional sequence, identifying the sequence to create a new privacy mask, and then to update a privacy mask.
Page 39: Lens Settings
AUTODOME IP starlight 5000i | AUTODOME IP Camera | en starlight 5000i IR Lens Settings Focus Focus speed Use the slider (from 1 to 8) to control how fast the Auto focus will readjust when the focus becomes blurred. IR focus correction Optimizes the focus for IR lighting.
Page 40: Pre-Positions And Tours
AUTODOME IP starlight 5000i | AUTODOME IP en | Camera starlight 5000i IR The camera can make up to two (2) recorded tours. A recorded tour saves all manual camera movements made during the recording, including its rate of pan, tilt and zoom speeds, and other lens setting changes.
Page 41: Pre-Position Settings
AUTODOME IP starlight 5000i | AUTODOME IP Camera | en starlight 5000i IR Click AUX Control. Type 8 in the input box and click AUX on. To stop the tour, type 8 and click AUX off. To define a Custom tour Create the individual pre-positions.
Page 42: Miscellaneous
6.14 Illuminator Note: This menu page is valid for AUTODOME IP 5000i IR │ AUTODOME IP starlight 5000i IR │ AUTODOME IP starlight 5100i IR only. IR mode By default, the camera is set to automatic illuminator mode (Auto). To deactivate this mode, select Off.
Page 43: Pixel Counter
AUTODOME IP starlight 5000i | AUTODOME IP Camera | en starlight 5000i IR Input volume Set the input volume using the slide. Values range from 0 to 119. Line Out Set the line output gain using the slider. Values range from 0 to 115.
Page 44: Recording
The Storage overview field displays the local media. Note: The recording performance of the SD card depends on the speed (class) and the performance of the SD card. Bosch recommends an SD card of Class 6 or higher. 2025-04 | 1.0 | DOC...
Page 45: Activating And Configuring Storage Media
AUTODOME IP starlight 5000i | AUTODOME IP Recording | en starlight 5000i IR Note: For more information about Automatic Network Replenishment (ANR), refer to the White Paper “ANR 2.0 Automatic Network Replenishment (ANR),” available on the product page for your camera. Access the product page on the online product catalog through the appropriate link from https://www.boschsecurity.com/xc/en/product-catalog/.
Page 46 AUTODOME IP starlight 5000i | AUTODOME IP en | Recording starlight 5000i IR Stream profile settings Select the encoder profile setting that is to be used with stream 1 and 2 when recording. This selection is independent of the selection for live stream transmission. (The properties of the encoder profiles are defined on the Encoder Profile page.)
Page 47: Maximum Retention Time
AUTODOME IP starlight 5000i | AUTODOME IP Recording | en starlight 5000i IR If the target has not yet been defined, click Configure accounts to jump to the Accounts page where the server information can be entered. Alarm triggers * Select the alarm type that is to trigger an alarm recording: –...
Page 48: Recording Status
AUTODOME IP starlight 5000i | AUTODOME IP en | Recording starlight 5000i IR Deleting Holidays You can delete holidays you have defined yourself at any time. Click the Delete button. A new window will open. Click the date you wish to delete.
Page 49: Sd Card Status
AUTODOME IP starlight 5000i | AUTODOME IP Recording | en starlight 5000i IR – 2560 x 1440 – Resource based The default option is 256 x 144. File name Select how file names are created for the individual images that are transmitted.
Page 50: Alarm
AUTODOME IP starlight 5000i | AUTODOME IP en | Alarm starlight 5000i IR Alarm Alarm Connections You can select how the camera responds to an alarm. In the event of an alarm, the unit can automatically connect to a pre-defined IP address. You can enter up to ten IP addresses to which the camera will connect in sequence in the event of an alarm, until a connection is made.
Page 51: Video Content Analysis (Vca)
AUTODOME IP starlight 5000i | AUTODOME IP Alarm | en starlight 5000i IR Caution! Please note that in some circumstances, a larger bandwidth must be available on the network for additional video images in the event of an alarm, in case Multicast operation is not possible.
