SLEIPNER AS
P.O. Box 519
N-1612 Fredrikstad
Norway
www.sleipnergroup.com
To download your language go to www.sleipnergroup.com
User Manual
Including Installation Guide for Control Panels
PJC421 & PJC422
DOCUMENT ID:
6770
REVISION:
2
DATE:
2021
EN
LANGUAGE:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PJC421 and is the answer not in the manual?

Questions and answers

Related Manuals for Sleipner PJC421

Summary of Contents for Sleipner PJC421

  • Page 1 User Manual Including Installation Guide for Control Panels PJC421 & PJC422 DOCUMENT ID: SLEIPNER AS 6770 REVISION: P.O. Box 519 DATE: N-1612 Fredrikstad 2021 Norway LANGUAGE: www.sleipnergroup.com To download your language go to www.sleipnergroup.com...

  • Page 2: Table Of Contents

    Warranty Statement ................................40 Products PJC421-PVREL - Single joystick, twist detent, thruster control and S-link Color LCD touch screen PJC421-PVREL-DNV - Single joystick, twist detent, thruster control and S-link Color LCD touch screen PJC421-LE90 - Single lever, detent, thruster control and S-link Color LCD touch screen...

  • Page 3: Responsibility Of The User Operating Thrusters

    Failure to follow the considerations and precautions can cause serious injury, damage and will render all warranties given by Sleipner Motor as VOID. MC_0411 Responsibility of the User Operating Thrusters MC_0418 Never use thrusters when close to objects, persons or animals in the water. The thruster will draw objects into the tunnel and the rotating propellers.

  • Page 4: Panel Layout & Functions

    Activating the stern thruster *Bow thruster installation only *Stern thruster installation only Activating both bow and Activating both bow and stern thruster to push the stern thruster to rotate the boat sideways boat on axis MG_0459 PJC421 & PJC422 6770 2021...

  • Page 5: Technical Specifications

    IEC 60068-2-30 Salt mist IEC 60068-2-52, Kb Compass Safe Distance 0.2m IEC 61000-4-8:2010 ISO 25862: 2009 Internal buzzer sound level IEC 60945:2002 External buzzer sound level IEC 60945:2002 Display weight 260g Display size 3.5 inch PJC421 & PJC422 6770 2021...

  • Page 6: Control Panel - Thruster Dashboard View

    If thrust from a remote panel is higher, it will be indicated with a light blue coloured bar. Indication of thrust from Indication of thrust from joystick connected to remote joystick connected to panel panel PJC421 & PJC422 6770 2021...
  • Page 7 Sliding bar for adjustment and indication of confi gured backlight level Indication of confi gured backlight level in % The backlight level can be adjusted with 1% resolution using the slide bar on the touch screen. PJC421 & PJC422 6770 2021...

  • Page 8: Control Panel - Alarms

    Alarm list, audible alarm signal active Push Mute active alarms on one TP-35 to mute the audible alarm signals on all Sleipner control panels that are turned on and connected to the S-Link bus. Unmuted alarms are listed in red, and muted alarms are listed in dark blue. Active alarms are not automatically cleared, even if the alarm state is no longer present in the device.
  • Page 9 Pressing the STOP button with a hydraulic controller connected to the S-Link bus will activate the dump valve and all hydraulic consumers will be disabled. The STOP Activated message will be displayed on all Sleipner control panels that are turned on. PJC421 & PJC422...

