4. Installation
4.1. How to link your LoRa device with the receiver:
Follow the next steps:
1.Download the Anemotracker Configurator app from the App Store or Anemotracker
Configure & Update from the Play Store.
2.Turn on your LoRa and receiver device.
3. Open the app and swipe up. All nearby devices will appear. You can filter by direction or
name.
4.Your device will be listed as "LORA-RECVR". Click on its name.
5. At the bottom of the page, you can link a new LoRa device to your receiver by pressing the
"+" button and selecting the LoRa device you want to link.
6.To remove a linked LoRa device, press the "-" icon.
7.After making your changes, click "Configure" to save the settings.
4.2. Installing the App and testing the unit
Follow the next steps:
1. Make sure your device is BLE compatible*. · Ultra Low Power LoRa works with Android 4.3
and beyond or iOS devices (4s, iPad2 or beyond).
2. Download and install Anemotracker App on your device from Google Play or Apple Store.
3. Once the App is installed start it and open the settings menu by sliding the screen to the
rigth.
4. Press the" Scan" button and all Ultra Low Power LoRa devices within the range should show
up at screen.
5. Select your device and connect.
