T&S B-2701 Series Installation And Maintenance Instructions Manual

T&S B-2701 Series Installation And Maintenance Instructions Manual

Single lever faucets with or without pop-up

Advertisement

Available languages

Available languages

Quick Links

Limited One Year Warranty
T&S warrants to the original purchaser (other
than for purposes of resale) that such product is
free from defects in material and workmanship
for a period of one (1) year from the date of
purchase. During this one-year warranty period,
if the product is found to be defective, T&S shall,
at its options, repair and/or replace it. To obtain
warranty service, products must be returned
to...
T&S Brass and Bronze Works, Inc.
Attn: Warranty Repair Department
2 Saddleback Cove
Travelers Rest, SC 29690
Shipping, freight, insurance, and other
transportation charges of the product to T&S
and the return of repaired or replaced product
to the purchaser are the responsibility of the
purchaser. Repair and/or replacement shall be
made within a reasonable time after receipt by
T&S of the returned product. This warranty does
not cover Items which have received secondary
fi nishing or have been altered or modifi ed after
purchase, or for defects caused by physical
abuse to or misuse of the product, or shipment
of the products.
Any express warranty not provided herein, and
any remedy for Breach of Contract which might
arise, is hereby excluded and disclaimed. Any
implied warranties of merchantability or fi tness
for a particular purpose are limited to one year in
duration. Under no circumstances shall T&S be
liable for loss of use or any special consequential
costs, expenses or damages.
Some states do not allow limitations on how
long and implied warranty lasts or the exclusion
or limitation of incidental or consequential dam-
ages, so the above limitations or exclusions may
not apply to you. Specifi c rights under this war-
ranty and other rights vary from state to state.
P/N: 098-013122-45 Rev.5
Date: 03-09-11
Drawn: TEH
Checked: DMH 03-11-11
Approved: JHB 03-16-11
Installation and
Maintenance
Instructions
B-2701, B-2703,
B-2710 & B-2711
SERIES
SINGLE LEVER FAUCETS
(with or without Pop-Up)

Advertisement

loading

Summary of Contents for T&S B-2701 Series

  • Page 1 Installation and Maintenance Instructions Limited One Year Warranty T&S warrants to the original purchaser (other than for purposes of resale) that such product is free from defects in material and workmanship for a period of one (1) year from the date of purchase.
  • Page 2: Exploded View

    Exploded View B-2701 & B-2703 Series...
  • Page 3 Exploded View B-2710 & B-2711 Series...
  • Page 4: Part Number Guide

    Part Number Guide Asm, Single Lever Rigid Base Faucet B-2701 Asm, Single Lever Rigid Base Faucet w/ 4” Deckplate B-2703 Asm, Single Lever Faucet w/ Pop-Up Drain B-2710 Asm, Single Lever Faucet B-2711 Gasket, Waterproof 014167-45 Lock Washer 000999-45 Lock Nut 016673-45 Kit, Lock Washer and Lock Nut 014166-45...
  • Page 5: General Instructions

    General Instructions Faucet Installation (B-2701 & B-2703) o-ring (Refer to diagram on page 2) pop-up drain stopper 1. Shut off water supply lines. Drill a 1-1/2” stem diameter hole in countertop where no.5 will be installed. fl ange screw 2. Clean countertop and bottom of no.5. Ap- ply putty to bottom of no.5.
  • Page 6 General Instructions 5. Replace pop-up drain stopper in drain body, with ‘o’-ring in place, and align stopper hole with guide and opening. drain 6. Reinsert rod ball assem- stopper bly back into drain body and through hole in drain stopper. fl...
  • Page 7 General Instructions 1. Remove no.7, then using no.8, loosen set screw and lift off no.6. 2. Adjust no.10 to desired position per below. Figure 1 Using needle Normal factory nose pliers, care- set position fully lift off the allows full mix- temperature limit ing of hot and stop ring from the...
  • Page 8: Instrucciones Generales

    Instrucciones Generales Anillo de caucho Instalación de la canilla: Tapón 1. Cierre la fuente principal de agua y Tallo desagüe las tuberías. Limpie muy bien la superfi cie del lavatorio. Reborde Tornillo 2. Instale la parte No.5 con la parte No.2 Arandela de sobre la cubierta o el lavatorio.
  • Page 9 Instrucciones Generales 5. Coloque de nuevo el tapón en el cuerpo de desagüe, con el anillo de caucho en su sitio y alinee el hueco del tapón con el guia y la avertura. 6. Insarte de nuevo el ensamble de la varilla con bola en el cuerpo Tapón de desagüe y a través del hueco Reborde...
  • Page 10 Instrucciones Generales 1. Remueva la parte No.7, luego afl oje el tornillo de presión utilizando la parte No.8, y remueva la parte No.6 alzándola. 2. Ajuste la parte No.10 a la posición deseada como lo indica abajo. Dibujo 1 Cuidadosamente La posición levante la argolla ajustada en la...
  • Page 11 Maintenance: 1. To change no.10, remove no.7 by hand. 2. Insert no.8 into hole of no.6 and loosen set screw of no.6. Remove no.6. 3. Unscrew no.12 and remove. 4. Unscrew no.11 and remove. 5. Remove no.10 and replace with new no.10. 6.
  • Page 12 B-2730 & B-2731 Single Lever Faucets T&S BRASS AND BRONZE WORKS, INC. A fi rm commitment to application-engineered plumbing products 2 Saddleback Cove, P.O. Box 1088 T & S Brass-Europe Travelers Rest, SC 29690 ‘De Veenhoeve’ Phone: (864) 834-4102 Oude Nieuwveenseweg 84 Fax: (864) 834-3518 2441 CW Nieuwveen...

This manual is also suitable for:

B-2703 seriesB-2730B-2710 seriesB-2731B-2711 series
