Summary of Contents for AUDAC VIRO5
- Page 1 User manual VIRO5 audac.eu...
- Page 2 This manual is put together with much care, and is as complete as could be on the publication date. However, updates on the specifications, functionality or software may have occurred since publication. To obtain the latest version of both manual and software, please visit the Audac website @ www.audac.eu. REV-1.7...
-
Page 3: Table Of Contents
Pole mount � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 014 Technical specifications VIRO5 - User manual... - Page 4 VIRO5 - User manual...
-
Page 5: Introduction
The combination of the cloth, sealing rubbers and drainage holes on the bottom of the speaker make it IP55 compliant. The VIRO loudspeaker is available in Black (/B) or White (/W). VIRO5 - User manual... - Page 6 Please dispose this product at your local collection point or recycling centre for electrical and electronic waste. This will make sure that it will be recycled in an environmentally friendly manner, and will help to protect the environment in which we all live. VIRO5 - User manual...
-
Page 7: Connections And Connectors
Chapter 1 Connections and connectors CONNECTION STANDARDS The in- and output connections for AUDAC audio equipment are performed according to international wiring standards for professional audio equipment 4-Pin Terminal block: For signal input and output linking connections VIRO5 - User manual... -
Page 8: Overview Viro: Back
2) Drop safety bushing the drainage holes. The VIRO5 has a M6 safety bushing. This provides the Install VIRO at a minimum down tilt of 5°. Standing water is option of mounting drop safety wires. Please check your local avoided trough this installation. - Page 9 The correct polarity is indicated above the connector. Make sure that the polarity is correct throughout the system. VIRO5 - User manual...
-
Page 10: Chapter 3 010
Always use the proper fasteners depending of the mounting surface. Once the bracket is mounted on the desired location, the loudspeaker can be fixed to the bracket. 198,00 110,00 70,00 VIRO5 - User manual... -
Page 11: Chapter 4 011
Multiple VIROs can be connected in parallel. Mind the minimum load impedance of the amplifier. The number of VIRO’s to be connected will depend whether 8 (VIRO5) or 16 (VIRO5D) Ohm variants will be used.. Make sure that all devices are switched off. -
Page 12: Chapter 5 012
Installing the optional transformer module (TRV106) 1. Big rubber washer 2. Transformer 3. Small rubber washer 4. Recessed mounting dish 5. Spring washer 6. Mounting bolt - M8 x 55 Connecting diagram 70V/15W 70V/30W 100V/30W 70V/60W 100V/60W 8Ω 16Ω VIRO5 - User manual... -
Page 13: Optional Mounting Accessories
The use of tools such as hammers, drills etc. may damage the ground pin. Mount the speaker to the ground pin by securing it with the four M6 bolts provided. The mounting holes on the ground pin are tapped, making the use of nuts unnecessary. VIRO5 - User manual... -
Page 14: Pole Mount
Tighten by closing the hose clamp. Mount the loudspeaker to the pole mount by securing it with the four M6 bolts provided. The mounting holes on the pole mount are tapped, making the use of nuts unnecessary. VIRO5 - User manual... -
Page 15: Technical Specifications
Dimensions (w x h x d) 198 x 235 x 191 mm Weight 4.2 Kg Optional accessories 70-100V transformer module TRV106 SpeakON connection plate CVS102 Ground pin MBK523/G Pole mount MBK530 Steel drop safety wire (gripple) STG601 VIRO5 - User manual... - Page 16 Discover more on audac.eu...
