GCC Technologies LaserPro E200S Series User Manual

Hide thumbs Also See for LaserPro E200S Series:
Table of Contents

Advertisement

Quick Links

Download this manual
GCC LaserPro E200S Series
User Manual
4F., No.236, Fude 2nd Rd., Xizhi Dist., New Taipei City 22151, Taiwan 886-2-6616-6692 Fax:886-2-2694-6875
232004160G(03)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LaserPro E200S Series and is the answer not in the manual?

Questions and answers

Related Manuals for GCC Technologies LaserPro E200S Series

Summary of Contents for GCC Technologies LaserPro E200S Series

  • Page 1 GCC LaserPro E200S Series User Manual 4F., No.236, Fude 2nd Rd., Xizhi Dist., New Taipei City 22151, Taiwan 886-2-6616-6692 Fax:886-2-2694-6875 232004160G(03)

  • Page 2: Table Of Contents

    Chapter 1 Safety ..................6 1.1 Principles of a CO 2 Laser ............... 7 1.2 Safety Ratings ..................7 1.3 The Safety Interlock System ..............7 1.4 Safety Labels ................... 8 1.5 Safety Measures ..................11 1.5.1 General Safety ...................... 11 1.6 Operating Environment.................
  • Page 3 6.2.2 For E200S Print Driver ..................51 6.2.2.1 Wi-Fi connection ......................51 6.2.2.2 LAN (DHCP ON) Connection ................... 53 6.2.2.3 LAN (DHCP OFF) Connection ..................54 6.2.2.4 USB Connection......................54 Chapter 7 Operating the GCC LaserPro E200S ........ 55 7.1 How to use focus tool ................56 7.2 SmartJOB Software Operation .............
  • Page 4 Chapter 9 Basic Maintenance ............108 9.1 Suggested Cleaning and Maintenance Supplies ......109 9.2 Maintaining the Worktable and Motion System ........ 110 9.2.1 Cleaning the Worktable and Motion System ..........110 9.2.2 Lubrication of the X / Y Rails ................111 9.3 Cleaning the Optics System ..............
  • Page 5 Release Note Version Release Date Change Jul, 2024 First version Aug, 2024 Add E200SL model Oct. 2024 Add E200SM model 232004160G(03)

  • Page 6: Chapter 1 Safety

    Chapter 1 Safety Principles of a CO Laser Safety Ratings The Safety Interlock System Safety Labels Safety Measures Operating Environment Noise Test 232004160G(03)

  • Page 7: Principles Of A Co 2 Laser

    1.1 Principles of a CO Laser LASER is the acronym for Light Amplification by Stimulated Emission of Radiation. A CO laser works by electrically stimulating the molecules within a carbon dioxide gas mixture. When focused through a lens, this highly-intense, invisible beam will vaporize many materials. Depending on the speed and intensity of the projected beam, a CO laser may be used to engrave or cut through a wide variety of materials.

  • Page 8: Safety Labels

    1.4 Safety Labels According to CDRH standards, all fixed or removable covers that allow access to a laser beam must have the appropriate laser warning labels attached to them. These warning labels must be clearly visible to the operator prior to removing the cover. Additional labels must be applied inside of the machine and be visible in the event the covers are removed.
  • Page 9 Safety Label CDRH and CE regulations require that all laser manufacturers add warning labels in specific locations throughout the equipment. The following warning labels are placed on the laser system for your safety. Do not remove these labels for any reason. If the labels become damaged or have been removed for any reason, do not operate the laser system and immediately contact Great Computer Cooperation or e-mail us for a replacement.
  • Page 10 ❺ Warning Label Warning label is written with all necessary information to be aware of during operation. ❸ ❷ ❽ ❻ Laser Path Warning Label LaserPro machines are very safe under normal use. Furthermore, Laser Path Warning Label are displayed at the proximities of possible laser paths as a reminder.

  • Page 11: Safety Measures

    ❽ Electrical Safety Label DANGEROUS VOLTAGES ARE PRESENT WITHIN THE ELECTRONICS ENCLOSURES OF THIS SYSTEM. Access to these areas is not necessary during normal operation. If it becomes necessary to open one of these enclosures for service reasons, please remember to disconnect the power cord from your electrical supply.
  • Page 12 WARNING!  Resulting debris from laser processing are very dangerous and may cause fire hazard.  DO NOT leave debris and scraps inside laser machine after job finished. Must keep machine clean after job finished.  Always remove the vector grid to clean any small pieces that have fallen through the grid.

