Summary of Contents for HBC-Radiomatic orbit
- Page 1 Operating Instructions Original Operating Instructions orbit YOO000G1...
- Page 2 HB C - radi om at ic Gm bH i s not l i abl e f or any m is pri nts or errors! ® radiomatic and radiobus are registered German trademarks . © 28 / 2024, HBC-radiomatic GmbH, 74564 Crailsheim, Germany part...
- Page 3 Modifications to the radio system may only be carried out by specialist personnel wh o have been trained and authorized by HBC-radiomatic. All modifications must be documented at the factory in the radio control master file. ...
- Page 4 Pos : 25 /T echnisc he Dokumentation/Betriebsanl eitungen/Sender/Bedi enung/Modul e/- 4- Aussc halten - ST OP- Schalter @ 2\mod_1225289959765_48.doc x @ 35880 @ @ 1 Press the STOP switch. Pos : 28 /T echnisc he Dokumentation/Betriebsanl eitungen/Sender/Bedi enung/Modul e/- 5- Hinweis - Akku wec hsel n ( orbit TC240) @ 9\mod_1358411807058_48.doc x @ 103537 @ @ 1 Note: Replace the battery when the status LED in the transmitter flashes red, an acoustic signal sounds and the transmitter vibrates.
- Page 5 Charge the batteries at intervals not exceeding 3 months when they are stored. When handled properly, Li-ion batteries by HBC-radiomatic can reach up to 500 charging cycles. Even after that, your batteries can be used for some time with a slightly decreased capacity.
- Page 6 Battery Charger Depending on customer selection, an AC or DC charger is available. A connection cable with the appropriate plug is included in the delivery. Please adhere to the following safety notifications in all cases. When the charger is improperly handled, there is the risk of fire and of electrical shock.
- Page 7 Pos : 45 /T echnisc he Dokumentation/Betriebsanl eitungen/Sender/Akku_Ladeger ät/M odul e/Li-Ion_Ladeger ät @ 9\mod_1358409217697_48.doc x @ 103411 @ 2 @ 1 Charging the battery 1. Connect the charger via the connecting cable to the power supply. 2. Insert the battery into the compartment. Charging will start automatically.
- Page 8 Pos : 49 /T echnisc he Dokumentation/Betriebsanl eitungen/Sender/Optionen/Modul e/_Ü1 - Opti onen @ 2\mod_1226593272812_48.doc x @ 37141 @ 1 @ 1 Options The availability of the following functions depends on the design and configuration of your radio control system. Pos : 50 /T echnisc he Dokumentation/Betriebsanl eitungen/Sender/Optionen/Modul e/_Ü2 - Sic herheitsfeatures @ 5\mod_1274367236207_48.doc x @ 61227 @ 2 @ 1 Safety Features Pos : 51 /T echnisc he Dokumentation/Betriebsanl eitungen/Sender/Optionen/Modul e/- 01- s hoc k-off_roll-detect_z ero-g_i nclinati on s witc h (H ands ender) @ 5\mod_1274367455864_48.doc x @ 61254 @ @ 1 ®...
- Page 9 Pos : 53 /T echnisc he Dokumentation/Betriebsanl eitungen/Sender/Optionen/Modul e/- 04- r adi omatic i nfrakey_neu @ 5\mod_1274426644078_48.doc x @ 61344 @ @ 1 ® radiomatic infrakey The radio system can only be activated via an infrared link between the transmitter and the receiver. This increases the safety of operation, i.e.
- Page 10 Pos : 58 /T echnisc he Dokumentation/Betriebsanl eitungen/Sender/Optionen/Modul e/- 23- Vibr ati ons alar m @ 5\mod_1270800932014_48.doc x @ 59930 @ @ 1 Vibration Alarm With the vibration alarm, the operator can be informed of an impending need to change the battery and/or potential dangers on the machine through the vibration of the transmitter.
- Page 11 Pos : 64 /T echnisc he Dokumentation/Betriebsanl eitungen/Sender/Optionen/Modul e/- 02.1- Fr equenz manag ement_Festfr equenz @ 5\mod_1274424301000_48.doc x @ 61290 @ 2 @ 1 Frequency Management Fixed Frequency If the identification plate in the battery compartment of the transmitter shows a frequency value (e.g. 433,500 MHz), the transmitter operates with a fixed frequency.
- Page 12 Pos : 74 /T echnisc he Dokumentation/Betriebsanl eitungen/Sender/Optionen/Modul e/- 03.1- Ü bernahme-Freigabe @ 13\mod_1444027960929_48.doc x @ 144744 @ 2 @ 1 Catch-Release Via the Catch-Release option two or more transmitters can control a machine alternately. When the receiver is switched on, the machine can initially be controlled via any associated transmitter.
- Page 13 Pos : 77 /T echnisc he Dokumentation/Betriebsanl eitungen/Sender/Optionen/Modul e/- 03.2- T andemfahrt neu @ 5\mod_1281505145362_48.doc x @ 62660 @ 2 @ 1 Tandem Operation Tandem Operation T1 The radio system consists of 1 transmitter and 2 receivers for 2 machines. The transmitter can control the machines individually or in parallel.
- Page 14 Tandem Operation TM/TS The radio system consists of 2 transmitters and 2 receivers for 2 machines . One transmitter is a master transmitter and can control the machines individually or in parallel . The other transmitter is a slave transmitter and can only control machine B. In order to be able to switch to machine B or A+B at the master transmitter, the key must be removed from the slave transmitter and inserted in the master transmitter.
- Page 15 Pos : 79 /T echnisc he Dokumentation/Betriebsanl eitungen/Sender/Optionen/Modul e/- 03.3- Ü bernahme-Freigabe-T andemfahrt @ 13\mod_1444031086609_48.doc x @ 144894 @ 2 @ 1 Catch-Release-Tandem Operation With the Catch-Release-Tandem Operation two or more transmitters can control several machines alternately. Each machine is equipped with a receiver that can receive and monitor all transmitter frequencies. After activating the receivers all transmitters have equal access to the radio control system .
- Page 16 Pos : 82 /T echnisc he Dokumentation/Betriebsanl eitungen/Sender/Optionen/Modul e/- 05- Kabelsteuerung @ 2\mod_1226395483359_48.doc x @ 36613 @ 2 @ 1 Cable Control With a cable you can generate a direct data connection between the transmitter and receiver. The radio transmission is disabled. At the same time, the power supply of the transmitter is provided through the cable, as well.
- Page 17 Due to the above, a clearly visible indicator lamp should be installed on the machine. Pos : 97 /T echnisc he Dokumentation/Betriebsanl eitungen/Sender/Optionen/Modul e/- 17- Sc hlüss elsc halter ( orbit) @ 3\mod_1247564149070_48.doc x @ 47060 @ 2 @ 1 Key Switch The transmitter can alternatively be switched off by the key switch.
- Page 18 Pos : 99 /T echnisc he Dokumentation/Betriebsanl eitungen/T ec hnis che D aten/_Ü 1 - TD @ 1\mod_1221552834937_48.doc x @ 35026 @ 1 @ 1 Technical Data Pos : 100 /Tec hnisc he D okumentati on/Betri ebs anleitungen/T echnisc he Daten/Sender/TD_VS_Sender @ 10 \mod_1378361521654_0.doc x @ 112253 @ @ 1 Max.
- Page 19 If you wish to bring a defective radio system to your distributor or the factory by yourself, we kindly ask you to make an appointment in advance. For an overview of our worldwide service and sales contacts, please visit our website www.hbc-radiomatic.com under "Contact". === Ende der Liste für T extmar ke Inhalt2 === 19 / 19...
