Operating Instructions
Radio Transmitter PM NTU
BE-PM_NTU-US-L.DOC [ Word 97 ] FL
HBC-radiomatic, Inc. , Cincinnati , Ohio 45242 , USA
Information and specifications subject to change without notice.
HBC
– Radio Controls
R
a
d
i
o
T
r
a
n
R
a
d
i
o
T
r
a
n
for Industrial Cranes
HBC-electronic
Funktechnik GmbH
Tel.: +49(0)7951/393-0
M a d e i n G e r m a n y
P r o d . C o d e : S N T U 1 . 0
USA
CAN
T r a n s m i t t e r S e r . N o . : 7 3 5 -
IP55 / Nema 4
U
: 6V DC
B a t t .
Frequency Band (MHz): 902 918
–
W5 : FB1
FCC-ID: NO9 SNTU04
s
m
i
t
t
e
r
P
M
s
m
i
t
t
e
r
P
M
made for
Page 1 / 16
N
T
U
N
T
U
Radio Control System
2000-08-16
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HBC-Radiomatic PM NTU
Summary of Contents for HBC-Radiomatic PM NTU
- Page 1 : 6V DC B a t t . Frequency Band (MHz): 902 918 – W5 : FB1 FCC-ID: NO9 SNTU04 Radio Control System HBC-radiomatic, Inc. , Cincinnati , Ohio 45242 , USA Information and specifications subject to change without notice. 2000-08-16...
- Page 2 ( 513 ) – 7 33 – 49 00 Fax : ( 513 ) – 7 33 – 49 03 HBC-radiomatic GmbH is not liable for any misprints or errors! – All rights reserved. ™ HBC-radiomatic is a registered American trademark.
-
Page 3: Table Of Contents
In The Event of a Fault ..............14 Technical Data ....................15 Dimensions of the PM NTU ............... 16 Radio Control System HBC-radiomatic, Inc. , Cincinnati , Ohio 45242 , USA Information and specifications subject to change without notice. 2000-08-16... -
Page 4: Description
Operating the PM NTU transmitter using a different frequency range or transmitting power requires the approval of the competent regulative authorities for telecommunication. The radio system consists of the PM NTU transmitter, two rechargeable NiCd batteries, a battery charger and a receiver with antenna. The transmitter housing with integrated antenna is made of glass-fiber reinforced plastic. -
Page 5: Safety Instructions
Pay attention to the comments and instructions given. Ignoring the information provided may permanently impair the reliability and operability of the equipment. Radio Control System HBC-radiomatic, Inc. , Cincinnati , Ohio 45242 , USA Information and specifications subject to change without notice. 2000-08-16... -
Page 6: General Safety Instructions
With the first signs of any malfunction related to the operative safety and reliability of the PM NTU radio transmitter the operator must immediately shut down or not activate the transmitter. For the purpose of the present manual "shut down" implies : –... -
Page 7: Operator Safety Instructions
Radio Control System HBC-radiomatic, Inc. , Cincinnati , Ohio 45242 , USA Information and specifications subject to change without notice. 2000-08-16... -
Page 8: Operating Instructions
Always use the "ON / OFF" switch to switch the transmitter ON or OFF. Do not use the STOP switch ! Radio Control System HBC-radiomatic, Inc. , Cincinnati , Ohio 45242 , USA 2000-08-16 Information and specifications subject to change without notice. -
Page 9: Battery And Battery Charger
Always use the protective cap included. – Use the charger at room temperature and protect it from extreme heat (direct sun). Radio Control System HBC-radiomatic, Inc. , Cincinnati , Ohio 45242 , USA Information and specifications subject to change without notice. 2000-08-16... -
Page 10: Special Operating Modes (Optional)
"followed" the transmitter to the frequency selected. Radio Control System HBC-radiomatic, Inc. , Cincinnati , Ohio 45242 , USA 2000-08-16 Information and specifications subject to change without notice. -
Page 11: Tele-Teach-In Battery (Ttb 10)
3.2.2 tele-teach-in Battery (TTB 10) The PM NTU radio control – together with the FSE 735 and FSE 770 radio receivers – features the so-called tele-teach-in option. This specific function allows you to input and store the minimum as well as maximum speeds assigned to the individual joystick functions in a –... - Page 12 In case of systems that offer creeping function, all the functions will have to be programmed again in the creeping mode (switch set to the snail symbol). Radio Control System HBC-radiomatic, Inc. , Cincinnati , Ohio 45242 , USA 2000-08-16 Information and specifications subject to change without notice.
-
Page 13: Trouble-Shooting
− The battery is defective. − Ensure that recharging process runs correctly. − Check transmitter functions using a fully charged or replacement battery. Radio Control System HBC-radiomatic, Inc. , Cincinnati , Ohio 45242 , USA Information and specifications subject to change without notice. 2000-08-16... -
Page 14: Maintenance
Never "clean" the transmitter with a pressure or with a steam cleaner. If necessary, clean it with a fine brush or soft cloth, please. Note: In the event of any problems with the radio system, contact your distributor or HBC-radiomatic, Inc. . In The Event of a Fault Warning: Never operate a crane or machine with a faulty or defective radio system. -
Page 15: Technical Data
9.8 x 2.5 x 2.0 " ( 255 x 64 x 50 mm ) Weight approx. 7.7 lb. ( 3,5 kg ) System of protection Nema 4 ( IP 55 ) Radio Control System HBC-radiomatic, Inc. , Cincinnati , Ohio 45242 , USA Information and specifications subject to change without notice. 2000-08-16... -
Page 16: Dimensions Of The Pm Ntu
W 5 : F B 1 SNTU: NO9SNTU04 FCC-ID: NO9 SNTU04 PMNTU: N09PMNTU4 264 mm (10.4 ") 420 mm (16.5 ") Radio Control System HBC-radiomatic, Inc. , Cincinnati , Ohio 45242 , USA 2000-08-16 Information and specifications subject to change without notice.