  • Page 13: Operating Environment

     Do not laser heat-sensitive surfaces or materia that may generate toxic fumes, such as PVC and Teflon.  Regularly clean and maintain your machine according to our cleaning and maintenance Instructions in Chapter 8. Doing so will ensure your machine will operate effectively and safely over a long period of time.

  • Page 14: Chapter 2 Unpacking And Content

    Chapter 2 Unpacking and Content Unloading and Unpacking Contents and Accessories Checklist 232004160G(03)

  • Page 15: Unloading And Unpacking

    2.1 Unloading and Unpacking The GCC LaserPro E200S series is shipped in one crate that contains machine, software, and all of the necessary accessories. The following section shows detailed step-by-step instructions for unpacking and assembly the accessory to workstation. WARNING! More than one person may be needed when loading and unloading the shipping crate in order to avoid body injury or damage to the machine.
  • Page 16 3) Remove the packing foam on the top. 4) Remove the side-cover carton. 5) Release the four safety blocks that hold the machine in place. 232004160G(03)
  • Page 17 6) Take out the water chiller and the accessory box. Accessory box Water chiller (E200S, E200SL only) 7) Now you can take out the machine. 232004160G(03)

  • Page 18: Chapter 3 Mechanical Overview

    Chapter 3 Mechanical Overview Front View Top View Right View Left View Rear View 232004160G(03)

  • Page 19: Front View

    Please take some time to familiarize yourself with this section regarding the mechanical overview of the LaserPro E200S series. References will be made back to the different parts of the LaserPro E200S series in later sections. 3.1 Front View Lower Front Door 3.2 Top View...
  • Page 20 3.3 Right (Profile) View Main Board 3.4 Left (Profile) View 232004160G(03)

  • Page 21: Rear View

    3.5 Rear View Air Valve Wi-Fi Module (E200S only) USB Port Ethernet Port Main Power Power Socket Power Inlet 232004160G(03)

  • Page 22: Water Chiller Front View

    Water Chiller Water Outlet Fume Extraction Signal (E200S, (E200S, Connection Port E200SL only) E200SL only) Water Chiller Power (E200S, Water Inlet (E200S, E200SL only) E200SL only) 3.6 Water Chiller Front View (E200S, E200SL) Power Light Alarm Light 232004160G(03)

  • Page 23: Water Chiller Right View

    3.7 Water Chiller Right View (E200S, E200SL) 232004160G(03)

  • Page 24: Water Chiller Left View

    3.8 Water Chiller Left View (E200S, E200SL) Water inlet Water Outlet Water Chiller Signal Water Chiller Power 3.9 Water Chiller Rear View (E200S, E200SL) Water Supply Inlet Water Level 232004160G(03)

  • Page 25: Chapter 4 Machine Setup

    Chapter 4 Machine Setup Water Chiller Setup E200S Desktop Laser Engraver Setup 232004160G(03)

  • Page 26: Water Chiller Setup

    4.1 Water Chiller Setup (E200S, E200SL) 1) Find two cables & two water hoses from the accessory box. 2) Connect the power cable from the machine to the water chiller. 232004160G(03)
  • Page 27 3) Connect the signal cable from the machine to the water chiller. 4) Connect the water hose from the machine to the water chiller. E200S machine “Water Out” to water chiller “Inlet”. E200S machine “Water in” to water chiller “Outlet” 232004160G(03)
  • Page 28 5) Fill distilled water into water supply inlet, make the water level be between the max and min limitation line. The tank capacity is 2L. NOTE: Please use distilled water ONLY 6) E200S Water Chiller setting up is completed. 232004160G(03)

  • Page 29: E200S Machine Setup

    4.2 E200S Machine Setup 1) Take out the Wi-Fi dongle from the zip bag in the accessory box. (E200S only) 2) Insert the Wi-Fi dongle to the USB port on the back of E200S machine. (E200S only) 232004160G(03)
  • Page 30 3) Connect the power cable and power on E200S machine. 4) Press on the "Quick Boot Button" on the front of machine. 232004160G(03)
  • Page 31 5) Remove the Camera Cover to let the camera is ready to capture the table. (E200S only) Remove the camera cover. 6) E200S setting up is simply and easy. * To use the extra facility, the power voltage shall be the same as the main power. 232004160G(03)

