User manual / Assembly instructions

Deponti Veranda

Type Trebbiano

Versie: EN – April 2025

www.deponti.com

Need help?

Do you have a question about the Trebbiano 8.8 and is the answer not in the manual?

Questions and answers

Summary of Contents for Deponti Trebbiano 8.8

Page 1 User manual / Assembly instructions Deponti Veranda Type Trebbiano Versie: EN – April 2025 www.deponti.com...
Page 2 ..............www.deponti.com...
Page 3 Before you can start enjoying your veranda it must be assembled properly. This manual provides clear instructions for all the steps you must complete for correct assembly of your Deponti veranda. We recommend that you take the time to read the entire manual before you begin assembly.
Page 4 Dispose the product in accordance with local laws and regulations. • Deponti B.V. accepts no liability for damage or injury caused by not (strictly) observing the safety regulations and instructions in this manual, or by negligence during assembly, use and maintenance of the product and any accompanying accessories.
Page 5 IEC 61535. • Always consult the assembly instructions of the supplied products and act in accordance with these instructions. • The installation coupling systems do not replace the national standard system of plugs and sockets. www.deponti.com Assembly manual Trebbiano page 5...
Page 6 LED lighting. The Deponti veranda Trebbiano is as standard available in widths of 3914, 4878, 5842 or 6806 mm. There is no limit to the number of sections that can be joined end to end. The veranda can have a projection of 2982, 3482, 3982 of 4482 mm deep.
Page 7 The net snow load on the roof follows from the Sk value (location- dependent), with correction factors for, among other things, the shape of the veranda, its position in relation to other structures and the envisaged service life of the veranda. Trebbiano 8.8 (TV) Dimensions of veranda Max. load downwards Max.
Page 8 1,28 4878 x 4482 mm 0,91 1,28 5842 x 4482 mm 0,91 1,28 6980 x 4482 mm 0,86 1,28 Maximum load is the characteristic value without safety factors or reduction through the reference period. www.deponti.com Assembly manual Trebbiano page 8...
Page 9 Note: Always carefully check the delivered items against the accompanying delivery note to ensure that the quantity and quality are correct. Any visible defects must be reported in writing within 7 days of delivery. www.deponti.com Assembly manual Trebbiano page 9...
Page 10 05. Splash profile 06. Drip profile 07. Rubber gutter 08. Adjustment profile 09. Wall profile finish cover In between beam package 10. In between beam 11. Glazing bead 12. Cover U-profile including glass profile www.deponti.com Assembly manual Trebbiano page 10...
Page 11 17. Cover cap left 18. Cover cap right Trebbiano rain water drainage (RWD) package 19. Water drainage RWD drilling jig 20. Glass plate 21. Pressure distribution 22. Pressure distribution 23. 90° RWD bend plate small plate large www.deponti.com Assembly manual Trebbiano page 11...
Page 12 Screw 4.2x19mm Screw 4.2x32mm Connection cable LED lighting Optional Coupling piece gutter Trebbiano set Coupling piece Coupling piece finish Connection piece centre cover post PP & Trebbiano 26. Mounting base Screw 6.3x25mm LED cover strip www.deponti.com Assembly manual Trebbiano page 12...
Page 13 Screws and drilling • Deponti supplies special 4.2x19 mm and 4.2x32 mm stainless steel screws with the veranda. Note: Pre-drill a hole for each screw with a 3 mm drill bit (unless indicated otherwise)! If you continue to turn them after they are tight, the screw head may break off. It is recommended that you screw carefully, with the torque limiter on your drill set properly.
Page 14 Warranty is void if the Trebbiano veranda is not assembled and installed in accordance with these instructions. www.deponti.com Assembly manual Trebbiano page 14...
Page 15 ø3 | ø Ø60 17mm www.deponti.com Assembly manual Trebbiano page 15...
Page 16 6806 x 3982 mm 840 x 3870 3914 x 4482 mm 840 x 4415 4878 x 4482 mm 840 x 4415 5842 x 4482 mm 840 x 4415 6806 x 4482 mm 840 x 4415 www.deponti.com Assembly manual Trebbiano page 16...
Page 17 Height from ground to bottom of wall profile Height from ground to underside of beam Height from ground to underside of gutter Length of wall profile Distance from rear of wall profile (wall) to front of posts www.deponti.com Assembly manual Trebbiano page 17...
Page 18 (optional) mounting feet, you should cut the posts on the desired length from the ground to the underside of the gutter (H3). When installing a Deponti Fiano Glass Sliding Door system under the Trebbiano, we recommend choosing a height of 2255 for H3 and 2420 for H2, or 2355 for H3 and 2520 for H2.
Page 19 Now drill holes with the appropriate bit. Make sure the wall profile is mounted level. Secure the wall profile. Provide the right fasteners yourself. The heads of the screws should have a maximum thickness of 5 mm. www.deponti.com Assembly manual Trebbiano page 19...
