Installation Instructions
Electronic Bathroom Sink Faucet
Record your model number:
Noter le numéro de modèle:
Anote su número de modelo:
Français, page 18
Español, página 36
1557544-2-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 104B77-SANA-CP KOH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kohler 104B77-SANA-CP KOH

Summary of Contents for Kohler 104B77-SANA-CP KOH

  • Page 1 Installation Instructions Electronic Bathroom Sink Faucet Record your model number: Noter le numéro de modèle: Anote su número de modelo: Français, page 18 Español, página 36 1557544-2-A...

  • Page 2: Warranty

    • Service parts: kohler.com/serviceparts • Care and cleaning: kohler.com/clean • Patents: kohlercompany.com/patents Warranty This product is covered under the KOHLER One-Year Limited Warranty, found at ® kohler.com/warranty. For a hardcopy of warranty terms, contact the Customer Care Center. 1557544-2-A Kohler Co.
  • Page 3 Tools Plumbers Putty Sealant Tape 1/8" Drill Bit 1-1/4" to 1-1/2" Hole Bit 3/8" Supply Stop 1557544-2-A Kohler Co.

  • Page 4: Before You Begin

    For new installations, install the faucet and drain to the sink before installing the sink. The faucet shown in this guide may differ from your actual product. The installation steps still apply. For installation with a mixing valve, two 3/8" compression supply hoses are required. 1557544-2-A Kohler Co.

  • Page 5: Install The Faucet

    Insert the faucet, water inlet tubing, and cables through the mounting hole. From under the sink, install the rubber washer and the metal washer onto the studs. Thread the nuts onto the studs until the faucet is secure. 1557544-2-A Kohler Co.

  • Page 6: Install The Control Box

    Use the standard wall anchors (provided) depending on your wall material. Attach the control box to the wall with the arrow pointing upward. Secure with the two screws (provided). Unthread the control box screws to remove the cover. 1557544-2-A Kohler Co.
  • Page 7 Connect the 2-pin sensor cable from the valve cover to the 2-pin sensor cable from the spout (orange and black cables). Guide the sensor cables through the slots in the control box. Loosely secure the cover to the control box for future access. 1557544-2-A Kohler Co.
  • Page 8 Verify that the tube from the spout is the appropriate length to reach the control box. Cut the tube if necessary. Remove any burrs and sharp edges. Insert the tube into the fitting (control box outlet end) until the tube stops. Verify that the tube is secure. 1557544-2-A Kohler Co.
  • Page 9 Use a 3/8" compression connection (not provided) to attach the hot supply to the hot inlet on the mixing valve (marked hot on the adjustment plate). Temperature Adjustment Loosen the lock screw on the adjustment plate. Rotate the adjustment plate to adjust the temperature. Retighten the lock screw. 1557544-2-A Kohler Co.
  • Page 10 Connect the power cords. Place the battery box into the empty space within the control box. Secure the control box cover to the control box. Allow 2 minutes for the sensor to cycle through the automatic sensing distance. 1557544-2-A Kohler Co.
  • Page 11 NOTE: The LED on the control valve assembly cover will flash RED every 2 seconds when the DC batteries are running low. The LED will flash every 6 seconds when the DC batteries are dead. Replace the batteries. 1557544-2-A Kohler Co.
  • Page 12 Connect the power cords. Place the hybrid battery into the empty space within the control box. Secure the control box cover to the control box. Allow 2 minutes for the sensor to cycle through the automatic sensing distance. 1557544-2-A Kohler Co.
  • Page 13 (Non-Staining) Plumbers Putty Disassemble the drain. Apply plumbers putty to the underside of the flange and attach. Apply thread sealant tape to the drain pipe threads. Tighten the nut. Connect the trapway. Wipe away excess plumbers putty. 1557544-2-A Kohler Co.

  • Page 14: Complete The Installation

    Uncover the sensors on the faucet or turn ON the water supplies. Activate the faucet and check all connections for leaks. Make adjustments as needed. Run water through the spout for 1 minute. Check for leaks and make adjustments as needed. 1557544-2-A Kohler Co.

  • Page 15: Troubleshooting

    Soak only the insert and no other components. C. Remove and clean the filter screen. 3. Constant A. The solenoid is A. Order and install a new solenoid water flow. not working. assembly. 1557544-2-A Kohler Co.
  • Page 16 However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by 1557544-2-A Kohler Co.
  • Page 17 • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This Class B digital apparatus complies with Canadian ICES-003. 1557544-2-A Kohler Co.