  • Page 32: Chapter 5 Software Setup

    Chapter 5 Software Setup Recommended Computer Configuration SmartJOB Installation E200S Driver Installation 232004160G(03)

  • Page 33: Recommended Computer Configuration

    5.1 Recommended Computer Configuration SmartJOB E200S software was designed to work best using both Windows and MAC system with the following minimum requirements Computer Configuration Intel Pentium, 1GHz or above DRAM 1GB RAM or above CDROM One CD-ROM disk drive 1 GB of free hard drive space SVGA Super VGA display (1204 x 768 min.
  • Page 34 Click “Next” Check the checkbox of “Launch SmartJOB” and click Finish. 232004160G(03)
  • Page 35 The SmartJOB will automatically open when installation is finish. Take out the Notification card from the accessory box Go to "Help" --> "Activate" from the menu bar and key in name and activate code to activate the software. 232004160G(03)
  • Page 36 E200S Camera Scaling In some cases you may find a slight output inaccuracy in the actual output compared to what you have set in the computer. This margin of error or offset is extremely small (approximately 1/300). What this means that there may be a 1-unit offset for every 300 unit increments. As an example, if you engrave a 300 mm straight line, it may end up measuring only 299 mm or 301 mm in the final output.

  • Page 37: E200S Driver Installation

    Open SmartJOB, go to “Setting” to enter the number as below picture: 5.3 E200S Driver Installation Please visit GCC website – download area to download E200S Print Driver and User Manual. https://www.gccworld.com/download.php?sid=driver 232004160G(03)

  • Page 38: Chapter 6 Connection Setup

    Chapter 6 Connection Setup Machine Connection Setup Assign the connection Method Connection Troubleshooting 232004160G(03)

  • Page 39: Machine Connection Setup

    6.1 Machine Connection Setup The LaserPro E200S series can communicate with a computer through a Wi-Fi (E200S only), USB Port or LAN Port connection interface. Please see below steps for each connection method. 6.1.1 Wi-Fi Connectivity (E200S only) Turn on the machine and click the “Func” → “Machine Setting” → “Network Setting” → “Wi-Fi” on the touch panel of the E200S.
  • Page 40 Click the green value box of the “Key in the first letter”, then the keyboard will appear. Key in the first letter of your country and click the “Enter” button to continue. Select your country from the list and the machine will reboot automatically. 232004160G(03)
  • Page 41 After rebooting, click the “Func” → “Machine Setting” → “Network Setting” → “Wi-Fi” on the touch panel of the E200S. Click the setup button for “Network” to load all available Wi-Fi networks and select the one you want to connect to. After the machine rebooting, the Wi-Fi connection is completed.

  • Page 42: Ethernet Connectivity

    6.1.2 Ethernet Connectivity Connect Ethernet cable between router and machine. Turn ON the machine. Connect computer to Internet through Ethernet or Wi-Fi. 6.1.3 USB Connection Connect USB cable between the computer and machine. 6.2 Assigns the Connection Method 6.2.1 For SmartJOB (E200S only) 6.2.1.1 Wi-Fi Connection Before setting connection, please make sure your computer is connected to the same Wi-Fi as E200S does.
  • Page 43 Select “E200S” from the drop-down menu, then click the “Scan Device” button, the software will search and show the machine in the list automatically. Click the machine you want to connect and click “OK” button to complete the connection. NOTE Please check your serial number of the machine to make sure the connection is correct if you have many machines.

