11.1 Tools Required 11.2 Preparing the Ceiling for Installation 11.3 Installing the Pipe Mount 11.4 Attaching the Mounting Cap and the Camera Connection Troubleshooting Decommissioning 14.1 Transfer 14.2 Disposal Support Bosch Security Systems Installation Manual 2025-04 | 1.0 | DOC...
AUTODOME IP starlight 5000i (IR) Safety Legal Information Copyright This manual is the intellectual property of Bosch Security Systems, and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered trademarks and must be treated accordingly.
10. Protect all connection cables from possible damage, particularly at connection points. Video loss - Video loss is inherent to digital video recording; therefore, Bosch Security Systems cannot be held liable for any damage that results from missing video information.
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Responsible party Bosch Security Systems, LLC 130 Perinton Parkway 14450 Fairport, NY, USA www.boschsecurity.us Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
For in-ceiling or indoor pendant applications that don’t require heater power, standard PoE+ (802.3at) midspans or switches can be used to power the camera. Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
Security advisories, that is a list of identified vulnerabilities and proposed solutions: https://www.boschsecurity.com/xc/en/support/product-security/security- advisories.html Bosch assumes no liability whatsoever for any damage caused by operating its products with outdated software components. Notice! Bosch strongly recommends upgrading to the latest firmware for the best possible functionality, compatibility, performance and security.
109 m (358 ft) 275 m (905 ft) Outdoor 28 m (94 ft) 45 m (150 ft) 72 m (238 ft) 183 m (603 ft) Wire Gage Wire diameter (mm²;ISO 6722, standard DIN sizes) Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
Loosen the three (3) Hex screws in the trim ring / bubble enclosure with the appropriate Torx screwdriver. Remove the trim ring / bubble enclosure. Remove the foam insert that protects the camera block. 2025-04 | 1.0 | DOC Bosch Security Systems Installation Manual...
Page 11
AUTODOME IP starlight 5000i (IR) Preparing the Camera | en Remove the tape holding the plastic lens protector; remove the lens protector. Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
IP cameras, including AUTODOME and MIC. The illustration can represent any IP camera. Mounting hardware varies between units. Figure 4.1: Correct outdoor installation with proper surge/lightning suppression 2025-04 | 1.0 | DOC Bosch Security Systems Installation Manual...
Page 13
Voltage range Minimum separation distance For <600 VAC 50 mm (2 in.) For >600 VAC and <3 kV 1.5 m (5 ft) For >3 kV 3 m (10 ft) Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
Page 14
Camera Housings and Mounts – Use only Bosch mounts listed on the datasheet of the specific camera. – Follow all grounding for the camera housings and mounts per the installation manual. 2025-04 | 1.0 | DOC...
Installing a microSD card (optional) | en Installing a microSD card (optional) Disconnect power to the camera while adding or removing an SD card. Push the camera block until you see the card slot. Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
Page 16
| Installing a microSD card (optional) AUTODOME IP starlight 5000i (IR) Insert the card into the slot. Push the camera block into its original position. 2025-04 | 1.0 | DOC Bosch Security Systems Installation Manual...
Page 17
AUTODOME IP starlight 5000i (IR) Installing a microSD card (optional) | en Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
Page 18
AUTODOME IP starlight 5000i (IR) Note: The next two steps are for pendant models only. Replace the trim ring / bubble enclosure. Tighten the screws with the T15 Torx screwdriver. Proceed with installation. 2025-04 | 1.0 | DOC Bosch Security Systems Installation Manual...
Tighten the four (4) securing screws to the Bracket Assembly. Secure the Bracket Assembly to an overhead securing point with a safety wire. Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
(3) screws. Tighten the screws firmly to secure the trim ring / bubble enclosure to the in-ceiling bracket. Remove the protective plastic sheet from the bubble. Installation is complete. 2025-04 | 1.0 | DOC Bosch Security Systems Installation Manual...
Cut the hole in the ceiling with a drywall utility saw or jig saw. > 15 kg (33 lb) 178.0 (7.0) Pull the cables (24 VAC, CAT 5/CAT6, alarm and/or audio as needed) through the hole in the ceiling. Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
Insert the camera (without the trim ring / bubble enclosure) into the hole in the ceiling. Ensure not to pinch the cables. Turn each fastening screw to secure the clamps in the ceiling. 2025-04 | 1.0 | DOC Bosch Security Systems Installation Manual...
Page 23
(3) screws. Tighten the screws firmly to secure the trim ring / bubble enclosure to the in-ceiling bracket. Remove the protective plastic sheet from the bubble. Installation is complete. Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
To make a watertight seal, wrap PTFE tape (user-supplied) four times around the threads at the end of the mount. Attach the mounting cap to the mount. Secure the locking screw with the T15 Torx screwdriver. 2025-04 | 1.0 | DOC Bosch Security Systems Installation Manual...
Page 25
Attach the hook at the end of the Safety Tether to the loop attached to the top of the camera. Connect the mating connectors on the user-supplied cables to the matching connectors on the camera. Refer to the chapter Connection for more information. Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
Page 26
| Installing a Camera Directly to an Indoor Wall AUTODOME IP starlight 5000i (IR) 2025-04 | 1.0 | DOC Bosch Security Systems Installation Manual...
