Mounting Instructions LANCOM AirLancer I-360D-5G
General notes
The LANCOM AirLancer I-360D-5G is a MIMO
Antenna capable of utilizing reflections from its
surroundings for better signal transmission from 5G/4G
frequencies. Since the antenna is an omni-directional
radiator, it does not have to be precisely aligned with the
base station of the mobile phone provider. However, it is
recommended to install the antenna close to the window
if possible. Please note: Metal-coated windows have a
negative effect on signal transmission. In this case, outdoor
antennas should be used if possible. Also the direct
proximity to metal walls can have a negative effect on the
performance of the antenna.
Placement on the desk or windowsill
The LANCOM AirLancer I-360D-5G can be easily placed on
a desk or windowsill using two fold-out feet.
Simply fold out the two feet at the bottom of the antenna
and position the antenna. For better stability, it is
recommended to run the antenna cable from the front
through the „X" shape of the antenna. For transportation of
the antenna the feet should always be folded in.
Fixing on the window
The LANCOM AirLancer I-360D-5G can be attached to the
window pane or other plain surfaces using a suction cup.
To do this, insert the suction cup of the antenna into the
keyhole-shaped recess on the back of the antenna. Then
press the antenna with the suction cup against the window
pane until a secure hold of the antenna is achieved. To
remove the antenna, it is recommended to slide the
antenna upwards out of the keyhole-shaped recess.
Afterwards the suction cup can be easily removed from
the window pane. Please note: Not all surfaces are suitable
for mounting with a suction cup. In case of temperature
changes or strong changes in air humidity, no permanent
hold can be guaranteed. Fixing with the suction cup is
therefore best for temporary applications.