  • Page 44: Lan (Dhcp On) Connection

    6.2.1.2 LAN (DHCP ON) Connection Before setting connection, please make sure your computer and the machine are connected to the same router. Open the SamrtJOB and click “Setting” on the tool bar. Select the “Wi-Fi / LAN” on the drop-down menu of Connection then click the “Setup” button to open the Wi-Fi setup window.
  • Page 45 Click the machine you want to connect and click “OK” button to complete the connection. 232004160G(03)

  • Page 46: Lan (Dhcp Off) Connection

    6.2.1.3 LAN (DHCP OFF) Connection Connect the LAN cable between computer and machine. → → → Turn ON the machine and click the “Func” “Machine Setting” “Network Setting” “Ethernet” on the touch panel of the E200S. Ensure the LAN setting is DCHP OFF. 232004160G(03)
  • Page 47 Press Ctrl + I key on keyboard to open the windows setting page, and go to “Network & internet” Click the “Ethernet” and click the “Edit” button for “IP Assignment”, then the Edit IP Settings window will appear. Please select “Manual” and turn the IPv4 ON. 232004160G(03)
  • Page 48 Now, refer to the touch panel of E200 to key in the value of the IP address, Mask, and Gateway. Then click the Save button to save the setting. NOTE  Please ensure that the IP address of the computer is set within the same subnet as the machine.
  • Page 49 10) Select the “Wi-Fi / LAN” on the drop-down menu of Connection then click the “Setup” button to open the Wi-Fi setup window. 11) Click on “Setup” button to open the setup window 12) Select “E200S” from the drop-down menu, then click the “Scan Device” button, the software will search and show the machine in the list automatically.

  • Page 50: Usb Connection

    6.2.1.4 USB connection 1) Open SmartJOB, and go to “settings” on the menu bar Select the “USB” on the drop-down menu of Connection then click the “Setup” button to open the Wi-Fi setup window. Select “E200S” from the drop-down menu, then click the “Scan Device” button, the software will search and show the machine in the list automatically.

  • Page 51: For E200S Print Driver

    6.2.2 For E200S Print Driver 6.2.2.1 Wi-Fi connection (E200S only) Before setting connection, please make sure your computer is connected to the same Wi-Fi as E200S does. → Go to “Control panel” “Devices and Printers” Double click “E200S” printer driver to open the printer driver window →...
  • Page 52 Click the “Port” button to open the Port Configure window. Select “LAN / Wi-Fi” and click “OK” button to open the setting window Please click the “Allow” button to continue if the Windows Security appeared. 232004160G(03)

  • Page 53: Lan (Dhcp On) Connection

    Then the “Device List” window will appear automatically. Double click your machine from the Device List and the setting is complete. NOTE Please check your serial number of the machine to make sure the connection is correct if you have many machines.

  • Page 54: Lan (Dhcp Off) Connection

    6.2.2.3 LAN (DHCP OFF) Connection Repeat steps 1 ~ 8 of chapter 6.2.1.3 to finish DHCP OFF settings. Repeat steps 2 ~ 7 of chapter 6.2.2.1 to set Port Configure. Then the “Device List” window will appear automatically. Double click your machine from the Device List and the setting is complete.

  • Page 55: Chapter 7 Operating The Gcc Laserpro E200S

    Chapter 7 Operating the GCC LaserPro E200S How to use Focus Tool SmartJOB Software Operation The LaserPro E200S Print Driver E200S Touch Panel Operation 232004160G(03)

  • Page 56: How To Use Focus Tool

    7.1 How to use focus tool Use the focus tool to do manual focus. There are two methods to set the correct focus distance. A. Place the focus tool this way to do manual focus with nozzle. With Air Nozzle Focus Tool B.
  • Page 57 Please refer to the following step to set correct focus distance manually. Step 1. Use the thumb screw on the carriage to adjust the focus distance. Step 2. Place the focus tool between the material and the carriage, the following picture shows the focus distance with the nozzle installed.
  • Page 58 Step 3. Place the focus tool between the material and the carriage, the following picture shows the focus distance without the nozzle installed. Step 4. Send the file to E200S machine. Step 5. Press "Start" on the touch panel to begin laser output. 232004160G(03)

  • Page 59: Smartjob Software Operation

    7.2 SmartJOB Software Operation (E200S only) 7.2.1 User interface introduction Function Definition Table Mat Display the actual table of the machine and object view QR Code Information Bar Display the material description when the QR code on the material is scanned File List Show the file history (Max.

  • Page 60: Functional Introduction

    7.2.2 Functional Introduction Function Definition Import Allow user to open/import files (available for JPG, BMP, PNG, EPS, PDF, SVG, AI formats) Trace Allow user to trace image and do contour Capture Table Take a table photo (including the object) and read the barcode one the material Pick Tool To select, position or transform objects Pan Tool...

