SMC Networks HRR Series Manual

Circulating Fluid Temperature Controller
Thermo-chiller
HRR
Series
Air-cooled Refrigeration
Operable without the need to
remove the unit from the rack
Front access
Simple to control, service,
and maintain with all filters
and drainage accessible via
the front panel
Bypass valve
Particle filter
(Standard)
Cooling capacity
Temperature stability
Global power supply
Monitoring Software
Thermo-chiller
Can conduct all setting operations as well as
monitor the operating status
Rack Mount Type
Water-cooled Refrigeration
Space saving
Multiple chillers can be
mounted to a 19-inch rack.
∗1 Refer to page 229 for details on 19-inch
racks.
DI filter
(Option)
(Standard)
1.1/1.2/1.8/2.4/3.0/5.1 kW
±0.1°C
100 VAC
Single-phase
(50/60 Hz)
200 to 230 VAC
Single-phase
380 415 VAC
3-phase to
(50/60 Hz)
¡USB 2.0 type B
¡Compatible OS: Windows 7/10
(.NET Framework 3.5 or higher)
∗ A dedicated driver is required to use with Windows 7.
¡Supported languages:
English, German, Japanese, French,
Italian, Russian, Spanish, Turkish,
Chinese, Korean
221
mm
Equivalent to 5U
∗
(EIA standards 1
310
Fluid fill
mm
port
Equivalent to 7U
∗
(EIA standards 1
Drain port
399
mm
Equivalent to 9U
∗
1
(EIA standards
(60 Hz)
/115 VAC
(60 Hz)
(50/60 Hz)
460 480 VAC
, to
(60 Hz)
710
mm
Equivalent
to 16U
∗
(EIA standards 1 )
HRR050-A
(UL Standards)
∗ Refer to page 233 for
applicable models.
)
)
)
Air-cooled
228
