Model 50 Central Controller,
Model 51 Control Console,
and Related Components
User Guide
Issue 4, July 2000
This User Guide is applicable for systems consisting of:
Model 50, serial number M50-00133 and later;
Model 51, serial number M51-00336 and later;
or Model 51 units upgraded to software
part number 7946, version 1.01 and higher
© 2000 by Studio Technologies, Inc., all rights reserved
5520 West Touhy Avenue
Skokie, Illinois 60077 U.S.A.
Telephone (847) 676-9177
.ax (847) 982-0747
www.studio-tech.com
50060-700, Issue 4