  • Page 61: Trace Image Files

    7.2.3 Trace Image Files SmartJOB allows you to import image files (ai., bmp., jpg., gif., png. etc… formats) and will trace the image for cutting. Please note, results may vary depending on the source image file. To trace an image, choose "Trace Image"...
  • Page 62 Input Settings Choose an Image Enables the user to import a file. The program is supported with many file formats such as BMP, JPG, GIF, PNG, etc. Trace Background The E200S will use camera to capture the image from the table Image Settings Mode Choose which tracing mode you would like to do...
  • Page 63 Color layers Will segment the image into the specified number of colors Contrast This value will determine the cutoff to whether parts of the image should be traced. When you adjust the contrast value, the preview will change to a black and white image showing what parts of the image will be traced.

  • Page 64: Engraving & Cut By Smartjob (Workflow)

    7.2.4 Engraving & Cut by SmartJOB (E200S only) Step 1. Place the GCC Material to E200S machine. Step 2. Open the SmartJOB software and import the file which you’d like to process. Step 3. After loading the file, please click “Capture Table” to take a photo of working table. 232004160G(03)
  • Page 65 Step 4. The capture picture will display in the working area of SmartJOB. Step 5. Click the file list, the processing parameter window will display automatically make the user to set parameter for the file. 232004160G(03)
  • Page 66 Step 6. Parameter setting is ok, press print to process the engraving job. Step 7. If you have adjusted the parameter, you can save the parameter into the material database and name it yourself. Step 8. The parameter will be saved to “Customer Parameter Database” as below 232004160G(03)
  • Page 67 Step 9. Here you can also do the export parameter data or import data. 232004160G(03)

  • Page 68: The Laserpro E200S Print Driver

    7.3 The LaserPro E200S Print Driver With the LaserPro E200S print driver successfully installed, you will need to adjust the printer and page size default settings before you can begin editing and completing jobs. By doing so, you will be setting the work area in your graphics software to match the LaserPro E200S’s worktable area.

  • Page 69: Page Setup And Orientation

    7.3.1 Page Setup and Orientation The first thing you must do before working with the LaserPro E200S Print Driver will be to make sure the page and layout settings are properly configured within your graphics software. You will need to access and edit the Page Setup or Layout page of your graphics software to set your graphics software’s page layout to match the LaserPro E200S’s work table’s dimensions and orientation.
  • Page 70 Click “Get page size from printer” button to set a correct page size. If you cannot get a correct page size, please make sure that the E200S print driver has been set to the default printer. Instead of manually selecting the Landscape and setting the Paper Width and Height, you can simply click the “Set From Printer”...

  • Page 71: Color Management

    7.3.2 Color Management The LaserPro driver uses pen color settings to control laser engraver’s engraving and cutting parameters. In addition to having your Page Setup and Orientation properly set in your graphics software, you will need to make sure Color Management is DISABLED prior to working with the LaserPro E200S Print Driver.

  • Page 72: Using The Laserpro E200S Print Driver

    7.3.3 Using the LaserPro E200S Print Driver Now after you have properly set the Page and Layout and Color Management of your graphics software, you are ready to configure the details of your actual job through the LaserPro E200S Print Driver. The LaserPro E200S print driver allows you to adjust your engraving / cutting options.

