- Page 1 DICENTIS Wireless Conference System Installation manual...
-
Page 3: Table Of Contents
Wireless Access Point (DCNM-WAP) Wireless Devices (DCNM-WD and DCNM-WDE) Battery Pack (DCNM-WLIION) Charger (DCNM-WCH05) High Directive Microphone (DCNM-HDMIC) Microphones (DCNM-MICx) Appendices 10.1 Product labels for South Korea and the Philippines Bosch Security Systems B.V. Installation manual 2025-03 | 2.4 |... -
Page 4: Safety
Do not step or stand on the surface of the transport case when the devices are inside. – File a complaint with the carrier if the devices are damaged during the carrier transport. 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual... -
Page 5: Frequency Bands And Power Output Specifications For European Red Directive (2014/53/Eu)
DCNM‑WD – DCNM‑WDE – DCNM‑WAP Warning! Changes or modifications made to this equipment, not expressly approved by Bosch Security Systems B.V. may void the user’s authority to operate the equipment. Bosch Security Systems B.V. 2025-03 | 2.4 | Installation manual... -
Page 6: Statement For Brazil
Local authority wireless approval Although the DICENTIS Wireless Conference System operates in a license-free band, it is subject to local certification regulations. Please contact your nearest Bosch representative for more information on the regulations for your country. 2025-03 | 2.4 | Bosch Security Systems B.V. -
Page 7: About This Manual
For information on getting permission for reprints and excerpts, contact Bosch Security Systems B.V.. The content and illustrations are subject to change without prior notice. -
Page 8: Document History
System overview: Information on connecting the DICENTIS Wireless Conference System to the DICENTIS Conference System. – Installation Wireless Access Point: Possibility of connecting the WAP to the Ethernet switch of the DICENTIS Conference System. 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual... -
Page 9: System Overview
PC is not required for operational use, it can be disconnected from the system after licensing/updating the system software). – a Battery Pack Charger (6). Figure 3.1: Typical DICENTIS Wireless Conference System Bosch Security Systems B.V. 2025-03 | 2.4 | Installation manual... - Page 10 (both to be ordered separately). – Participants can use the Wireless Device Extended to participate in a discussion. Charger (DCNM‑WCH05): used to charge the Battery Packs of the Wireless Devices. 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual...
- Page 11 In/Out connectors of both the primary and secondary WAP. – If access to the API (for showing voting results) and web browser settings is required, make sure Ethernet cables are connected to both the primary and secondary WAP. Bosch Security Systems B.V. 2025-03 | 2.4 | Installation manual...
- Page 12 Provides power to the DICENTIS devices via PoE. Wireless Access Point: – Central component of the wireless system. – When connected to the Ethernet switch, allows the connection between the wireless and the wired systems. 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual...
-
Page 13: Extended System Requirements
> Country of your choice > Conference Systems > DICENTIS Wireless Conference System > HD cameras and accessories) – Onvif Profile-S compatible cameras, tested with Bosch IP4000 and IP5000 and Lumens VC-A50P. – Support for Sony IP cameras via CGI commands for 300/360 series: Sony SRG-300SE/301SE and SRG-360SHE. -
Page 14: Planning
Unpacking This equipment should be unpacked and handled with care. If an item appears to be damaged, notify the shipper immediately. If any items are missing, notify your Bosch representative. The original packaging is the safest container in which to transport products and can be used to return products for service if necessary. - Page 15 The scan is only valid for that specific location, so check multiple positions in the meeting room. – Only the network presence is shown, not the data intensity in the channels. – Check if there are WiFi networks that belong to the venue. Bosch Security Systems B.V. 2025-03 | 2.4 | Installation manual...
-
Page 16: Coverage Area
– For a maximum Wi-Fi coverage area, the DCNM‑WAP should be placed on a central location in the room. – The DCNM‑WAP has a typical Wi-Fi coverage distance of 30 m. 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual... - Page 17 30 meters is the maximum distance if there is a direct line of sight. Obstacles between the Wireless Access Point and the devices will reduce this distance. Preferred location: on the ceiling Bosch Security Systems B.V. 2025-03 | 2.4 | Installation manual...
-
Page 18: Installation Planning
DICENTIS Wireless Conference System Configuration manual for more information. Installation planning Make sure you have all components for installing and connecting the DICENTIS Wireless Conference System (see System overview, page 9). 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual... - Page 19 Conference System (see System overview, page 9 and the paragraphs Control capacity and Coverage area in this section). – Use only Bosch specified installation materials and tools (see Additional components, page 20). Determine the end‑user requirements, typical questions are: –...
