General Installation Considerations and Precautions for Windlass ......................7 Control Panel Installation..................................8 Measurements ......................................9 Visual Wiring Diagram ................................... 10 Sleipner Group Waste Disposal and Recycling Guide .......................... 12 Service and Support................................... 13 Product Spare Parts and Additional Resources ..........................13 Warranty Statement .................................... 13...
• Keep the engine running during windlass operation to ensure good battery capacity. • Sleipner Motor AS is not responsible for damage or injury caused by the use of our windlass systems. • While dropping anchor, do not push the “UP” button until the anchor is resting at the seabed.
To ensure a long battery lifetime, the remote control switches off automatically 4 min. after the last button was pressed. (NB: Remote and receiver is normally connected and ready to use. See own manual for more information and variants.) RCT-21 RCT-22 RCT-23 Control Panels 86-08950 & 86-08955 6666 2025...
After the first stop is detected and pull is resumed by repressing the “up” again and the controller will pull the anchor in at reduced speed and with a lower allowable pull until the second stop is registered. At this point, the anchor should rest in the bracket without unnecessary high tension on the rope, windlass, fasteners etc. MG_0376 Control Panels 86-08950 & 86-08955 6666 2025...
Double ‘ON’ buttons to activate the control panel Control Panel 86-08955 Lower anchor Raise anchor Double ‘ON’ buttons to activate the control panel 'OFF' button to deactivate the control panel MG_0401 Control Panels 86-08950 & 86-08955 6666 2025...
When planning the installation of Sleipner products, ensure easy access to the products for future service and inspection requirements. For Sleipner Windlass systems: MC_0424 Always use original Sleipner rope. (NB: While dropping anchor, do not push the “UP” button until the anchor is resting at the seabed.) • •...
Insert the control panel in place and fasten screws. (NB: Add grease to the nut threads and fasten slowly to prevent galling.) Insert the control panels covering caps. Gasket Screws Cables Gasket Cover caps Screws Cables MG_0402 Control Panels 86-08950 & 86-08955 6666 2025...
A+B+C+D+E+F <6m : 25mm2 A+B+C+D+E+F=6-16m : 35mm2 A+B+C+D+E+F>16m : 50mm2 Autostop Sensor Motor (Not applicable for chain) To change motor direction: Change cables D1 and D2 on motor Maxi MG_0403 Control Panels 86-08950 & 86-08955 6666 2025...
Page 11
Cable size A,B and C : f total length A+B+C <10m : 25mm2 A+B+C >10m : 35mm2 Autostop sensor (opt.) Motor Mini/Midi To change motor direc�on: Change cables D1 and D2 in control box MG_0404 Control Panels 86-08950 & 86-08955 6666 2025...
Introduction: At Sleipner Group, we prioritize sustainability and encourage the repair and re-manufacturing of products to extend their life cycles. If disposal is necessary, please follow these guidelines to recycle and manage waste responsibly, ensuring our efforts align with environmental protection efforts.
11. This warranty gives you specific legal rights, and you may also have other rights which vary from country to country. Patents MC_0024 At Sleipner we continually reinvest to develop and offer the latest technology in marine advancements. To see the many unique designs we have patented, visit our website www.sleipnergroup.com/patents Control Panels 86-08950 & 86-08955...
