Summary of Contents for 2mag maxMIX
- Page 1 Operation Manual English maxMIX Order no.: 30501 Includes: Quick Start Operation Manual Technical Documentation Specifications Version 6.1 Issue 09/2020 www.2mag.de...
- Page 2 For any enquiries, questions or suggestions please do not hesitate to contact us at info@2mag.de. 2mag Main competence of 2mag is based upon mixing, tempering and measuring/controlling. In these fields we are offering support with our products to the modern laboratory within the standardized daily business as well as for the implementation of highly complex processes in the state-of-the-art research.
-
Page 3: Table Of Contents
4.2 Stirring operation and stirrer control _____________________ 11 4.3 Warning notices _____________________________________ 13 B Maintenance, Cleaning and Care _______________________ 14 C Service case and customer service _____________________ 15 D Errors ____________________________________________ 16 E Technical details____________________________________ 17 © 2mag AG Page 3 of 18 Version: 6.1... -
Page 4: A Quick Start
Image 1: Magnetic stirrer maxMIX Your product contains at despatch: A modern motor-driven magnetic stirring system (maxMIX) consisting of a stainless steel stirring plate with 1 stirring point. An external power supply unit (Input: 100-240 V / 50-60 Hz / 4.2 A;... -
Page 5: Application Fields
2. Application fields 2.1 Operator The maintenance-free magnetic stirrer maxMIX are used in the fields of chemistry, medicine, pharmacy, microbiology and biotechnology. The operators are generally working in research and development, production and quality assurance, where magnetic stirrers with high power are needed for e.g. -
Page 6: Vessels
The 2mag is offering special products for the just mentioned application combinations. More information for this can be found at www.2mag.de info@2mag.de 2.5 Vessels Please only use round, chemical resistant and, where required, heat- resistant vessels made of glass or non-magnetic metal. - Page 7 In case the stirring activity is too weak: Use commercial magnetic stirring bars with SamariumCobalt-core. Use a longer stirring bar or a stirring flask with smaller diameter. © 2mag AG Page 7 of 18 Version: 6.1...
-
Page 8: Installation
3. Installation 3.1 Safety advice Please ensure the following basic conditions prior to installation: The magnetic stirrer maxMIX works with extremely powerful permanent magnets. Cardiac pacemakers, data storage mediums, magnetic cards and other devices, which can be affected by magnetic fields, have to be kept away from the fields of the stirring unit as well as from the stirring bars. -
Page 9: Installation, Connection To The Power Supply Unit
The magnetic stirrer is now connected to the power supply unit and ready for operation. Image 2: Installation, rear side of the magnetic stirrer maxMIX Description functional elements of magnetic stirrer - backside Power supply unit (100-240 volts) -
Page 10: Operating Of The Magnetic Stirrer
4. Operating of the magnetic stirrer Image 3: Magnetic stirrer maxMIX Image 3: Close-up, operating elements, magnetic stirrer maxMIX 4.1 Description operating elements Magnetic stirrer maxMIX Stirrer control ON/OFF key for magnetic stirrer MODE-key (M) for acceleration adjustment of the magnetic stirrer... -
Page 11: Stirring Operation And Stirrer Control
Operating of the Magnetrührers maxMIX After the cables have been installed correctly according to Installation, connection to the magnetic stirrer, the magnetic stirrer maxMIX will be ready for operation. 4.2 Stirring operation and stirrer control Turning On and Off Please press the On/OFF-key (8) once. The magnetic stirrer will be switched on by that. - Page 12 © 2mag AG Page 12 of 18 Version: 6.1...
-
Page 13: Warning Notices
Operation in higher ambient temperatures can damage the stirring drive. The magnetic stirrer maxMIX is not suitable for using in water baths, incubators, ovens and humid atmosphere. Please ensure BEFORE you connect the power supply unit again that the socket is 100% dried! ©... -
Page 14: B Maintenance, Cleaning And Care
The control unit must not be dipped in water or any cleaning solutions. 2mag devices are generally maintenance-free. Due to their construction the 2mag devices are very robust and designed for the professional daily use. We recommend cleaning the devices’ surfaces with e.g. cleaning agents containing tensides or isopropyl alcohol regularly. -
Page 15: C Service Case And Customer Service
Web: www.2mag.de Warranty: Due to their construction, the 2mag devices are very robust and designed for the professional daily use. Should in any case, despite our strict quality control, a system part not work without any fault, it can be repaired or exchanged by our customer service without any problems. -
Page 16: D Errors
Please get into contact with us. In general, we are ready to help you in case of problems. For any enquiries, questions or suggestions please do not hesitate to contact us at info@2mag.de © 2mag AG Page 16 of 18 Version: 6.1... -
Page 17: E Technical Details
E Technical details Magnetic stirrer maxMIX maxMIX Order no. 30501 Stirring points Stirring volume/point 1 – 150 liters Stirring power (max.) 40 watts Speed range 100 – 1,200 rpm Acceleration variable, 20 - 99 s Material housing stainless-steel Material sealing Permitted operation -10 up to +50 °C (at 95% humidity) - Page 18 39 x 70 mm, Ø 45 mm Weight (gross) approx. 0.36 kg Image 6: Stirring bar ASTEROID 70 2mag AG Schragenhofstr. 35 J Fon: +49 89 38153110 DE-80992 Muenchen E-Mail: info@2mag.de GERMANY Web: www.2mag.de © 2mag AG Page 18 of 18 Version: 6.1...
- Page 20 EU-DECLARATION OF CONFORMITY FOR TECHNICAL DEVICES (acc. to EU-guideline of the electromagnetic compatibility 2014/30/EU and the low voltage directive 2014/35/EU) 2mag AG Schragenhofstraße 35 J DE-80992 Muenchen GERMANY Hereby declares that the product maxMIX is conform to the appropriate regulations of the EU-guideline of the electromagnetic compatibility (EU-guideline 2014/30/EU) as well as the low voltage directive (2014/35/EU) incl.