Page 20 Assembly manual Trebbiano page 20...
Page 21 ø60 mm hole in the centre of the post. Bear in mind that for the height, the RWD may end up below ground level (on a drainpipe), or just above ground level. www.deponti.com Assembly manual Trebbiano page 21...
Page 22 3. Place the RWD pipe through the top hole of the post and slide it over the RWD bend. Saw the RWD pipe to size so that it extends ±10 mm below the plate of the post. www.deponti.com Assembly manual Trebbiano...
Page 23 M12 5.8 Hilti-HY 200 anchors with a bonding depth of 170 mm. B: Length of the wall profile D: Distance of the back side of the wall profile (wall) to the front of the posts. www.deponti.com Assembly manual Trebbiano page 23...
Page 24 6060 mm 4878 x 4482 mm 4870 mm 4474 mm 6746 mm 5842 x 4482 mm 5834 mm 4474 mm 7493 mm 6806 x 4482 mm 6798 mm 4474 mm 8286 mm Table: 6.4.1 www.deponti.com Assembly manual Trebbiano page 24...
Page 25 2. Unscrew the front and rear cap from the beam. 3. Drill a hole with a diameter of ø10 in the rear cover. 4. Drill a hole with a diameter of ø10 in the bottom of the beam on the front. www.deponti.com Assembly manual Trebbiano page 25...
Page 26 Pull the supplied wire through the rear plate and through the beam. Thread the wire at the front of the veranda through the hole. www.deponti.com Assembly manual Trebbiano page 26...
Page 27 6. Screw the front plate back into the beam. 7. Screw the rear plate back into the beam. www.deponti.com Assembly manual Trebbiano page 27...
Page 28 Tighten the lock nuts only a few turns. Next, attach the small pressure distribution plates with the M10 screws. Only then tighten everything evenly (crosswise). www.deponti.com Assembly manual Trebbiano page 28...
Page 29 60mm hole drill bit, using the point marked with a marker as the centre of the hole. Also drill through the corner piece 5. Next, place the RWD in the hole and screw it down using ST 4.2 x 19mm screws. Ø60 www.deponti.com Assembly manual Trebbiano page 29...
Page 30 6. Place the leaf catcher in the RWD. www.deponti.com Assembly manual Trebbiano page 30...
Page 31 Make sure the bottom of the gutter is flush with the top of the posts. Make sure the RWD falls into the RWD pipe. Screw corner pieces to the posts using two ST 4.2 x 19mm screws in the holes previously drilled. www.deponti.com Assembly manual Trebbiano page 31...
Page 32 Next, attach the small pressure distribution plates with the M10 screws. Only then tighten everything evenly (crosswise). Attach the corner piece to the second gutter. Do this as described in steps 3 and 4. www.deponti.com Assembly manual Trebbiano page 32...
Page 33 6. Drill 2 holes of 4.0mm in both posts in the inside of the veranda, 15mm from the top. 7. Place the first gutter with the corner piece in the first post. Allow the connection piece to rest on the second post. www.deponti.com Assembly manual Trebbiano page 33...
Page 34 10. Use a lift to raise up the gutters at the coupling piece it protrudes about 35 millimetres above the post. 11. Then insert the connection piece centre post PP & Trebbiano into the post from above. Then lower the gutter until it rests on the connection piece. www.deponti.com Assembly manual Trebbiano page 34...
Page 35 12. Use 4x ST 4.2 x 19mm to attach the coupling piece to the connection piece. Screw the self- drilling screws into the holes in the coupling piece and connection piece. www.deponti.com Assembly manual Trebbiano page 35...
Page 36 13. Screw the corner pieces to the posts using two ST 4.2 x 19mm screws in the holes previously drilled. www.deponti.com Assembly manual Trebbiano page 36...
Page 37 Then screw the glass profile to the gutter using the ST 4.2x19mm screw. Do this for both side beams. 5. Attach both beams to the corner pieces with 3x ST 4.2 x 19mm screws. www.deponti.com Assembly manual Trebbiano page 37...
Page 38 Screw the posts to the blind mounting bases on at least two sides. Do this with ST 6.3 x 25mm screws, 4 x per side. Position the screws as shown in the image below. www.deponti.com Assembly manual Trebbiano page 38...
Page 39 NOTE! The placement of the power supply is important so that later the top cover can be clicked around it. Connect the cable pulled through the beam to one of the two thin cables of the power supply. www.deponti.com Assembly manual Trebbiano page 39...
Page 40 Remark 4: A maximum of 7m of LED lighting may be connected to one driver. When connecting multiple gutters, an additional driver must be installed. (incl. 5m 24v cable through the girder). LED strips cannot be interconnected if several drivers are connected. www.deponti.com Assembly manual Trebbiano page 40...
Page 41 4. Decrease light intensity 5. Group 1, Group 2 and Group 3 6. Save / recall preset 1 7. Save / recall preset 2 8. All groups (1 to 3) 9. Factory reset hole 10. Battery cover www.deponti.com Assembly manual Trebbiano page 41...
Page 42 3x slowly and then 3x quickly. The remote control has now been reset to the factory settings. www.deponti.com Assembly manual Trebbiano page 42...
