T&S EVERSTEEL SMPK-2LSN-06 Installation And Maintenance Instructions

Installation and
Maintenance
Instructions
STAINLESS STEEL
SINGLE LEVERS
Limited Lifetime Warranty
(Commercial Applications)
T&S warrants to the original purchaser (other than for purposes of resale) that such product is free from
defects in material and workmanship for its limited lifetime. During this warranty period, if the product is
found to be defective, T&S shall, at its options, repair and/or replace it. To obtain warranty service, products
must be returned to...
T&S Brass and Bronze Works, Inc.
Attn: Warranty Repair Department
2 Saddleback Cove
Travelers Rest, SC 29690
Shipping, freight, insurance, and other transportation charges of the product to T&S and the return
of repaired or replaced product to the purchaser are the responsibility of the purchaser. Repair and/or
replacement shall be made within a reasonable time after receipt by T&S of the returned product. This
warranty does not cover Items which have received secondary finishing or have been altered or modified
after purchase, or for defects caused by physical abuse to or misuse of the product, or shipment of the
products.
Any express warranty not provided herein, and any remedy for Breach of Contract which might arise,
is hereby excluded and disclaimed. Any implied warranties of merchantability or fitness for a particular
purpose are limited in duration to the warranty period provided on the product. Under no circumstances
shall T&S be liable for loss of use or any special consequential costs, expenses or damages.
Some states do not allow limitations on how long and implied warranty lasts or the exclusion or limitation
of incidental or consequential damages, so the above limitations or exclusions may not apply to you. Specific
rights under this warranty and other rights vary from state to state.
Attention California Residents:
WARNING This product can expose you to chemicals including Lead, Chromium
(hexavalent compounds) and Phthalates (DEHP) which are known to the State of California
to cause cancer and birth defects or other reproductive harm.
For more information go to
www.P65Warnings.ca.gov.
P/N: 098-021107-45ES Rev.0
DATE: 08-08-23
DRAWN: TED
CHECKED: JMD 06-06-24
APPROVED: JHB 06-06-24
Step 1:
Insert flex line inlets and tighten by hand. Apply
plumber's putty to underside of body and insert into
mounting hole. With wrench, tighten the locking nut.
Step 3:
For Pre-Rinse Units: make sure the EasyInstall®
locking washer is seated properly inside the faucet
body.
For Faucets: remove the EasyInstall® locking washer.
Step 5:
Lock the EasyInstall® locking nut in place. Tighten
with wrench.
Step 2:
For Pre-Rinse Units: apply plumber's tape to top of
riser threads and attach to spring assembly. Tighten
with wrench.
Step 4:
For Pre-Rinse Units: place riser assembly into faucet
body.
For Faucets: place the swing nozzle into faucet body.
Press down until the end-fitting "pops" in.
lock washer
