- Page 1 USER GUIDE STANDARD RANGE LITHIUM BATTERIES...
-
Page 3: Table Of Contents
CONTENTS Product Overview Overview Key Features Package Contents Getting Started Installation Discharge Curve Wiring Diagrams Storage Safe Mode Optimising your Charging Product Dimensions Back Page... -
Page 4: Product Overview
Australian design and development • LiFePO4 battery • Compact and lightweight • Heavy duty ABS casing • High discharge rate • iTechworld BMS • Over discharge protection (Safemode) • A grade cylindrical cells Package Contents 1x iTechworld Standard Range Battery... -
Page 5: Getting Started
GETTING STARTED INSTALLATION Standard Range batteries can be installed in any orientation, except for upside down (with terminals facing down). DISCHARGE CURVE Please note that a lithium battery’ s discharge curve will differ from your previous lead acid batteries. Please refer to the discharge curve graph to better understand how a lithium battery will perform. -
Page 6: Parallel Connection
PARALLEL CONNECTION SERIES CONNECTION... -
Page 7: Storage
STORAGE When your iTechworld Standard Range battery is not in use, it is recommended to completely isolate the battery, charge it up to 13.5V and check the voltage every 3 months, then charging the battery as needed. To ensure your battery is completely isolated, it' s essential to disconnect it from any connected devices or systems. - Page 8 • Disconnect all loads/inputs from the battery. • Connect the iTechworld battery in parallel to a different battery. • Connect an ACDC charger to the battery at the same time as the paralleled battery and allow it to begin charging. We recommend a three-stage 20A or higher charger.
-
Page 9: Optimising Your Charging
OPTIMISING YOUR CHARGING Embedded within every iTechworld battery lies a sophisticated Battery Management System (BMS) which sets our batteries apart from conventional lead- acid, calcium, or even other lithium batteries. including Lead Acid, Gel and AGM, making it versatile for various charging systems. -
Page 10: Specifications
Up to 48V (4 x batteries) Parallel Connection Up to 4 batteries Life Cycles @ 80% Depth of Discharge 2,000+ Life Cycles @ 40% Depth of Discharge 4,000+ Terminal Type Case Material iTechworld Standard Range battery. Scan to visit our website... - Page 11 151.5mm 65.5mm 42mm 181mm 77mm 122mm...
- Page 12 228mm 138mm 180mm 333mm 176mm 266mm...
-
Page 13: Safety Precautions
Disclaimer: While iTechworld has taken every precaution to ensure the accuracy of the contents of this user guide, iTechworld assumes no responsibility for any errors or omissions. without notice. - Page 14 WARNING: Do not disassemble or modify the battery; doing so may result in a risk of electrical WARNING: Do not use this battery in series or parallel with another battery of different chemistry or capacity. WARNING: Do not leave the battery in Safe Mode for longer than 7 days. WARNING: Don’t ignore any warning signs that may appear throughout use of the battery (e.g.
- Page 15 1300 483 249 service@itechworld.com.au www.itechworld.com.au When it comes to energy storage and creation at iTechworld, we take pride in being one of the biggest names in the industry. Based in Australia, we are a family-owned and operated business. With many more innovative products on the horizon we are committed to constantly raising the bar to Whether you’re an avid camper, 4WD enthusiast , freedom seeker or...
