- Page 1 USER GUIDE X RANGE WATERPROOF LITHIUM BATTERIES...
-
Page 2: Table Of Contents
CONTENTS Product Overview Overview Key Features Package Contents Getting Started Installation Bluetooth Wiring Diagrams Discharge Curve Storage Safe Mode Optimising your Charging Specifications Product Dimensions Safety Precautions Certifications Contact Us Back Page... -
Page 3: Product Overview
OVERVIEW The iTechworld X Range represents the pinnacle of deep cycle lithium battery design. These batteries are equipped with a pre-installed Battery Management System that enables compatibility with a wide range of charging systems, making them well-suited for use in boats, caravans, motor-homes, RVs, and more. With an IP67 rating, they are also waterproof and dustproof, making them suitable for under-the-bonnet use. -
Page 4: Getting Started
GETTING STARTED INSTALLATION Your iTechworld X Range battery boasts an impressive IP67 rating, making it suitable for installation in a wide range of environments. Here' s what you need to know: The X Range battery can be installed in any orientation, except for upside down (with terminals facing down). -
Page 5: Parallel Connection
PARALLEL CONNECTION SERIES CONNECTION... -
Page 6: Discharge Curve
DISCHARGE CURVE Please note that a lithium battery’ s discharge curve will differ from your previous lead acid batteries. Please refer to the discharge curve graph to better understand how a lithium battery will perform. X Range Discharge Curve 0.1C Load 15.0 14.0 13.0... -
Page 7: Storage
STORAGE When your iTechworld X Range battery is not in use, it is recommended to completely isolate the battery, charge it to 13.5V and check the voltage every 3 months, then charge the battery as needed. To ensure your battery is completely isolated, it is essential to disconnect it from any connected devices or systems. - Page 8 • Disconnect all loads/inputs from the battery. • Connect the iTechworld battery in parallel to a different battery. • Connect an ACDC charger to the battery at the same time as the paralleled battery and allow it to begin charging. We recommend a three-stage 20A or higher charger.
-
Page 9: Optimising Your Charging
OPTIMISING YOUR CHARGING Embedded within every iTechworld battery lies a sophisticated Battery Management System (BMS) which sets our batteries apart from conventional lead- acid, calcium, or even other lithium batteries. This BMS enables the battery to accept a broad range of charging profiles, including Lead Acid, Gel and AGM, making it versatile for various charging systems. -
Page 10: Specifications
Life Cycles @ 80% Depth of Discharge 5,000 Life Cycles @ 40% Depth of Discharge 10,000+ Terminal Type Case Material For more information on specifications please visit our website and select your iTechworld X Range battery. Scan to visit our website... -
Page 14: Safety Precautions
Disclaimer: While iTechworld has taken every precaution to ensure the accuracy of the contents of this user guide, iTechworld assumes no responsibility for any errors or omissions. Furthermore, all specifications and functionality may change at any time without notice. -
Page 15: Certifications
LIMITATIONS OF USE: Do not use in connection with life support systems or other medical equipment or devices. CERTIFICATIONS Our iTechworld X Range batteries are in compliance with the following standards and certifi cations: UL1642 Australian IEC62133... -
Page 16: Contact Us
When it comes to energy storage and creation at iTechworld, we take pride in being one of the biggest names in the industry. Based in Australia, we are a family-owned and operated business. With many more innovative products on the horizon we are committed to constantly raising the bar to provide bigger and better benefi ts to all our customers Australia-wide.
