About your Roomba® 205 DustCompactor™ Robot
DustCompactor™ Bin
EN
DustCompactor™ Bin
1
Compacting Arm
2
Filter
3
Bin Lid Release Button
4
Bin Lid
NOTE:
The water tank may contain a small amount of residual water
due to quality inspection. This is normal.
6
For more information, visit global.irobot.com
Water Tank
(Combo models only)
Water Tank
5
Water Tank Release Button
6
Electrode Plates
7
Mop Pad
8
Water Tank Cap
Dock
(Place against a wall)
9
8
10
11
12
Dock
9
IR Window
10
Charging Contacts
11
Power Port
NOTE:
The DustCompactor™ Bin must be installed for both
vacuuming mode and vacuuming & mopping mode otherwise the
vacuum-mop cannot be turned on.
12
Cord Attachment
13
Cord Wrap
14
Plug
13
14
