- Page 1 Operation Manual English MIX 1 XL Order no.: 30201 MIX 1 XL RS232 Order no.: 30211 Includes: Quick Start Operation Manual Technical Documentation Specifications Version 6.2 Issue 02/2021 www.2mag.de...
- Page 2 For any enquiries, questions or suggestions please do not hesitate to contact us at info@2mag.de. 2mag Main competence of 2mag is based upon mixing, tempering and measuring/controlling. In these fields we are offering support with our products to the modern laboratory within the standardized daily business as well as for the implementation of highly complex processes in the state-of-the-art research.
-
Page 3: Table Of Contents
4.4.6 Control with HyperTerminal ___________________________ 20 4.4.7 Control with PuTTY __________________________________ 22 B Maintenance, Cleaning and Care _______________________ 26 C Service case and customer service _____________________ 27 D Errors ____________________________________________ 28 E Technical details____________________________________ 29 © 2mag AG Seite 3 von 30 Version: 6.1... -
Page 4: A Quick Start
Image 1: Magnetic stirrer MIX 1 XL (RS232) Your product contains at despatch: A modern motor-driven magnetic stirring system (MIX 1 XL) consisting of a stainless steel stirring plate with 1 stirring point. An external power supply unit (Input: 100-240 V / 50-60 Hz / 1.5 A;... -
Page 5: Application Fields
Safety cabinets Safety cabins 2.4 Application not for the intended use The magnetic stirrer MIX 1 XL RS232 is explicitly not intended for the application of: Stirring and warming of flammable liquids Warming of pressure-tight closed and NOT pressure- resistant vessels or glasses (e.g. -
Page 6: Vessels
The mixing flasks should be filled max. up to the middle (high speed range) resp. up to ¾ (low speed range). Never throw the stirring bar into the flask! BURSTING RISK of the flask! BURSTING RISK of the stirring bar’s magnetic core! © 2mag AG Seite 6 von 30 Version: 6.1... - Page 7 In case the stirring activity is too weak: Use commercial magnetic stirring bars with SamariumCobalt-core. Use a longer stirring bar or a stirring flask with smaller diameter. © 2mag AG Seite 7 von 30 Version: 6.1...
-
Page 8: Installation
3. Installation 3.1 Safety advice Please ensure the following basic conditions prior to installation: The magnetic stirrer MIX 1 XL (RS232) works with extremely powerful permanent magnets. Cardiac pacemakers, data storage mediums, magnetic cards and other devices, which can be... -
Page 9: Installation, Connection To The Power Supply Unit
The magnetic stirrer is now connected to the power supply unit and ready for operation. Image 2: Installation, rear side of the magnetic stirrer MIX 1 XL Description functional elements of magnetic stirrer - backside Power supply unit (100-240 volts) -
Page 10: Operating Of The Magnetic Stirrer
4. Operating of the magnetic stirrer Image 3: Magnetic stirrer MIX 1 XL Image 4: Close-up, operating elements, magnetic stirrer MIX 1 XL 4.1 Description operating elements Magnetic stirrer MIX 1 XL Stirrer control ON/OFF key for magnetic stirrer MODE-key (M) switch for adjustment of speed, power, acceleration... -
Page 11: Stirring Operation And Stirrer Control
Operating of the Magnetrührers MIX 1 XL (RS232) After the cables have been installed correctly according to Installation, connection to the power supply unit, the magnetic stirrer MIX 1 XL (RS232) will be ready for operation. 4.2 Stirring operation and stirrer control Turning On and Off Please press the ON/OFF-key (8) once. - Page 12 The current value is now shown on the display (10). „I 0“ seconds means the interval function is OFF. „I 6“ seconds is the shortest interval time. „I240“ seconds is the longest interval time. © 2mag AG Seite 12 von 30 Version: 6.1...
- Page 13 5 seconds. The acceleration adjustment is finished again at the time the speed range is shown. The acceleration adjustment can also be finished immediately by repeated pressing the MODE-key (9) again. © 2mag AG Seite 13 von 30 Version: 6.1...
- Page 14 – Stirring Bar Monitoring The Magnetic Stirrer MIX 1 XL is equipped as standard with a newly developed stirring bar control. In case of the magnetic coupling’s separation between the magnetic stirrer and the stirring bar during the acceleration phase, the magnetic stirrer will be stopped and started again and the set speed level will be reduced automatically by 100 rpm.
