- Page 1 Lantech IEC-0101FT Industrial 10/100TX to 100M-FX Slim Type Converter User Manual...
-
Page 2: Fcc Warning
Lantech FCC Warning This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. -
Page 3: Table Of Contents
Lantech Content FCC Warning ............i CE Mark Warning ..........i Overview ............. 1 Introduction .............. 1 Features ..............3 Packing List .............. 4 Safety Precaution ............. 4 Hardware Description ......... 5 Front Panel ............... 5 Top View ..............6 Wiring the Power Inputs ........... - Page 4 Lantech Mounting Installation ........12 DIN-Rail Mounting ..........12 Wall Mount Plate Mounting ........14 Network Connection ......... 15 Installation Steps ............ 15 Troubles shooting ..........17 Technical Specification ........18...
-
Page 5: Overview
Lantech Overview Introduction The Industrial 10/100Base TX to 100BaseFX Media Converter is a cost-effective solution for the converting between 10/100Base-TX and 100Base-FX cabling, it allows you to extend the cabling distance of your 100Base-FX network up to 2 kilometers for multi-mode fiber or 30 kilometers for single-mode fiber. - Page 6 Lantech more reliable. Meanwhile, 6,000 V ESD protections for Ethernet ports make Industrial 10/100Base TX to 100BaseFX Media Converter more suitable for harsh environments. Wide Operating Temperature The operating temperature of the Industrial 10/100Base TX to 100BaseFX Media Converter is between -40 ~ 75...
-
Page 7: Features
Lantech Features Provides 1 x 10/100Mbps Ethernet ports with RJ-45 connector Provides 1 x SC (multi-mode & single-mode) fiber connector Supports full/half duplex flow control Supports MDI/MDI-X auto-crossover Supports surge (EFT) protection 3,000 V for power line Supports 6,000 V... -
Page 8: Packing List
Lantech Packing List 1 x Industrial 10/100BaseTX to 100BaseFX Media Converter 1 x User manual 2 x Wall Mounting Bracket and Screws 1 x DIN-rail Mounting Bracket and Screws Safety Precaution Attention IF DC voltage is supplied by an external circuit, please use a... -
Page 9: Hardware Description
Lantech Hardware Description Hardware Description In this chapter, you will be given an overview of the Industrial In this chapter, you will be given an overview of the Industrial 10/100Base TX to 100BaseFX Media Converter hardware installation 10/100Base TX to 100BaseFX Media Converter hardware installation procedures. -
Page 10: Top View
Lantech Top View The top panel of the Industrial 10/100Base TX to 100BaseFX Media Converter is equipped one terminal block connector of two DC power inputs. Top Panel of the Industrial 10/100Base TX to 100BaseFX Media Converter Wiring the Power Inputs Please follow the steps below to insert the power wire. -
Page 11: Wiring The Fault Alarm Contact
Lantech Tighten the wire-clamp screws for preventing the wires from loosing. Wiring the Fault Alarm Contact The fault alarm contact is in the middle of terminal block connector as the picture shows below. Inserting the wires, it will detect the fault status including power failure/port link failure and form an open circuit. -
Page 12: Dip-Switch
Lantech Full-duplex mode FDX/COL Yellow Flashing Packet collision occurred (fiber port) Half-duplex mode Connected to network LNK/ACT Green Flashing Networking is active (fiber port) Not connected to network Link to 100Mbps network 100M (RJ-45) Yellow Link to 10Mbps network Connected to network... -
Page 13: Ports
Lantech until entire frame is ready, but instead it forwards the received data immediately after the data being received. And TP port should be forced at 100M in this application. When DIP-Switch is in switching mode (OFF), the converter function is the same as a Switch Hub. - Page 14 Lantech cable. The table below shows the 10BASE-T/ 100BASE-TX MDI and MDI-X port pin outs. Pin MDI-X Signal Name MDI Signal Name Receive Data plus (RD+) Transmit Data plus (TD+) Receive Data minus (RD-) Transmit Data minus (TD-) Transmit Data plus (TD+)
-
Page 15: Cabling
Lantech ATTENTION This is a Class 1 Laser/LED product. Don’t stare into the Laser/LED Beam. Cabling Twisted-pair segment can be connected with unshielded twisted pair (UTP) or shielded twisted pair (STP) cable. The cable must comply with the IEEE 802.3u 100Base TX standard for Category 5. The cable between the converter and the link partner (converter, switch, hub, workstation, etc.) -
Page 16: Mounting Installation
Lantech Mounting Installation Mounting Installation DIN-Rail Mounting DIN-Rail Mounting The DIN-Rail is screwed on the unit when out of factory. If the DIN-Rail is The DIN-Rail is screwed on the unit when out of factory. If the DIN-Rail is not screwed on the unit, please see the pictures and follow the steps not screwed on the unit, please see the pictures and follow the steps below to screw the DIN-Rail on the unit. - Page 17 Lantech After the DIN-Rail is screwed on the rear side of the unit, insert the top of DIN-Rail into the track. Then, lightly push the DIN-Rail into the track. Check if the DIN-Rail is tightened on the track or not.
-
Page 18: Wall Mount Plate Mounting
Lantech Wall Mount Plate Mounting Follow the steps below to mount the unit with wall mount plate. Remove the DIN-Rail from the unit; loose the screws to remove the DIN-Rail. Place the wall mount plate on the top & bottom side of the unit. -
Page 19: Network Connection
Lantech Network Connection Network Connection In this paragraph, we will describe how to install the Industrial 10/100Base TX In this paragraph, we will describe how to install the Industrial 10/100Base TX to 100BaseFX Media Converter. to 100BaseFX Media Converter. Installation Steps Unpack the unit packing. - Page 20 Lantech installation. If you want to wall mount the unit, then please refer to Wall Mount Plate Mounting section for wall mount plate installation. To hang the unit on the DIN-Rail track or wall, please refer to the Mounting Installation section.
-
Page 21: Troubles Shooting
Lantech Troubles shooting Verify that you are using the right power cord/adapter (DC 9-56V), please don’t use the power adapter with DC output bigger than 48V, or it will burn this converter down. Select the proper UTP/STP cable to construct your network. Please check that you are using the right cable. -
Page 22: Technical Specification
Lantech Technical Specification Technical Specification The technical specifications of the unit are listed as follows. The technical specifications of the unit are listed as follows. Communications Communications Compatibility IEEE 802.3, 802.3u, 802.3x 10/100Base-TX Multi-Mode Fiber 2km Transmission Distance Single-Mode Fiber 30km... - Page 23 Lantech Mechanism 30 x 95 x 140 mm Dimensions (WxHxD) Enclosure IP30, Metal shell with solid mounting kits Mounting DIN35 rail, Wall Protection ESD (Ethernet) 6,000 V 3,000 V Surge (EFT for power) Power Reverse Environment -40 ~ 75 C (wide operating temperature...
- Page 24 Lantech CE EN61000-4-11, CE EN61000-4-12, CE EN61000-6-2, CE EN61000-6-4 Free Fall IEC60068-2-32 IEC60068-2-27 Shock Vibration IEC60068-2-6...