-
Page 20: Additional Components
CAT5e cables - These cables are required if you want to connect a PC/Laptop to the Wireless Access Point (DCNM‑WAP) for running the web browser interface and connecting a switch and HD Conference Domes. 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual... -
Page 21: Installation Wireless Access Point
AC plug‑EU, AC plug‑US, GE24I48‑R7B Mounting bracket DVD with manuals and software Safety instructions Brand logo The orientation of the logo could be changed. TORX 10 Figure 5.1: Change logo orientation Bosch Security Systems B.V. 2025-03 | 2.4 | Installation manual... - Page 22 Connect the Ethernet (PoE) (2) or AC/DC power supply adapter (3). For detailed connection description, see the “Power on / connection and indicator” paragraph at the end of this section. 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual...
- Page 23 Installation Wireless Access Point | en Wall or ceiling installation Use the mounting bracket to attach the Wireless Access Point to a wall or ceiling. TORX 10 Figure 5.3: Mounting to a wall or ceiling Bosch Security Systems B.V. 2025-03 | 2.4 | Installation manual...
- Page 24 | Installation Wireless Access Point DICENTIS Tripod floor stand installation Use the mounting bracket to install the Wireless Access Point on a Bosch LBC1259/01 universal tripod floor stand. Figure 5.4: Mounting on a tripod floor stand 2025-03 | 2.4 | Bosch Security Systems B.V.
- Page 25 Tip: Live (+) Ring: Return (-) Sleeve: Shield Balanced audio line input socket: Connection from audio source. Use standard line output cabling. 6.3 mm (1/4") jacks with the following pinning: Bosch Security Systems B.V. 2025-03 | 2.4 | Installation manual...
- Page 26 8 seconds to set all settings to factory default. Refer to – Planning, page 14 – Additional components, page 20 – System overview, page 9 – System design planning, page 14 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual...
-
Page 27: Installation Wireless Devices And Accessories
Follow below steps to install the required accessories to, and placing of, the Wireless Devices. These steps are a summary: Check that all equipment is available. For your reference, see the Wireless Device figure and table in this section. Bosch Security Systems B.V. 2025-03 | 2.4 | Installation manual... - Page 28 Wireless Device and Wireless Access Point is removed. (DCNM‑WLIION) Battery Pack capacity test button. See Battery Pack, page 30. (DCNM‑WLIION) Battery Pack capacity LED (5x) indicators. See Battery Pack, page 30. 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual...
-
Page 29: Microphones
Figure 6.1: DCNM‑HDMIC or DCNM‑MICx to Wireless Device connection Both the DCNM‑HDMIC High Directive Microphone and DCNM-MICL/S Stem Microphone are typically used with the DICENTIS devices. Figure 6.2: DCNM‑HDMIC and DCNM‑MICS / DCNM‑MICL front and bottom view Bosch Security Systems B.V. 2025-03 | 2.4 | Installation manual... -
Page 30: Battery Pack
5% (LEDs 1/2). Refer to Charger, page 33. – Empty battery packs must be charged within 30 days. – Do not leave an empty Battery Pack in a Wireless Device. 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual... - Page 31 How to install the Battery Pack Figure 6.4: Wireless Device bottom view including Battery Pack Figure 6.5: DCNM‑WLIION Battery Pack top (1) and rear (3) view. Remove the attachable microphone. Turn the Wireless Device up‑side‑down. Bosch Security Systems B.V. 2025-03 | 2.4 | Installation manual...
- Page 32 LED 1: <3 NOTE: The accuracy of the Battery Pack remaining capacity is +/- 20%. Securing nock (3x). Secures the Battery Pack in the Wireless Device. Power supply and charging connector. 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual...
-
Page 33: Charger
NOTE: It can take up to 1 minute before the first LED is lit. Power on/off LED: Is on when the power cable is connected to Charger and the other end is connected to the mains power supply. Bosch Security Systems B.V. 2025-03 | 2.4 | Installation manual... - Page 34 Caution! Do not obstruct the ventilation grilles. A blockage of the ventilation grilles can cause a risk of fire and malfunction/defect of the Charger and Battery Pack. 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual...
- Page 35 The Charger (DCNM‑WCH05) must be fixed installed to the wall by qualified service personnel, using the supplied mounting bracket. Disassembly is also only allowed by qualified service personnel. TORX 10 TORX 10 Figure 6.7: Installation to a wall Bosch Security Systems B.V. 2025-03 | 2.4 | Installation manual...
- Page 36 If the mains power supply is 100‑127 V(AC), 50/60 Hz, a maximum of 2 Chargers can be looped‑through. – If the mains power supply is 220‑240 V(AC), 50/60 Hz, a maximum of 5 Chargers can be looped‑through. 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual...
