USER MANUAL
Table of Contents
Safety Information.............................................................................................3
Specifications...................................................................................................4
Main Power Connection.....................................................................................5
DMX-512 Connection.........................................................................................5
Main Control Menu..............................................................................................................6
DMX Profile.........................................................................................................................8
Rigging the Fixture............................................................................................9
Cleaning & Maintenance.....................................................................................................9
Parts List.............................................................................................................................9
Advertisement
Table of Contents
Related Manuals for MegaLite Outshine Strip Q80
Summary of Contents for MegaLite Outshine Strip Q80
- Page 1 USER MANUAL Table of Contents Safety Information…………………………………………………………..…………………….3 Specifications……………………………………………………………………………………...4 Main Power Connection………………………………………………………………………….5 DMX-512 Connection…………………………………………………………………...………..5 Main Control Menu......................6 DMX Profile.........................8 Rigging the Fixture………………………………………………………………………………..9 Cleaning & Maintenance.....................9 Parts List..........................9...
- Page 3 Check that the unit has not been damaged during transport Check that the unit has not been damaged during transport Protection Against Fire Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 1. Maintain a minimum of 1 foot distance from any type of flame. 3.
-
Page 4: Technical Information
Technical Information Part Numbers 7225 Outshine Strip Q80 7225-S Outshine Strip Q80, Silver Housing Mechanical Specifications DMX Connectors: Neutrik 3 pin XLR NC3FXX-HD-D and NC3MXX-HD-D IP 67 connectors in and out Power connection: Screw type power cable monted connection to Nema 5-15 Thermal: Maximum ambient temperature 104°... -
Page 5: Main Power Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit has Auto switching power supply. It will respond to 110V or 220V automatically This unit must be earthed. (electronically grounded) The occupation of the connection-cable is as follows: This fixture is equipped with an electronic power supply that will let the unit operate from 100V to 240V from 50Hz to 60Hz Cable (USA) Cable (EU) - Page 6 Display Menu The control board on the fixture base is your interface to access and control all the functions on the unit. Its LED display gives you a code view of the options and functions. The following will explain each func- tion and its options.
- Page 7 1: DMX 1: DMX 2: Slave 2: Slave 3: Auto 3: Auto 4: Program 4: Program This function allows the fixture fade between color 1: DMX Program 2: Slave 1) Mode: 3: Auto 2) Speed: 4: Program 3) Strobe: Program: This function gives you control over the pre-programs Mode: To Select the fixtures pre-program chase (1 to 14).
- Page 8 Outshine Strip Q80 DMX Profile Outshine Strip Q80 4 Channel Mode DMX Channel Function Description Value Init LED Color Red LED intensity 0-255 LED Color Green LED Intensity 0-255 LED Color Blue LED Intensity 0-255 DMX Chanel Function Description Value...
-
Page 9: Rigging The Fixture
Rigging the fixture Caution! 1. The installations must be carried out by an authorized dealer or trained professional. 2. Unit may cause severe injures if you have doubts concerning the safety do not install. 3. Unit is to be 24inches away from flammable materials (decoration material) 4. -
Page 10: Warranty Information
Warranty Information Warranty Conditions -Unless otherwise stated in writing, your product is covered by a one year parts and labor limited warranty. -LEDs are not guaranteed to match in color temperature or output. -It is the owner’s responsibility to furnish receipts or invoices for verification of purchase, date, and reseller or distributor. If purchase date cannot be provided, date of manufacture will be used to determine warranty period.