Page 52 A separate Help file provides information about configuring for the VCA settings. Note: Full VCA configuration and Help is only available on the web browser when MPEG ActiveX software from Bosch is installed on your computer. MPEG ActiveX software is available from the Bosch Security Systems DownloadStore (https:// downloadstore.boschsecurity.com/)
Page 53 AUTODOME IP starlight 5000i | AUTODOME IP Alarm | en starlight 5000i IR Alarm status The alarm status is displayed here for information purposes. This means you can check the effects of your settings immediately. Tamper detection Detect tampering of cameras and video cables by means of various options. Run a series of tests at different times of the day and night to ensure that the video sensor is operating as intended.
Page 54: Audio Alarm
AUTODOME IP starlight 5000i | AUTODOME IP en | Alarm starlight 5000i IR changes to occur simultaneously in a large number of sensor fields to trigger an alarm. This option allows detection, independently of motion alarms, manipulation of the orientation or location of a camera resulting from turning the camera mount bracket, for example.
Page 55 AUTODOME IP starlight 5000i | AUTODOME IP Alarm | en starlight 5000i IR Mail server IP address Enter the IP address of a mail server that operates on the SMTP standard (Simple Mail Transfer Protocol). Outgoing e-mails are sent to the mail server via the address you entered.
Page 56: Alarm Inputs
AUTODOME IP starlight 5000i | AUTODOME IP en | Alarm starlight 5000i IR Test e-mail You can test the e-mail function by clicking the Send Now button. An alarm e-mail is immediately created and sent. Alarm Inputs Active Configure the alarm triggers for the unit.
Page 57: Alarm Task Editor
AUTODOME IP starlight 5000i | AUTODOME IP Alarm | en starlight 5000i IR Output name Enter a name for the alarm output. This name appears on the Live page. Note: This name appears in the Digital I/O section of the Live page.
Page 58: Network
AUTODOME IP starlight 5000i | AUTODOME IP en | Network starlight 5000i IR Network The settings on these pages are used to integrate the device into a network. Some changes only take effect after a reboot. In this case Set changes to Set and Reboot.
Page 59 AUTODOME IP starlight 5000i | AUTODOME IP Network | en starlight 5000i IR Prefix length A typical IPv6 node address consists of a prefix and an interface identifier (total 128 bits). The prefix is the part of the address where the bits have fixed values or are the bits that define a subnet.
Page 60: Advanced
AUTODOME IP starlight 5000i | AUTODOME IP en | Network starlight 5000i IR HSTS Select this option to use the web security policy HTTP Strict Transport Security (HSTS) to provide secure connections. RCP+ port 1756 To exchange connection data, you can activate the unsecured RCP+ port 1756. If you want connection data to be transmitted only when encrypted, select the Off option to deactivate the port.
Page 61: Network Management
AUTODOME IP starlight 5000i | AUTODOME IP Network | en starlight 5000i IR Network Management SNMP The camera supports two versions of Simple Network Management Protocol (SNMP) for managing and monitoring network components, and can send SNMP messages (traps) to IP addresses.
Page 62: Ipv4 Filter
AUTODOME IP starlight 5000i | AUTODOME IP en | Network starlight 5000i IR With a 0.0.0.0 setting, the encoder for the stream operates in multi-unicast mode (copying of data stream in device). The camera supports multi-unicast connections for up to five simultaneously connected receivers.
Page 63: Service
Notice! Potential loss of data Bosch recommends that you save all device configurations, including IVA and calibration, on your network before starting a firmware update. Notice! Before starting a firmware update, make sure to select the correct upload file.
Page 64: Licenses
AUTODOME IP starlight 5000i | AUTODOME IP en | Service starlight 5000i IR 10.2 Licenses This window is for the activation of additional functions by entering activation codes. An overview of installed licenses is shown. The installation code of the unit is also displayed here.
Page 65: System Overview
AUTODOME IP starlight 5000i | AUTODOME IP Service | en starlight 5000i IR – failed to home properly. – restarted. – lost video. Logs This section updates automatically with the history of the camera and maintains a log of all events such as those listed below.
Page 66: Operation Via The Browser
AUTODOME IP starlight 5000i | AUTODOME IP en | Operation via the browser starlight 5000i IR Operation via the browser 11.1 Live page 11.1.1 Connection Stream 1 Select this option to display stream 1 of the camera. Stream 2 Select this option to display stream 2 of the camera.
