DEMO MANUAL DC2867A
PARTS LIST
ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 1 C2
3 1 C8
4 1 C9
5 1 C12
6 1 C15
7 1 FB1
8 1 L1
9 2 R1, R4
10 1 R2
11 1 R3
12 1 R5
13 1 U1
Additional Demo Board Circuit Components
1 0 C5
2 0 C6
3 0 C3, C10
4 0 C14
5 0 R6, R7
Hardware: For Demo Board Only
1 10 E1-E10
2 1 JP1
3 1 JP2
4 1 XJP1, XJP2
5 4 MP1-MP4
4
PART DESCRIPTION
CAP ., 22µF, ALUM. ELECT., 63V, 20%, 6.3x7.7mm, CE-BS
CAP ., 1µF, X7R, 50V, 10%, 0603
CAP ., 0.01µF, X7R, 16V, 10%, 0603
CAP ., 4.7µF, X5R, 6.3V, 10%, 0603
CAP ., 0.1µF, X7R, 50V, 10%, 0603
CAP ., 22µF, X5R, 16V, 10%, 1206
IND., 300Ω, FERRITE BEAD, 25%, 250mA, 0402, AEC-Q200
IND., 47µH, PWR, SHIELDED, 30%, 0.39A, 940mΩ, 3816
RES., 1M, 1%, 1/10W, 0603, AEC-Q200
RES., 18.2k, 1%, 1/10W, 0603, AEC-Q200
RES., 49.9k, 1%, 1/10W, 0603
RES., 187k, 1%, 1/10W, 0603, AEC-Q200
IC, 42V 120mA BUCK REGULATOR, LQFN-12
CAP ., 10pF, C0G, 16V, 5%, 0603, OPT
CAP ., 10µF, X5R, 6.3V, 20%, 0603, OPT
CAP ., 1µF, X7R, 50V, 10%, 0805
CAP ., OPTION, 0603
RES., OPTION, 0603
TEST POINT, TURRET, 0.094" MTG. HOLE, PCB 0.062" THK
CONN., HDR, MALE, 1x3, 2mm, VERT, ST, THT, NO SUBS.
ALLOWED
CONN., HDR, MALE, 2x4, 2mm, VERT, ST, THT
CONN., SHUNT, FEMALE, 2 POS, 2mm
STANDOFF , NYLON, SNAP-ON, 0.50"
MANUFACTURER/PART NUMBER
SUN ELECTRONIC INDUSTRIES CORP , 63CE22BS
AVX, 06035C105KAT2A
AVX, 0603YC103KAT2A
KEMET, C0603C475K9PACTU
AVX, 06035C104KAT2A
AVX, 1206YD226KAT2A
MMZ1005Y301CTD25
WURTH ELEKTRONIK, 744031470
VISHAY, CRCW06031M00FKEA
PANASONIC, ERJ3EKF1822
NIC, NRC06F4992TRF
PANASONIC, ERJ3EKF1873V
ANALOG DEVICES, LT8604CAV#TRMPBF
MILL-MAX, 2501-2-00-80-00-00-07-0
WURTH ELEKTRONIK, 62000311121
WURTH ELEKTRONIK, 62000821121
WURTH ELEKTRONIK, 60800213421
WURTH ELEKTRONIK, 702935000