  • Page 10: Control Panel - Menu Navigation

    Panel Settings Lists TP-35 serial number and fi rmware version. Joystick Select joystick type and perform calibration. Settings Station Control Only available on DNV product variants. Activate and confi gure the transfer of command functionality. Settings PJC421 & PJC422 6770 2021...
  • Page 11 The load sharing will dynamically limit the thrust request for each thruster depending on the joystick position and limit settings. For a detailed explanation and setup guide, see AC series thruster user manual, document ID 6054. PJC421 & PJC422 6770...
  • Page 12 Set the running direction for the bow thruster. Bow Thrust • Normal (default) Direction • Swapped Set the running direction for the stern thruster. Stern Thrust • Normal (default) Direction • Swapped Panel settings Lists TP-35 serial number and fi rmware version. PJC421 & PJC422 6770 2021...
  • Page 13 Calibrate a connected single Danfoss PVREL joystick. PVREL Dual Danfoss Calibrate a connected dual Danfoss PVREL joystick. PVREL Single Lilaas LE90/LF90/ Calibrate a connected single Lilaas LE90/LF90/LF90X joystick. LF90X Dual Lilaas LE90/LF90/ Calibrate a connected dual Lilaas LE90/LF90/LF90X joystick. LF90X PJC421 & PJC422 6770 2021...
  • Page 14 Follow the on-screen instructions to calibrate the joystick. It is important to keep the joystick in the specifi ed position while pressing . Below is an example of the steps for calibrating a dual joystick. Abort joystick calibration and return to Joystick Setting menu. Confi rm current calibration step. PJC421 & PJC422 6770 2021...
  • Page 15 A failure on the S-Link power supply will suspend thruster operation from the control panel. If the auxiliary power supply falls outside rated voltage ratings, an alarm will be triggered, but thruster operation will be allowed. PJC421 & PJC422 6770...
  • Page 16 MC_0407 Display of motor RPM and gear leg low oil level alarm Sleipner’s Thruster Monitoring Unit-1 (TMU-1) must be installed and connected to the S-Link bus to display motor RPM and gear leg low oil level alarm on TP-35. The thruster motor must be equipped with an RPM sensor connected to TMU-1. An oil tank with a level switch must be installed and connected to TMU-1.
  • Page 17 10 seconds. If the operator aligns the joysticks while this notice is displayed, command is taken, and an audible signal is given. If the joysticks are not aligned during the time the notice is displayed or the notice is manually closed, the workstation continues to be NOT IN COMMAND. Closes the notice. Joysticks Command is transferred. aligned PJC421 & PJC422 6770 2021...
  • Page 18 When command is released, an audible signal will be given to indicate that the state of the control panel has changed from IN COMMAND to NOT IN COMMAND. If command is released when thrusters are running, the thrusters will stop. Release command. PJC421 & PJC422 6770 2021...

  • Page 19: Phc-3 Fault Codes

    Digital Output 6 is confi gured as crossover and output is open "-Check for open circuit, power consumption < 5.0 Watt 10515.0.13 PHC DOUT 6 - Open Circuit circuit -Output confi gured wrong, parameter 0506" PJC421 & PJC422 6770 2021...
  • Page 20 VFD Instance 1 No Communication Lost communication with VFD -On the VFD make sure the RS485 BUS TERMINATION is in ON position" 36103.1.0 VFD IN LOCAL Instance 1 - VFD in local mode -Switch VFD to remote mode PJC421 & PJC422 6770 2021...

  • Page 21: Pdc-301 Fault Codes

    Lost Power Management signal from VFD, VFD not available 36101.1.204 VFD PMS Instance 1 SIGNAL LOST -Check VFD for more information. anymore. 36103.1.0 VFD IN LOCAL Instance 1 - VFD in Local or Hand Mode -Change mode in VFD panel. PJC421 & PJC422 6770 2021...

  • Page 22: Responsibility Of The Installer

    Sleipner products. If you are interfacing the S-Link™ bus by agreement with Sleipner through a designated Sleipner supplied interface, you are still required to install at least one original Sleipner control panel to enable efficient troubleshooting if necessary.

  • Page 23: Tp-35 Control Panel Installation

    Ensure the panel should be mounted 20 cm away from any compass to ensure that the accuracy of the compass is not affected. If the panel is mounted in an weather exposed location mounting the covering is recommended when the panel is not used. Top Mount Flush Mount MG_0463 PJC421 & PJC422 6770 2021...

  • Page 24: Tp-35 Control Panel Top Mount Installation

    *Optional X1 Joystick: Required. Connect cable from joystick X2 S-Link: Required. Connect cable from S-Link bus X3 I/O: Optional See Detailed IO Description MG_0464 section for more information. PJC421 & PJC422 6770 2021...

  • Page 25: Tp-35 Control Panel Flush Mount Installation

    Front surface Apply sealant on the milled surface. *Optional X1 Joystick: Required. Connect cable from joystick X2 S-Link: Required. Connect cable from S-Link bus X3 I/O: Optional See Detailed IO Description MG_0465 section for more information. PJC421 & PJC422 6770 2021...

