KIBI Circular KBF1009 Installation Manual

Faucet only/with pop up drain

Advertisement

Quick Links

Installation Guide
Circular
KBF1009
Faucet Only
Circular
C-KBF1009-KPW101
Faucet with Pop up Drain
www.kibiusa.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Circular KBF1009 and is the answer not in the manual?

Questions and answers

Summary of Contents for KIBI Circular KBF1009

  • Page 1 Installation Guide Circular KBF1009 Faucet Only Circular C-KBF1009-KPW101 Faucet with Pop up Drain www.kibiusa.com...
  • Page 2: Before Installation

    Contact KIBI VOLUME-C 855-883-0888 ✉ support@kibiusa.com �� www.kibiusa.com PRIOR TO INSTALLATION 1- For best results, we recommends that this unit be installed by a licensed, professional plumber.
  • Page 3 Dimensions Critical dimensions show in mm KBF1009 1-5/8” 7-15/16” (42 mm) (202 mm) 2-3/16” (55 mm) 6-9/16” (166 mm) Φ1-3/8” (Φ35 mm) Supply line with 3/8" compression C-KBF1009-KPW101 1-5/8” 7-15/16” (42 mm) (2 0 2 mm) 2-7/16” (Φ62 mm) 2-7/16 (max 62 mm) Φ1-5/8”...
  • Page 4: Parts List

    Parts List KBF1009 Plug Handle Internal hex screw M5x5 Cover Oring Bonnet Nut CT35UF001 Cartridge 443260010 Aerator Service Key for Aerator Allen Key 2.5mm Facuet Base Water Line Rubber Washer M10_3/8”_27-1/2” Long Screws Rubber Washer Metal Washer Mounting Screw Mountig Screws C-KBF1009-KPW101 Plug Handle...
  • Page 5: Faucet Installation

    Faucet Installation Shut off water suppliers. Remove the old faucet, clean the Remove the mounting hardware from the mounting mounting surface. pipe. Note: For first time install, flush the pipes first by open the angel valve to run 60s. Put the rubber O-ring into the bottom gap of From below the sink, Slide rubber washer, metal washer faucets then Insert faucet into faucet hole.
  • Page 6 Pop-up drain Installation Remove all components from drain piece including: thin and thick silicone washer, hard washer, drain nut and tail piece. Insert thick silicone washer and hard washer over the Insert drain and thin silicone washer into basin. Apply exposed mail threaded area and screw drain nut onto Teflon to the exposed male threading area of drain piece.
  • Page 8: Troubleshooting

    Here are the details of our warranty policy: Kibi USA warrants the structure and finish of the faucets and accessories to be free from defects in material and workmanship under normal usage for as long as the original purchaser resides in the residence in which the product was first installed.

This manual is also suitable for:

Circular c-kbf1009-kpw101Circular c-kbf1009bg-kpw101bg