  • Page 73: Using The Laserpro E200S Print Driver >> Pen Page

    7.3.4 Using the LaserPro E200S Print Driver >> Pen Page Mode Setting [DEFAULT SETTING: Black & White] You can select four primary mode settings, depending on your application or results you would like to achieve. Black & White: Select this mode when using clipart images or drawings with several colors, shades of gray, or many outlines.
  • Page 74 The Black & White mode interprets the processed image by the varying colors and shades. For the best results, we suggest you convert the image to a grayscale image with your graphics software prior to engraving in the Black & White mode. NOTE Selecting the Black &...
  • Page 75 NOTE Outputting a full-table (25.1" x 18.1") job using 300 or 600 DPI will result in a truncation error; this is due to the large differences in set DPI vs. actual DPI output for those two particular DPI settings. Therefore, when processing a 25.1" x 18.1" job using 300 DPI, we recommend you move to the next higher DPI setting of 380.
  • Page 76 PEN [DEFAULT SETTING: Speed 50, Power 50, PPI 400] The LaserPro E200S incorporates the use of 5 different colors to represent 5 different laser power and speed settings when cutting and engraving. These colors are referred to as “Pen”. Think of each pen as a designated laser setting, rather than as a color.
  • Page 77 Power (Pen Page) [DEFAULT SETTING: 50] The power slider controls the laser’s power during operation (engraving/cutting power) with a range setting from 0 – 100%. The percentage setting represents the power for each laser pulse fired. The lower the power setting, the shallower it engraves or cuts, and vice-versa. The power slider controls the laser’s power during operation (engraving /cutting power) with a range setting from 0 100% (PWM signal provided by the mainboard).
  • Page 78 need to select the pen color that you have assigned to the sections to be cut and select the Air checkbox for those particular pen colors. Position Modes [DEFAULT SETTING: Home] These selections allow you to control the positioning of the laser head after each job completion and before the next subsequent job.
  • Page 79 Image Output Direction [DEFAULT SETTING: Top To Bottom] These selections allow you to control the direction in which the system processes an engraved image. Selecting this will force the system to process the current task by moving the laser Top to Bottom carriage from the top to the bottom of the image (rear end to front end of the work table).
  • Page 80 Halftone [DEFAULT SETTING: Dithering] This option controls the way a raster-engraved image is processed. The “digital image to engraved output” process can be processed via two methods: Dithering or Error Diffusion. Each offer additional output options yielding different output effects, style, and quality. ...
  • Page 81  Enhance Dithering [DEFAULT SETTING: Unselected] Selecting this will produce a finer dithering output. ✓ Error Diffusion (Raster Page): Interprets and outputs the raster engraving via the error diffusion method. This mode will allow you to select from three diffusion types: Floyd, Stucki, and Jarvis. ✓...
  • Page 82 Pitch (Stamp Page) Your stamp will be a reversed image composed of engraved depressions and ridges. Think of these ridges as the "contact sections" of the stamp. If the ridges of these contact sections are too thin, they may break. The Pitch setting allows you to increase the width of the ridge base, hence creating more stable "contact sections"...

  • Page 83: The Laserpro E200S Print Driver

    7.4 The LaserPro E200S Print Driver 7.4.1 Navigation Chart of E20S Touch Panel 232004160G(03)

  • Page 84: Main Work Page

    7.4.2 Main Work Page When the LaserPro E200S is powered on, the machine will perform a series of safety checks and initializing routines. The Touch Panel screen will display the GCC copyright, LaserPro logo, and machine initialization pages before going to the main work page. The main work page is the page that the LaserPro E200S will default to upon startup and will be the “home base”...

  • Page 85: Function Page

    7.4.3 Function Page • Machine Setting Page – this page allows you to do LED light setting, reset and offset tuning. • Advanced Option – this page allows you to view laser status and origin position. • Information Page – this page allows you to view information regarding the system such as the GCC logo, machine name, firmware version, and other information.

  • Page 86: File Management Page

    7.4.4 File Management Page To manage the edited file to adjust / set up the parameters File Information Page File Edit Page 232004160G(03)

  • Page 87: File Management Page >> File Edit Raster Page

    7.4.5 File Management Page >> File Edit Raster Page The File Edit Raster Page allows you to edit the raster power and speed settings. These settings correspond to the same settings found on the LaserPro E200S driver. This page allows you to easily adjust these values to make immediate adjustments while processing your loaded jobs, even when you have disconnected your computer from the LaserPro E200S ...

  • Page 88: File Management Page >> File Edit Vector Page

    7.4.6 File Management Page >> File Edit Vector Page The File Edit Vector Page allows you to edit the vector pen, vector power, vector speed, and vector PPI, and power ramp settings for the selected job. These settings correspond to the same settings found on the LaserPro E200S driver.