  • Page 26: Measurements Tp-35 Top Mount

    Measurements TP-35 Flush Mount MC_0392 TP-35 Flush Mount Measurement Measurement description code inch Panel Height 120.5 Panel width Raised height above the dashboard 0.26 Depth behind the dashboard (not inc. cables) 23.5 Cable bend radius Flush mount MG_0475 PJC421 & PJC422 6770 2021...

  • Page 27: Pjc421-Pvrel Control Panel Installation

    PJC421-PVREL Control Panel Installation MC_0396 Place the supplied cut-out template on the desired installation location. Cut out the area according to the template. Plug cable into the cable/ connector at the rear of the TP-35 control panel. (NB: During the TP-35 panel installation this cable may already be attached if access to the back side of the control panels is impossible.)

  • Page 28: Pjc421-Pvrel Measurements

    PJC421-PVREL Measurements MC_0387 PJC421 Measurement Measurement description code inch Panel Height 123.4 Panel width 105.5 Raised height above the dashboard 111.3 Depth behind the dashboard (not inc. cables) 94.7 Cable bend radius MG_0435 PJC421 & PJC422 6770 2021...

  • Page 29: Pjc422-Pvrel Control Panel Installation

    Joystick cables can be connected in any arrangement to the two upper sockets TP-35 cable must be connected to the lower socket Connect both joystick cables to the T-connector. Connect cable between T-connector and TP-35 (X1 Joystick). MG_0467 PJC421 & PJC422 6770 2021...

  • Page 30: Pjc422-Pvrel Measurements

    PJC422-PVREL Measurements MC_0386 PJC422 Measurement Measurement description code mm inch Panel Height Panel width Raised height above the dashboard 111.3 Depth behind the dashboard (not inc. cables) 94.7 Cable bend radius MG_0433 PJC421 & PJC422 6770 2021...

  • Page 31: Pjc421-Lf90 And Pjc422-Lf90 Control Panel Installation

    PJC421-LF90 and PJC422-LF90 Control Panel Installation MC_0396 Place the supplied cut-out template on the desired installation location. Cut out the area according to the template. Place the gasket to the back face of the panel. If the front surface around your cut out is jagged or chipped, use a sealant to assist the gasket.

  • Page 32: Pjc421-Lf90 And Pjc422-Lf90 Measurements

    PJC421-LF90 and PJC422-LF90 Measurements MC_0389 PJC421 PJC422 Measurement LF90/-DNV LF90/-DNV Measurement description code inch inch Panel Height Panel width Raised height above the dashboard 98.8 98.8 Depth behind the dashboard (not inc. cables) *PJC422-LF90 MG_0457 PJC421 & PJC422 6770 2021...

  • Page 33: Pjc421-Le90 And Pjc422-Le90 Control Panel Installation

    PJC421-LE90 and PJC422-LE90 Control Panel Installation MC_0396 Place the supplied cut-out template on the desired installation location. Cut out the area according to the template. Plug cable into the cable/ connector at the rear of the TP-35 control panel. (NB: During the TP-35 panel installation this cable may already be attached if access to the back side of the control panels is impossible.)

  • Page 34: Pjc421-Le90 And Pjc422-Le90 Measurements

    PJC421-LE90 and PJC422-LE90 Measurements MC_0390 PJC421 PJC422 Measurement LE90/-DNV LE90/-DNV Measurement description code inch inch Panel Height Panel width Raised height above the dashboard 104.7 104.7 Depth behind the dashboard (not inc. cables) 17.2 17.2 *PJC422-LE90 MG_0456 PJC421 & PJC422...

  • Page 35: Pjc421-Lf90X And Pjc422-Lf90X Control Panel Installation

    PJC421-LF90X and PJC422-LF90X Control Panel Installation MC_0396 Place the supplied cut-out template on the desired installation location. Cut out the area according to the template. Plug cable into the cable/ connector at the rear of the TP-35 control panel. (NB: During the TP-35 panel installation this cable may already be attached if access to the back side of the control panels is impossible.)