Page 67: Pre-Positions
AUTODOME IP starlight 5000i | AUTODOME IP Operation via the browser | en starlight 5000i IR 11.1.3 Pre-positions The camera displays Pre-position 1 through Pre-position 6. Select the appropriate pre- position to view the video image for that pre-position/scene. In the lower left of the video image, the OSD displays the Camera number (title), the Pre-position number, and the Pre- position number stored.
Page 68: Special Functions
AUTODOME IP starlight 5000i | AUTODOME IP en | Operation via the browser starlight 5000i IR Note: You can change the name of an alarm input in Configuration > Interfaces > Alarm Inputs > Input 1 (or Input 2) > Name.
Page 69: Full-Screen Video
AUTODOME IP starlight 5000i | AUTODOME IP Operation via the browser | en starlight 5000i IR 11.1.9 Full-screen video Click the full-screen icon to view the selected stream in full-screen mode; press Esc on the keyboard to return to the normal viewing window.
Page 70: Status Icons
AUTODOME IP starlight 5000i | AUTODOME IP en | Operation via the browser starlight 5000i IR The information from the icons can help with solving problems with the unit or with fine- tuning the unit. Hover over the CPU load icon to see the CPU load.
Page 71: Selecting The Recording Stream
AUTODOME IP starlight 5000i | AUTODOME IP Operation via the browser | en starlight 5000i IR – Track list 11.2.1 Selecting the recording stream On the left side of the browser, expand the Connection group if necessary. To view a recording stream: Click the Recording drop-down arrow to see the options.
Page 72: Dashboard
AUTODOME IP starlight 5000i | AUTODOME IP en | Operation via the browser starlight 5000i IR 11.3 Dashboard The Dashboard page is used to display detailed information about the device and is only visible in the application bar if the Show 'Dashboard' option is enabled by a service-level user in the Configuration >...
Page 73: Aux Commands
AUTODOME IP starlight 5000i | AUTODOME IP AUX Commands | en starlight 5000i IR AUX Commands Function Command Notes On/Off Auto pan without limits (Continuous) On/Off Auto pan between limits On/Off Run Custom Pre-Position Tour On/Off Run Pre-Position Tour On/Off...
Page 74 AUTODOME IP starlight 5000i | AUTODOME IP en | AUX Commands starlight 5000i IR Function Command Notes On/Off Mask Calibration Procedure 1-256 Set/- Pre-position Programming 1-256 -/Shot Pre-position Recall 2025-04 | 1.0 | DOC Bosch Security Systems User manual...
Page 75: Troubleshooting
Transmission mode is set to UDP. Camera reboots frequently or Test your camera with another power supply. intermittently. Check the Bosch website for a software update that might address the issue. No OSD messages appear. Bosch’s Video SDK is required. Video management software from third parties does not use the SDK.
Page 76 AUTODOME IP starlight 5000i | AUTODOME IP en | Troubleshooting starlight 5000i IR Problem Questions to Ask/Actions to Resolve the Problem - Check that there is 24 V output from the transformer. If O.K., then: - Check the integrity of all wires and mating connectors to the camera.
Page 77: Rebooting The Unit
If you cannot control the unit after the firmware upgrade, then cycle the power to the unit. If a power reset does not solve the problem, or if Configuration or video management software identifies the unit as “Videojet Generic,” then contact your Bosch Service Center for an RMA for the unit.
Page 78: Physical Reset Button
AUTODOME IP starlight 5000i | AUTODOME IP en | Troubleshooting starlight 5000i IR 13.2 Physical reset button You may need to complete a hardware reset if you have the following issues: – You can power up the camera but cannot log on to the camera using the web browser.
Page 79: Customer Service And Support
AUTODOME IP starlight 5000i | AUTODOME IP Troubleshooting | en starlight 5000i IR 13.3 Customer Service and Support If this unit needs service or if you need technical support, contact Bosch Security Systems Technical Support for instructions. USA and Canada Telephone: 800-289-0096, option 4 Fax: 800-315-0470 Email: technical.support@us.bosch.com...
Page 80: Support
Troubleshooting – Repair & Exchange – Product Security Bosch Building Technologies Academy Visit the Bosch Building Technologies Academy website and have access to training courses, video tutorials and documents: www.boschsecurity.com/xc/en/support/training/ 2025-04 | 1.0 | DOC Bosch Security Systems User manual...