  • Page 89: Machine Setting

    7.4.7 Machine Setting The Machine Setting Page allows you to access and modify various machine settings, including: Others (Air Delay), Offset tuning, LED light setting, Reset. 232004160G(03)

  • Page 90: Other Page >> Air Delay Setting Page

    7.4.8 Other Page >> Air Delay Setting Page The Air Delay setting allows you to specify the delay in seconds of the SmartAIR air-assist after the point of laser firing. • Air Delay: 1-100 seconds Depending on the material you are engraving with, your laser settings, and the desired results, please experiment with the air delay to achieve your desired results.

  • Page 91: Offset Tuning

    7.4.9 Offset Tuning The trace file offset page allows you to adjust the offset for trace file , you can tuning the trace file by using this function. 7.4.10 LED Light Setting The LED setting page allows you to set the lightness of LED, lever: 1~5 232004160G(03)

  • Page 92: Reset Page

    7.4.11 Reset Page The Reset Page will restore machine settings back to factory default. Press ENTER to confirm the change and restart the machine. 232004160G(03)

  • Page 93: Machine Information Page

    7.4.12 Machine Information Page The Machine Information Page allows you to view information regarding the system such as the GCC logo, machine name, firmware version, and other information. 7.4.13 Advanced Option The advanced page allows you to enable different usages for the laser machine, such as Laser Status – to reset laser firing time, Origin Position setting.

  • Page 94: Advanced Option >> Laser Status

    7.4.14 Advanced Option >> Laser Status Reset Laser Firing time, you will have to enter the password to reset the Laser Fired time 7.4.15 Advanced Option >> Origin Position The Origin Position Page allows you to reset the origin position by defining the current X-axis and Y-axis positions.

  • Page 95: Chapter 8 Optional Items

    Chapter 8 Optional Items Fume extraction System Air Compressor Rotary Attachment 232004160G(03)

  • Page 96: Fume Extraction System Option

    When purchasing the LaserPro E200S from your local authorized GCC distributor, you will be provided a chance to purchase optional items to enhance your experience with your system. If anytime after the purchase of your LaserPro E200S, would you like to purchase any optional item, please contact your local authorized GCC distributor.
  • Page 97 There is a 4” odor reduction tubing adaptor that comes with E200S machine which is the accessory box. Connect the 4” diameter adaptor to the ventilation opening located on the rear side of GCC E200S machine. (As shown in the picture below). Try to keep this tubing as straight as possible as bends reduce the exhaust efficiency.

  • Page 98: Air Compressor

    8.2 Air Compressor Specifically designed for laser engravers, the air compressor utilizes an oil-free diaphragm. The air compressor helps to eliminate harmful and potentially damaging moisture from the laser optics, maximizing life of the laser optics. In addition, the air compressor provides an optimal airflow to the SmartAIR nozzles to minimize flaming, suppress working temperatures, and blow away dust and particle by products generated from the laser process.
  • Page 99 Connect a 1/4" tubing to the pressure relief valve of the compressor. NOTE It is important that the 1/4" air tubing has clean, straight cuts on each end. Jagged or slanted cuts will not produce adequate sealing capabilities. Plug the air compressor’s power cord into the “For Air Compressor” power socket. Plug the female end of power cord to the power cord B socket.
  • Page 100 Congratulations, you have finished setting up the air compressor. Make sure you have the proper SmartAIR nozzle installed (depending on your application), before you turn on and utilize the air compressor. Air Flow Regulator: Air tube Fastener ⚫ Turn clockwise to increase airflow ⚫...