  • Page 36: Pjc421-Lf90X And Pjc422-Lf90X Measurements

    PJC421-LF90X and PJC422-LF90X Measurements MC_0391 PJC421 PJC422 Measurement LF90X/-DNV LF90X/-DNV Measurement description code inch inch Panel Height Panel width Raised height above the dashboard 112.5 112.5 Depth behind the dashboard (not inc. cables) *PJC422-LF90X MG_0458 PJC421 & PJC422 6770 2021...

  • Page 37: Detailed Io Description

    Max current consumption of buzzer: 100mA 10. Grey - DO_ISO_OUT Output voltage is equal to S-Link voltage Order number IO cable: SM908998 Order number buzzer: SM909828 Relay A MG_0481 Relay B Optional isolated relay connection Max current thru relay: 45mA PJC421 & PJC422 6770 2021...

  • Page 38: S-Link System Description

    MC_0120 S-Link is a CAN-based control system used for communication between Sleipner products installed on a vessel. The system uses BACKBONE Cables as a common power and communication bus with separate SPUR Cables to each connected unit. Units with low power consumption are powered directly from the S-Link bus therefore one power cable must be connected to the BACKBONE Cable through a T-Connector.

  • Page 39: List Of Installed S-Link Devices

    Fill in the type, location and serial numbers of the S-link devices installed. Keeping this as a reference will make the setup procedure easier! S-link device Location Serial number (ie Thruster, AMS, PPC etc) (Bow, Bow-STB, Stern, Stern-STB) PJC421 & PJC422 6770 2021...

  • Page 40: Service And Support

    10. This warranty gives you specific legal rights, and you may also have other rights which vary from country to country. Patents MC_0024 At Sleipner we continually reinvest to develop and offer the latest technology in marine advancements. To see the many unique designs we have patented visit our website www.sleipnergroup.com/patents PJC421 & PJC422...
  • Page 41 TP-35 Top Mount  13,1  13,1  96,1 83,0 78,9 95,5 PJC421 & PJC422 6770 2021...
  • Page 42 TP-35 Flush Mount Milling depth 3,5mm 4xStud positions  95,5 82,1 89,1 10,0  PJC421 & PJC422 6770 2021...
  • Page 43 PJC421-PVREL 94,5  74,0 4xØ3 PJC421 & PJC422 6770 2021...
  • Page 44 PJC422-PVREL 95,0 74,0 84,0  6xØ3 PJC421 & PJC422 6770 2021...
  • Page 45 PJC421-LF90 PJC422-LF90 4 x Ø5,5mm 17,25 44,0 78,5 PJC421 & PJC422 6770 2021...
  • Page 46 PJC421-LE90 PJC422-LE90 79,2 4xØ5,5mm 70,0  39,6 PJC421 & PJC422 6770 2021...
  • Page 47 PJC421-LF90X PJC422-LF90X 47,0 16,1 79,2 PJC421 & PJC422 6770 2021...
  • Page 48 This declaration of conformity is issued under the exclusive responsibility of the manufacturer. Fredrikstad, 20th of April 2021 Ronny Skauen, President and CEO Sleipner Bank: 5122.05.33267 A part of Sleipner Group P.O. box 519 Org. Nr.: NO 932 455 463 mva Arne Svendsensgt. 6-8 NO-1612 Fredrikstad, Norway Web: sleipnergroup.com...
  • Page 49 This declaration of conformity is issued under the exclusive responsibility of the manufacturer. Fredrikstad, 20th of April 2021 Ronny Skauen, President and CEO Sleipner Bank: 5122.05.33267 A part of Sleipner Group P.O. box 519 Org. Nr.: NO 932 455 463 mva Arne Svendsensgt. 6-8 NO-1612 Fredrikstad, Norway Web: sleipnergroup.com...
  • Page 50 Notes MC_0037 ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................PJC421 & PJC422 6770 2021...
  • Page 51 Notes MC_0037 ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................PJC421 & PJC422 6770 2021...
  • Page 52 © Copyright Sleipner Motor AS, 2021 The information given in the document was correct at the time it was published. However, Sleipner Motor AS can not accept liability for any inaccuracies or omissions it may contain. Continuous product improvement may change the product specifi cations without notice.