-
Page 15: Warning Notices
The magnetic stirrer maxMIX is not suitable for using in water baths, incubators, ovens and humid atmosphere. Please ensure BEFORE you connect the power supply unit again that the socket is 100% dried! © 2mag AG Seite 15 von 30 Version: 6.1... -
Page 16: Pc-Interface - Rs232
Pin assignment of the RS232 interface: Drawing 1: Pin-assignment RS232 interface 4.4.2 RS232 Commands The RS232-commands are ASCII coded and can be sent to the MIX 1 XL RS232 with e.g. the program HyperTerminal or PuTTY, which are coming with the Windows operation system. - Page 17 Spread sheet 2: Commands – interface RS232 Each entering of the complete command has to be finished with the ASCII code “Carriage Return (CR)”. There is no determination of small and capital letters. © 2mag AG Seite 17 von 30 Version: 6.1...
-
Page 18: Format - Command - Feedback
The manual parameters can be changed only by the keys during running in the manual mode and the remote parameter only by the RS232 interface during running in the remote mode! © 2mag AG Seite 18 von 30 Version: 6.1... -
Page 19: Control Of More Than One Units
It can be connected more than one control unit with only one interface. All control units are connected with the help of a special needed 2mag adapter box with a standard RS232 cable to the PC and to the controllers. -
Page 20: Control With Hyperterminal
ASCII configuration. For manual sending of commands via HyperTerminal the ASCII configuration must be set which is shown in screenshot 4. Screenshot 1: Startscreen Hyperterminal © 2mag AG Seite 20 von 30 Version: 6.1... - Page 21 Screenshot 2: Port Setting: 9600 bps, 8 bits, no parity, 1 Stopbit, no flow control Screenshot 3: Settings chose ASCII Setup © 2mag AG Seite 21 von 30 Version: 6.1...
-
Page 22: Control With Putty
Local echo: Force on Local line editing: Force on Category: “Connection” “Serial” Serial line to connect to: COM? Speed (baud): 9600 Data bits: 8 Stop bits: 1 Parity: None Flow control: None © 2mag AG Seite 22 von 30 Version: 6.1... - Page 23 Screenshot 5: Category: “Session” Serial line: COM? Speed: 9600 Connection type: Serial © 2mag AG Seite 23 von 30 Version: 6.1...
- Page 24 Screenshot 6: Category: “Terminal” Implicit CR in every LF Implicit LF in every CR Local echo: Force on Local line editing: Force on © 2mag AG Seite 24 von 30 Version: 6.1...
- Page 25 Screenshot 7: Category: “Connection” “Serial” Serial line to connect to: COM? Speed (baud): 9600 Data bits: 8 Stop bits: 1 Parity: None Flow control: None © 2mag AG Seite 25 von 30 Version: 6.1...
-
Page 26: B Maintenance, Cleaning And Care
The control unit must not be dipped in water or any cleaning solutions. 2mag devices are generally maintenance-free. Due to their construction the 2mag devices are very robust and designed for the professional daily use. We recommend cleaning the devices’ surfaces with e.g. cleaning agents containing tensides or isopropyl alcohol regularly. -
Page 27: C Service Case And Customer Service
Web: www.2mag.de Warranty: Due to their construction, the 2mag devices are very robust and designed for the professional daily use. Should in any case, despite our strict quality control, a system part not work without any fault, it can be repaired or exchanged by our customer service without any problems. -
Page 28: D Errors
Please get into contact with us. In general, we are ready to help you in case of problems. For any enquiries, questions or suggestions please do not hesitate to contact us at info@2mag.de © 2mag AG Seite 28 von 30 Version: 6.1... -
Page 29: E Technical Details
E Technical details Magnetic stirrer MIX 1 XL MIX 1 XL Order no. 30201 Order no. 30211 (With RS232 interface) Stirring points Stirring volume/point 500 ml – 40 liters Stirring power (max.) 20 watts Stirring power, steps 4 steps, (5/10/15/20 watts) Speed range 70 –... - Page 30 Diameter tripod construction Ø 99 mm Weight (gross) approx. 0.15 kg Image 6: Stirring bar SATELLITE 70 2mag AG Schragenhofstr. 35 J Fon: +49 89 38153110 DE-80992 Muenchen E-Mail: info@2mag.de GERMANY Web: www.2mag.de © 2mag AG Seite 30 von 30 Version: 6.1...
- Page 32 DE-80992 Muenchen GERMANY Hereby declares that the product MIX 1 XL (RS232) is conform to the appropriate regulations of the EU-guideline of the electromagnetic compatibility (EU-guideline 2014/30/EU) as well as the low voltage directive (2014/35/EU) incl. their changes and the laws for the realization of the guideline into national law.