  • Page 101: Rotary Attachment Option

    8.3 Rotary Attachment Option The rotary attachment option provides the E200S with the ability to engrave on cylindrical or spherical objects. In addition to the standard X, Y, Z axis, the rotary attachment allows for a fourth axis which rotates your object 360° to allow for engraving on cups, wine glasses, and even spherical objects. Work Piece Limitations Maximum Length 250 mm (10 inches)
  • Page 102 ⚫ GCC design two axle-center for E200S rotary attachment to enlarge the availability object sizes. Follow the procedure to exchange the front fixture and back fixture: Remove the two screws holding the fixtures. Exchange the front fixture and back fixture as below picture. Before After 232004160G(03)
  • Page 103 NOTE Align the origin point to the flat top of shaft then tighten the first screw against it, following to tighten the second screw. Flat Top Origin Point 1. Align the origin to flat shaft, then tighten this screw against it 2.
  • Page 104 2) Take out the grid cutting table as shown below 3) Grid cutting table uninstallation is completed. b. Installation of E200S Rotary Attachment 1) Turn off the power of the laser engraver 2) Open the front panel of the machine, lower the working platform to its bottom. 3) When placing the rotary attachment on the working table, the rotary attachment can only apply the small conical fixtures to work with small objects of diameters.
  • Page 105 6) Connect the rotary attachment cable to the rotary attachment port located inside the machine (shown in the picture below) 7) Close the front door panel. 8) The rotary attachment is now properly installed. 9) Power on the LaserPro E200S and the rotary attachment will be automatically detected, and the engraving table will automatically move to its lowest position.
  • Page 106 5) At the Paper Page, the first thing is to check the “Rotary Fixture” option. The Paper Size and Rotary Parameter will change to allow for proper input based on the rotary attachment setup. 6) Under Paper Size column, the X value represents the length of the work piece. Enter the length of your work piece in this field A.
  • Page 107 7) Go back to other pages of GCC Laser Print Driver to set up laser parameters like speed, power, and dpi etc. (refer to Chapter V of user manual for print driver operation details) and click “OK” to print your design to the laser machine. 8) Despite the dummy-proof installation design, please ensure that the rotary device is installed correctly before turning on the machine.

  • Page 108: Chapter 9 Basic Maintenance

    Chapter 9 Basic Maintenance Suggested Cleaning and Maintenance Supplies Maintaining the Work Table and Motion System Cleaning the Optics System 232004160G(03)

  • Page 109: Suggested Cleaning And Maintenance Supplies

    Keeping your LaserPro E200S clean and well maintained will ensure quality output, consistent reliability, and extended product life. Smoke, dust or residue build-up inside the laser system or the mechanical components can cause a reduction in the laser power, irregularities in the motion system, reduced product life cycle, and a host of other avoidable problems.

  • Page 110: Maintaining The Worktable And Motion System

    *The recommended lens cleaner is TIFFEN Lens Cleaner. You can go through the following link to get more information. Tiffen Lens Cleaner 1.25 oz - EK1767136T – The Tiffen Company 9.2 Maintaining the Worktable and Motion System 9.2.1 Cleaning the Worktable and Motion System Clean the working table and the motion system on weekly basis through the following steps: Turn the power off and unplug the E200S before cleaning.

  • Page 111: Lubrication Of The X / Y Rails

    9.2.2 Lubrication of the X / Y Rails In order to keep the motion system running smoothly, the X / Y rails of the motion system will need lubrication on a weekly basis. Use a small amount of light grade machine oil or PS2 grease to a paper or cotton towel and apply to the rails.

  • Page 112: Removing And Cleaning The Focal Lens

    CAUTION! If the center of the mirror is scratched, contact your LaserPro E200S dealer for a replacement. 9.3.2 Removing and Cleaning the Focal Lens 1) Remove the thumb screw on lens carriage and slide out the focal lens. 2) Clean the focal lens with a cotton swab and lens cleaner solution. Be sure to clean both sides of the focal lens (DO NOT apply any pressure or other cleaning solutions to the lens surface).

  • Page 113: Chapter 10 Appendix

    Chapter 10 Appendix GCC LaserPro E200S Series Specification Sheet 232004160G(03)

  • Page 114: Gcc Laserpro E200S Specification Sheet

    10.1 GCC LaserPro E200S Specification sheet Model GCC E200S GCC E200SL GCC E200SM Work Area 510 x 330 mm (20 x 12.9 in.) 520 x 340 x 20 mm (20.4 x 13.4 x 0.78 in.) (with grid cutting table) Maximum Part Size (WxLxH) 505 x 340 x 76 mm (19.8 x 13.4 x 2.99 in.) (remove grid cutting table) CCD Camera Standard, accurate within 4mm (0.16 in.)
  • Page 115 Facility Requirements Electrical 100-240VAC, 50-60Hz Auto Switching, Max. 15A External exhaust system with minimum flow rate 300 m /h (10594 ft /min) is required, 2,500PA Air Exhaust System negative pressure (Pure-Air PA-300 @ 4" exhaust port)  Speed does not equal to throughput. See dealer or visit www.GCCworld.com for more details.
