INSTALLATION
INSTRUCTIONS
TOILET SEAT | TIVOLI
BEFORE YOU BEGIN:
Before proceeding with installation, please read these instructions to familiarise yourself with the
required tools, materials and installation sequences. Please leave these instructions for the con-
sumer after installation.
Prior to installation, inspect the toilet seat to ensure that no damage has occurred in transit. If
damage has occurred, or a visible defect exists, do not proceed with installation, and advise your
supplier immediately.
PARTS IDENTIFICATION:
Toilet seat
x 1
INSTALLATION:
1.Insert expansion
bushes into seat fixing
holes
1597846-A2-A
®
WRAP OVER TOILET SEAT
Expansion bush
x 2
March 2024
Screw
Hinge plate
x 2
x 2
2. Attach gaskets to the
bottom of hinge plates
Page 1
Hinge plate gasket
x 2
3. Connect hinge plates
to expansion bushes
with screws, but do not
fully tighten, shall be
still adjustable
englefield.co.nz
21303A-0
Hinge plate cap
x 2
