CeoTronics CT-DECT Multi M7 Operating Manual page 44

11 ASR-Control (Ambient Sound Reception)
11.2 ASR in combination with CT-ClipCom Digital
Use the quick access menu of the CT-DECT Multi M7 to access the ASR function (see Quick
access menu [} 22])
The intensity of the ASR function of the CT-ClipCom Digital can be regulated in four stages.
Press the ASR button repeatedly to switch through the levels.
ASR ASR
Press to set Press to finish
desired level
This is a ring circuit: stage 4 is followed by stage 1.
The default setting is level 3 - ASR natural.
Level
Level 1
Level 2
Level 3
Level 4
NOTICE
After each restart, the ASR intensity is reset to the default setting. A change to this setting
is therefore not saved permanently.
44 / 68
Signalling sound
1x long
1x short
2x short
3x short
dok7039-en-01-0924
Feature
ASR off
ASR muffled
ASR natural
ASR amplified