- Page 37 The LEDs (3) showing the charging level of the Battery Pack. – Remove the Battery Pack as soon it is fully charged (All LEDs (3) are on). Refer to – Charger (DCNM-WCH05), page 46 Bosch Security Systems B.V. 2025-03 | 2.4 | Installation manual...
-
Page 38: System Power On And Configuration
Wireless Access Point and Wireless Devices. – For documentation, refer to the DICENTIS Wireless Conference System product related information on: www.boschsecurity.com > Country of your choice > Conference Systems > DICENTIS Wireless Conference System 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual... -
Page 39: Maintenance
Inspect components Check all DICENTIS Wireless Conference System components for signs of wear and tear. Replacement products can be ordered from your Bosch representative, if required. Check the Wireless Devices microphone buttons for correct operation. They should not be loose or stick when operated. -
Page 40: Technical Data
Ceiling, Wall or Tripod floor stand (using included bracket) Dimensions (H x W x D) 285 x 202 x 65 mm with bracket (11.2 x 8.0 x 2.6 in) Weight: with bracket 958 g (2.11 lb) without bracket 725 g (1.60 lb) Color Light grey (RAL 000 7500) 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual... - Page 41 DICENTIS Technical data | en Environmental Operating temperature 5 ºC to +45 ºC (41 ºF to +113 ºF) Storage and transport temperature -20 ºC to +70 ºC (-4 ºF to +158 ºF) Relative humidity < 95 %, > 5 % Bosch Security Systems B.V. 2025-03 | 2.4 | Installation manual...
-
Page 42: Wireless Devices (Dcnm-Wd And Dcnm-Wde)
Dimensions (H x W x D) without 72 x 259 x139 mm microphone (2.8 x 10.2 x 5.5 in) Weight: DCNM‑WD 590 g (1.30 Lb) DCNM‑WD + Battery Pack 1051 g (2.32 lb) Color (top and base) Traffic black (RAL 9017) 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual... - Page 43 Nominal microphone input 80 dB SPL Maximum microphone input 110 dB SPL Audio outputs Loudspeaker nominal output 72 dB SPL at 0.5 m Loudspeaker maximum output 80 dB SPL Headphone nominal output 0 dBV Headphone maximum output 3 dBV Bosch Security Systems B.V. 2025-03 | 2.4 | Installation manual...
- Page 44 1131 g (2.49 lb) Color (top and base) Traffic black (RAL 9017) Environmental Operating temperature 5 ºC to +45 ºC (41 ºF to +113 ºF) Storage and transport temperature -20 ºC to +70 ºC (-4 ºF to +158 ºF) Relative humidity < 95 %, > 5% 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual...
-
Page 45: Battery Pack (Dcnm-Wliion)
Weight 460 g (1.0 lb) Color Charcoal Environmental Operating temperature 5 ºC to +45 ºC (41 ºF to +113 ºF) Advised storage and transport -5 ºC to +35 ºC temperature (23 ºF to +95 ºF) Relative humidity <75 %, >5 % Bosch Security Systems B.V. 2025-03 | 2.4 | Installation manual... -
Page 46: Charger (Dcnm-Wch05)
Weight (without batteries) 1.8 kg (3.97 lb) Color Traffic black (RAL 9017) Environmental Operating temperature 5 ºC to +45 ºC (41 ºF to +113 ºF) Storage temperature -20 ºC to +70 ºC (-4 ºF to +158 ºF) Relative humidity < 95 %, > 5 % 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual... -
Page 47: High Directive Microphone (Dcnm-Hdmic)
Traffic black RAL 9017 Pearl light grey RAL 9022 Environmental Operating temperature 0 ºC to +45 ºC (32 ºF to +113 ºF) Storage and transport temperature -20 ºC to +70 ºC (-4 ºF to +158 ºF) Relative humidity < 95 %, > 5% Bosch Security Systems B.V. 2025-03 | 2.4 | Installation manual... -
Page 48: Microphones (Dcnm-Micx)
Traffic black RAL 9017 Pearl light grey RAL 9022 Environmental Operating temperature 0 ºC to +45 ºC (32 ºF to +113 ºF) Storage and transport temperature -20 ºC to +70 ºC (-4 ºF to +158 ºF) Relative humidity < 95 %, > 5% 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual... -
Page 49: Appendices
DICENTIS Appendices | en Appendices 10.1 Product labels for South Korea and the Philippines DCNM WAP label DCNM WD label DCNM WDE label Bosch Security Systems B.V. 2025-03 | 2.4 | Installation manual... - Page 50 | Appendices DICENTIS 2025-03 | 2.4 | Bosch Security Systems B.V. Installation manual...
- Page 52 Bosch Security Systems B.V. Torenallee 49 5617 BA Eindhoven Netherlands www.boschsecurity.com © Bosch Security Systems B.V., 2025 Building solutions for a better life 202503281658...
