Behringer Wave Quick Reference

DIGITAL
UW – Upper Wavetable setting:
0 – All waves, wrapping
1 – The Upper Wavetable is used
2 – Exclude basic waveforms, no wrapping
SW – Sub-oscillator Waveform / function:
0 – Follows Main-oscillator, plus WAVES-SUB control
1 – WAVES-SUB independent control
2 – ENV3 → Sub-oscillator waveform
3 – Off
4 – Hard-sync, sync frequency is set by WAVES-SUB
5 – Ring mod, waveform is set by WAVES-SUB
6 – Noise generator, level is set by WAVES-SUB
KW – Keyboard → Waveform tracking:
0 – Off
1-3 – Higher notes = higher waveform in the wavetable
4 – Each note has its own waveform, WAVES-OSC offset
5-7 – Stronger versions of 4, waveforms are skipped
KF – Keyboard → Filter cutoff tracking:
0 – Off
1-2 – Less than 100%
3 – Approximately at 100%
4-6 – Between 100% and 200%
7 – Approximately at 200%
KL – Keyboard → Loudness tracking:
0-3 – Lower keys will sound louder than higher keys
4 – All keys have the same loudness
5-7 – Higher keys will sound louder than lower keys
MW – Waveform modulation:
0 – Off
1 – LFO → Waveform, amount set by ModWheel
2 – ModWheel → Waveform
3-9 – LFO → Waveform, amount from 10% to 100%
MF – Filter modulation:
0 – Off
1 – LFO → Cutoff, amount set by ModWheel
2 – ModWheel → Cutoff
3 – ModWheel → Resonance
4-9 – LFO → Cutoff, amount from 10% to 100%
ML – Loudness modulation:
0 – Off
1 – LFO → Loudness. Enhanced: amount set by ModWheel
Behringer Wave V1.0.11 Quick Reference (rev. A)
DIGITAL
BD – Bend wheel destination:
0 – Off
1 – Oscillators pitch
2 – Filter cutoff
3 – Waveform
4 – Only Sub-oscillator pitch
5 – Pitch + Filter cutoff
6 – Pitch + Waveform
7 – Filter cutoff + Waveform
BI – Bend wheel interval:
0 – Two semitones
1 – Major third
2 – Fifth
3 – One octave
4 – Two octaves
5 – One octave in semitones steps
TW - Aftertouch → Waveform:
0 – Off
1 – Aftertouch → Waveform
2 – Aftertouch → LFO modulation amount
TF – Aftertouch → Filter cutoff:
0 – Off
1 – Aftertouch → Filter cutoff
2 – Aftertouch → LFO modulation amount
TL – Aftertouch → Loudness:
0 – Off
1 – Aftertouch → Loudness
2 – Aftertouch → LFO modulation amount
TM – Aftertouch → ModWheel:
0 – Off
1 – On
VF – Velocity → Filter cutoff:
0 – Off
1 – Low sensitivity
2 – Medium sensitivity
3 – High sensitivity
VL – Velocity → Loudness:
0 – Off
1 – Low sensitivity
2 – Medium sensitivity
3 – High sensitivity
TUNING
DETU – Detune:
0 – Off
1-4 – Detune amount
5 – Fifth
6 – Up one octave
7 – Up two octaves
8 – Down one octave
9 – Down two octaves
MO – LFO → Main-oscillator: (ModWheel sets amount)
0 – Off
1 – On
MS – LFO → Sub-oscillator: (ModWheel sets amount)
0 – Off
1 – On
EO – ENV3 → Main-oscillator:
0 – Off
1 – On
2-9 – Portamento (both oscillators) glide time
ES – ENV3 → Sub-oscillator:
0 – Off
1 – On
BI – Bend wheel interval: (same as BI in DIGITAL)
0 – Two semitones
1 – Major third
2 – Fifth
3 – One octave
4 – Two octaves
5 – One octave in semitones steps
USER
EXP-PEDAL – Select action:
0 – Off
1 – Loudness
2 – Filter Cutoff
3 – Filter Resonance
4 – Waveform
5 – Modulation Wheel
TOUCH – Channel Aftertouch transmitted and received:
0 – Off
1 – Transmitted over MIDI
2 – Received over MIDI only, not from the keyboard
3 – Transmitted and received over MIDI