Page 43 6. Pre-drill Ø4.5mm holes in the glass profiles of the in between beam that align with the groove in the front gutter. Then screw the glass profiles to the gutter using 2x St. 4.2x19mm screws. www.deponti.com Assembly manual Trebbiano page 43...
Page 44 Assembly manual Trebbiano page 44...
Page 45 7. Repeat the previous steps 1 to 6 to fit the remaining top covers and in between beams. Be sure to work from one side to the other. www.deponti.com Assembly manual Trebbiano page 45...
Page 46 1. Fold over the protruding flaps of the foam and place them between the gutter rubbers. 2. Cut the foam flaps at the level of the gutter rubbers. www.deponti.com Assembly manual Trebbiano page 46...
Page 47 1. Pre-drill Ø4.5mm holes in the glass profiles of the beams that align with the slot in the top covers. Screw the glass profiles to the top covers with the ST 4.2x19mm screws. www.deponti.com Assembly manual Trebbiano page 47...
Page 48 1. Remove the protective film from the tape. 2. Stick the glass drip profile on the underside of the glass plate at the end side. 3. Repeat steps 1 and 2 for all glass panels. www.deponti.com Assembly manual Trebbiano page 48...
Page 49 Then lay the first glass pane between the beams on the glass profile. 2. Remove the protective film from the tape and stick the splash profile to the glass panel. Make sure the splash profile falls between the glass profiles and rests against the gutter. www.deponti.com Assembly manual Trebbiano page 49...
Page 50 4. Pre-drill Ø4.5mm holes in the glazing beads. Drill the holes approximately 900mm apart. Start approximately 50mm from one end and end approximately 50mm from the other end. Then screw the glazing beads to the glass profiles with the ST 4.2 x 32mm screws. 55.2 www.deponti.com Assembly manual Trebbiano page 50...
Page 51 5. Repeat the previous steps 1 to 4 for the other glass panels and glazing beads. www.deponti.com Assembly manual Trebbiano page 51...
Page 52 40mm. This ensures a better fit between the rubber and the glass. 5. Thoroughly seal the adjustment profile (between the wall and the adjustment profile) at the top. Finish the sealant smoothly and watertight. This section is marked in red on the drawing. www.deponti.com Assembly manual Trebbiano page 52...
Page 53 At the in between beams, place the cover U-profiles over the beams and slide them against the gutter. Align them with the top of the beams. www.deponti.com Assembly manual Trebbiano page 53...
Page 54 NOTE! The cover cap for the left and right hand side are different. Make sure the cover caps align correctly with the posts. NOTE! Tape may adhere poorly in wet weather conditions. Use a drop of mounting kit for extra security. www.deponti.com Assembly manual Trebbiano page 54...
Page 55 Optional: when coupling verandas, add the finish cover to the coupling piece. 1. Remove the protective film from the finish cover of the coupling piece. 2. Press the finish cover onto both gutters. Make sure the cover is properly aligned with the posts. www.deponti.com Assembly manual Trebbiano page 55...
Page 56 1. Screw the finish cover for the wall profile with 4x ST4.2 x19mm screws to the wall profile and beams. www.deponti.com Assembly manual Trebbiano page 56...
Page 57 Congratulations! Your veranda is now finished! www.deponti.com Assembly manual Trebbiano page 57...
Page 58 • Glass drip profile = 783 • Wall profile = 5500 • Adjustment profile = 5500 Width (W) Finish cover Finish cover Finish cover D = Distance between centres of the in between beams. www.deponti.com Assembly manual Trebbiano page 58...
Page 59 NOTE! This Deponti Trebbiano veranda should be installed with a slope for the glass of at minimum 28 mm per metre. To shorten the projection, you need to shorten multiple parts. Below is a calculation help and example of how to shorten the width.
Page 60 8. Cut the LED strip to size. This can be done in 5cm increments. To reconnect the LED strips, you can order a set of LED strip connectors from Deponti. This way, you can simply follow the diagram shown later in the manual.
Page 61 9. After cutting everything to size, place the parts (except the screws, washers and locknuts) back on the gutter. Start at the rubber gasket. Make sure the threaded rods protrude 20mm from the gutter. www.deponti.com Assembly manual Trebbiano page 61...
Page 62 Make sure the glass profile is flush with the mounting plate. At the front of the beam, the glass profile should protrude +/- 3 mm below the beam. Mount the glass profile to the beam with the Deponti ST 4.2 x 19mm screws. Note: - When working on the glass profile, lay the beam tube on its side.
Page 63 Assembly manual Trebbiano page 63...
Page 64 • Never use a high-pressure sprayer. Deponti B.V. has a special cleaning product in its range. Ask your partner. Dispose of the product according to local laws and regulations. Warranty in accordance with the warranty conditions and Deponti’s general terms and conditions.
