About the Brickstream 3D Gen 2 Sensor
The sensor captures behavior and tracks physical movements that provide a basis for analytical
algorithms, enabling it to generate traffic metrics, queue metrics, and service metrics in a single sensor
for retail outlets, malls, transportation hubs, and smart buildings.
The sensor:
Has two camera lenses
n
Uses CMOS (complementary metal-oxide semiconductor) image sensors for Wide VGA, High
n
Dynamic Range (HDR) images
Uses LINUX operating system (OS)
n
Provides on-board processing and data storage
n
Adjusts automatically to environmental changes (i.e., lighting and temperature)
n
Is IP addressable for remote management and support, including firmware upgrades
n
Uses proven advanced stereo vision and patented path tracking technology to:
n
Collect and store metrics at one minute granularity
n
Can distinguish between adults, children, and shopping units and present them as distinct
n
data metrics
Filter objects based on height, shape, and size (e.g., children, shopping carts, strollers,
n
etc.)
Provide robust and accurate metrics across a broad set of environments (e.g.,
n
indoor/outdoor and high traffic)
Provides optional Wi-Fi and BLE support with a USB Wi-Fi BLE dongle (2510 model only - dongle
n
sold separately)
Hardware Components
The Brickstream sensor is boxed and shipped to a customer. To properly install the sensor, we
recommend the purchase of an industry standard 802.3af PoE System. Depending on the method and
location for installing the sensor, suitable mounting hardware is required (recessed mount, RAM
mount, or outdoor mount). Mounting hardware is purchased separately.
The following image provides a diagram of the Brickstream sensor.
