Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information What’s Included Specifications Main Power Connection DMX Connection Display Settings DMX Profile Size And Weight Segment Installation Warranty Customer Service... -
Page 2: Safety Information
Check that the unit has not been damaged during transport. Protection Against Fire Maintain a minimum of 1 foot distance from any type of flame. Fixture is designed for indoor use. Do not install the unit too close to a heat source. Make sure cables are properly secured. -
Page 3: Specifications
Specifications Part Numbers Fixture ID 4150-Pielite Multibeam Mechanical Specifications Housing: Metal Mounting System: Quick Release Clamp Mounts, Multiple Fixture Quick Release Joining Mounts Power Connection: Seetronics SAC3MPX Input & SACFPX output (Nema 5-15 to SAC3FX-67 cable included) Signal Connection: 3 and 5 Pin XLR In and Out Lens: 4.5º... -
Page 4: Main Power Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit must be earthed. (Electronically grounded) Replace fuse only with the specified type and rating. (F6 250V) This device is equipped with auto switching power supply that will allow the fixture to work from 90-264V AC 50/60Hz Power Link max 3 units at 110V and 6 units at 220V Cable USA... -
Page 5: Display Control
Display Control Reset 180 37° C DMX Menu The control board on the fixture base is your interface to access and control all the functions on the unit. It’s LCD display gives you a code view of the options and functions. The following will explain each function. Enter Menu Advan... - Page 6 Manual: Gives you operational control over the fixture via display 37° C DMX Reset 180 Menu Advan Menu Manual: Select the Channel you wish to adjust. Us the up/down button to . Channels to adjust are: select the function setting from 0-255 Dimmer Dimmer Shutter...
-
Page 7: Dmx Profile
DMX Profile Pielite Multibeam Channel Channel Channel Channel Function Description Value Init Value Mode Mode Mode Mode Dimmer Dimmer Off to Full 0-255 LED Intensity Red LED Intensity 0-255 LED Intensity Green LED Intensity 0-255 LED Intensity Blue LED Intensity... -
Page 8: Size And Weight
Size and Weight 21”inch / 534mm 11.33”/ 288mm Use Secondary Safety Attachment 18662 Bandera Rd Helotes, TX 78023 www.mega.lighting 14.5”/ 368mm (With Power Connection) POWER IN 90-264V AC 50/60Hz 5.25” Back 104mm (With Safety 4.12”/ Enter Down Eye Bolt) 104mm MAX POWER LINK @110V 3 UNITS DMX IN... -
Page 9: Segment
Segment Facing Upwards Segment Positions Installation Caution! 1. The Installation must be carried out by an authorized dealer or trained professional. 2. Unit may cause severe injuries, if you have doubts concerning the safety do not install. 3. Unit is to be 24 inches away from flammable materials. 4. - Page 10 Fixture Hanging Orientations Fixture can be hung in the following configurations with the included hardware. Vertical Pie Half Pie When Connecting 2 or more Pielite’s together, make sure you are using the quick connection brackets on top and below the fixtures. Full Pie...
-
Page 11: Warranty
General Terms & Conditions 1. All resellers must have approved and signed Reseller Application on file, including their respective state tax information and W-9. Applications are re-evaluated on a fiscal calendar year basis to assure business integrity and tax status. 2. -
Page 12: Customer Support
Customer Support MEGA-Lite has a customer support line to provide set-up help and to answer any questions should you encounter a problem. Please visit our website for any other related technical documents. For service related issues, please contact our service dept. Monday - Friday 9am to 6pm CST (210)684-2600 Service@mega.lighting...
