DEMO MANUAL DC2861A
PARTS LIST
ITEM QTY REFERENCE
Required Circuit Components
1 4 C1, C3, CIN1, CIN5
2 2 C2, CIN6
3 1 C4
4 1 CIN2
5 1 CIN3
6 1 COUT1
7 1 COUT2
8 1 COUT3
9 1 R3
10 2 R4, R6
11 1 R11
12 1 U1
Additional Demo Board Circuit Components
1 0 C5, C6, C7, C12
2 0 C11, CIN4
3 1 L1
4 1 Q1
5 0 R12
6 3 C8, C9, C10
7 1 R13
8 1 R14
9 1 RS1
Hardware: For Demo Board Only
1 8 E1, E2, E3, E4, E5, E6,
E7, E8
2 5 J1, J2, J3, J4, J5
3 2 J6, J7
4 1 JP1
5 1 JP8
6 4 MP1, MP2, MP3, MP4
7 2 XJP1, XJP8
6
PART DESCRIPTION
CAP ., 10μF, X7R, 16V, 10%, 0805
CAP ., 150μF, ALUM POLY, OS-CON, 10V, 20%, 8mm × 6.9mm
CAP ., 0.1μF, X7R, 6.3V, 10%, 0603
CAP ., 22μF, X5R, 10V, 20%, 0603
CAP ., 22μF, X5R, 16V, 10%, 0805
CAP ., 22μF, X5R, 6.3V, 20%, 0603
CAP ., 22μF, X5R, 6.3V, 20%, 0805
CAP ., 100μF, X5R, 6.3V, 20%, 0805
RES., 100k, 1%, 1/10W, 0603
RES., 60.4k, 1%, 1/10W, 0603, AEC-Q200
RES., 0Ω, 1/10W, 0603, AEC-Q200
IC, 5.5V , 10A μModule in 4mm × 4mm PACKAGE, BGA
IN
CAP ., OPTION, 0603
CAP ., OPTION, 0805
IND., 100Ω AT 100MHz, FERRITE BEAD, 25%, 8A, 6mΩ, 1812
XSTR., MOSFET, N-CH, 30V, 5.5A, SOT-23-3
RES., OPTION, 0603
CAP ., 1μF, X7R, 16V, 10%, 0603
RES., 10k, 1%, 1/10W, 0603, AEC-Q200
RES., 10Ω, 1%, 1/10W, 0603
RES., 0.02Ω, 1%, 1W, 1206, PWR, METAL, SENSE, AEC-Q200
TEST POINT, TURRET, 0.094" MTG. HOLE, PCB 0.062" THK
CONN., BANANA JACK, FEMALE, THT, NON-INSULATED,
SWAGE, 0.218"
CONN., RF , BNC, RCPT, JACK, 5-PIN, ST, THT, 50Ω
CONN., HDR, MALE, 1×3, 2mm, VERT, ST, THT, NO SUBS.
ALLOWED
CONN., HDR, MALE, 2×3, 2mm, VERT, ST, THT
STANDOFF , NYLON, SNAP-ON, 0.50"
CONN., SHUNT, FEMALE, 2-POS, 2mm
MANUFACTURER/PART NUMBER
TAIYO YUDEN, EMK212BB7106MG
PANASONIC, 10SVP150MX
AVX, 06036C104KAT2A
AVX, 0603ZD226MAT2A
TDK, C2012X5R1C226K125AC
MURATA, GRM188R60J226MEA0D
KEMET, C0805C226M9PACTU
MURATA, GRM21BR60J107ME15K
STACKPOLE ELECTRONICS, INC.,
RMCF0603FG100K
VISHAY, CRCW060360K4FKEA
VISHAY, CRCW06030000Z0EAHP
ANALOG DEVICES, LTM4658EY#PBF
WURTH ELEKTRONIK, 74279226101
VISHAY, Si2338DS-T1-GE3
KEMET, C0603C105K4RAC7867
VISHAY, CRCW060310K0FKEA
VISHAY, CRCW060310R0FKEA
VISHAY, WSLP1206R0200FEA
MILL-MAX, 2501-2-00-80-00-00-07-0
KEYSTONE, 575-4
AMPHENOL RF , 112404
WURTH ELEKTRONIK, 62000311121
WURTH ELEKTRONIK, 62000621121
KEYSTONE, 8833
WURTH ELEKTRONIK, 60800213421