Page 27
AUTODOME IP starlight 5000i (IR) Installing a Camera Directly to an Indoor Wall | en NDA-U-WMT NDA-U-WMT NDA-U-PAx NDA-U-PMT NDA-U-RMT Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
Page 28
| Installing a Camera Directly to an Indoor Wall AUTODOME IP starlight 5000i (IR) 2025-04 | 1.0 | DOC Bosch Security Systems Installation Manual...
Secure the locking screw with the T15 Torx screwdriver. Thread all connection cables through the mounting cap. Attach the hook at the end of the Safety Tether to the loop attached to the top of the camera. Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
Page 30
| Installing a Surveillance Cabinet and Camera AUTODOME IP starlight 5000i (IR) Connect the mating connectors on the user-supplied cables to the matching connectors on the camera. Refer to the chapter Connection for more information. 2025-04 | 1.0 | DOC Bosch Security Systems Installation Manual...
Page 31
AUTODOME IP starlight 5000i (IR) Installing a Surveillance Cabinet and Camera | en NDA-U-WMT NDA-U-WMT NDA-U-PAx NDA-U-PMT NDA-U-RMT Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
Page 32
| Installing a Surveillance Cabinet and Camera AUTODOME IP starlight 5000i (IR) 2025-04 | 1.0 | DOC Bosch Security Systems Installation Manual...
Anchor bolts can be used for blind structures where there is no access to the rear. Apply a weatherproof sealant around each fastener hole at the mounting surface. Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
To make a watertight seal, wrap PTFE tape (user-supplied) four times around the threads at the end of the mount. Attach the mounting cap to the mount. Secure the locking screw with the T15 Torx screwdriver. 2025-04 | 1.0 | DOC Bosch Security Systems Installation Manual...
Page 35
Attach the hook at the end of the Safety Tether to the loop attached to the top of the camera. Connect the mating connectors on the user-supplied cables to the matching connectors on the camera. Refer to the chapter Connection for more information. Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
Page 36
| Installing a Roof Mount and Camera AUTODOME IP starlight 5000i (IR) 2025-04 | 1.0 | DOC Bosch Security Systems Installation Manual...
Page 37
AUTODOME IP starlight 5000i (IR) Installing a Roof Mount and Camera | en NDA-U-WMT NDA-U-WMT NDA-U-PAx NDA-U-PMT NDA-U-RMT Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
Page 38
| Installing a Roof Mount and Camera AUTODOME IP starlight 5000i (IR) 2025-04 | 1.0 | DOC Bosch Security Systems Installation Manual...
Attach the pipe extension to the open end of the pipe mount. Attach the hook at the end of the Safety Tether to the loop attached to the top of the camera. Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
Attach the hook at the end of the Safety Tether to the loop attached to the top of the camera. Connect the mating connectors on the user-supplied cables to the matching connectors on the camera. Refer to the chapter Connection for more information. 2025-04 | 1.0 | DOC Bosch Security Systems Installation Manual...
Page 41
AUTODOME IP starlight 5000i (IR) Installing a Pipe Mount and Camera | en Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
Page 42
| Installing a Pipe Mount and Camera AUTODOME IP starlight 5000i (IR) NDA-U-WMT NDA-U-WMT NDA-U-PAx NDA-U-PMT NDA-U-RMT 2025-04 | 1.0 | DOC Bosch Security Systems Installation Manual...
Page 43
AUTODOME IP starlight 5000i (IR) Installing a Pipe Mount and Camera | en Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
Figure 12.1: AUTODOME IP System Configuration 1 AUTODOME camera 2 IP connection (Ethernet/Cat5) (100 m maximum) 3 Network switch 4 Network device (computer with monitor, DVR/NVR, etc.) 2025-04 | 1.0 | DOC Bosch Security Systems Installation Manual...
Page 45
Alarm Out Brown ALARM_IN1 Alarm In 1 White ALARM_IN2 Alarm In 2 Blue AUDIO OUT Audio Out Grey Ground Black AUDIO GND Audio Ground Green AUDIO IN Audio In Purple Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
Transmission mode is set to UDP. Camera reboots frequently or Test your camera with another power supply. intermittently. Check the Bosch website for a software update that might address the issue. No OSD messages appear. Bosch’s Video SDK is required. Video management software from third parties does not use the SDK.
Page 47
Ensure that the maximum distance between any two Ethernet connections is 100 m (328 ft) or less. If O.K., then: - Restore all camera settings. Background is too bright to see Turn on backlight compensation. subject. Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
The device should only be passed on together with this Installation manual. 14.2 Disposal Disposal - Your Bosch product was developed and manufactured with high-quality material and components that can be recycled and reused. This symbol means that electronic and electrical appliances, which have reached the end of their working life, must be collected and disposed of separately from household waste material.
Troubleshooting – Repair & Exchange – Product Security Bosch Building Technologies Academy Visit the Bosch Building Technologies Academy website and have access to training courses, video tutorials and documents: www.boschsecurity.com/xc/en/support/training/ Bosch Security Systems 2025-04 | 1.0 | DOC Installation Manual...
Page 50
| Support AUTODOME IP starlight 5000i (IR) 2025-04 | 1.0 | DOC Bosch Security Systems Installation Manual...
Page 52
